Used Walker Process Equipment
Stock No.:
10128096Used Walker 2,000 Gallon Stainless Steel Processor Kettle | Model PZ-C3-PV | Jacketed | 3 HP Scrape Agitator
Used Walker 2,000 Gallon Stainless Steel Processor Kettle | Model PZ-C3-PV | Jacketed | 3 HP Scrape Agitator. Dished top, coned bottom. 96" OD x 72" straight side. Vessel is 10 PSIG at 250 degrees F. Jacket heat is 15 PSIG at 250 degrees F. Jacket cool is 100 PSIG at 100 degrees F. Anchor style scrape agitator, driven by a 3hp 3/60/230/460v 1760rpm motor through a reducer. Jacket has three zones with 2" valves. Jacket has 3" condensate with 4" outlet. Bottom has 3" tri clamp outlet. Top has 19" hinged manway with 4" sight glass. Nozzles on top are threaded 6", threaded 3", (2) 3" tri clamp and (2) 2" tri clamp. Serial# 75-7.
MFR: Walker
Stock No.:
54255001Used Walker 316L Stainless Steel Reactor, Model SP | 800L (211 Gal) | 50 psig | Agitated & Jacketed | NB#1646
Used- Walker 316L Stainless Steel Reactor, Model SP. 800L (approx. 211 gallons) capacity. Vessel internal rated 50 psig and full vac at 275 degrees F. Jacket rated 50 psig MAWP at 275 degrees F. -20 degrees F at 50 psi MDMT. Dish top and bottom. 2" tri-clamp center bottom outlet. Openings: (2) 2" top tri-clamp, 4" sight glass, 8" drive, 16" top manway w/ 4" sight glass in cover. Off-center top entering 1725 RPM, .75 HP Lightnin agitator. Has spray ball. Mounted on (3) stainless steel legs. NB #1646. Built 1989. Our Freight specialists can assist with any trucking and customs documents to ensure a smooth transition.
MFR: Walker
Stock No.:
11059386Used Walker Vertical Jacketed Mix Tank – 2,500 Gallon Stainless Steel
Used Walker Vertical Jacketed Mix Tank 2,500 Gallon Stainless Steel. 15' overall height. Top entering 10 HP right angle center turbine agitation, with stainless steel shaft and dual pitched turbines. Stainless steel side wall baffles and thermowell. 3" Outlet. Last used in sanitary cosmetics facility.
MFR: Walker
Stock No.:
11059383Used Walker 500-Gallon Jacketed Stainless Steel Mix Tank | Model PZ-ST | Heated Process Vessel
Used Walker 500-Gallon Jacketed Stainless Steel Mix Tank | Model PZ-ST | Heated Process Vessel. Jacket rated 100psi at 250 degrees F. Top mounted mixer driven by a 1hp 3/60/230/460v 1730rpm motor through reducer 55.17:1 ratio. Height 86" with agitator.
MFR: Walker
Stock No.:
54296006Used Walker 800 Gallon Stainless Steel Jacketed Processor Kettle – Anchor Agitat
Used Walker Model PZ-CB-SP vertical 800-gallon processor kettle fabricated from 304L stainless steel, designed for heating, cooling, and mixing viscous products in food, dairy, cosmetic, pharmaceutical, and chemical applications. Vessel measures approximately 58" diameter x 72" straight side with a dished top and slight cone bottom. Atmospheric-rated vessel with a 304 stainless steel jacket rated 50 PSI (-20F to 300F) providing approximately 64 sq. ft. of heat transfer surface. Equipped with a top-entering anchor-style scrape agitator driven by a 5 HP, 3/60/460 volt motor through a 97.89:1 gear reducer for slow-speed, high-torque mixing and efficient wall scraping. Features a 20" manway, 16" x 12" top opening, multiple process nozzles, 4" center bottom outlet with approximately 24" discharge height, 1-1/2" side outlet, and is mounted on (3) stainless steel legs. Serial #8210, National Board #3136, built 1994.
MFR: Walker
