Used-Sistersville Tank Works Approximately 15,444 Gallon C276 Hastelloy Vertical
Used-Sistersville Tank Works Approximately 15,444 Gallon C276 Hastelloy Vertical Tank. 144" diameter X 168" high straight side. Internal rated 15 PSIG @ 212 degrees F. Shell max external pressure 13.07 PSIA. Dished top and bottom head. Top fittings: 4" with 2" diptube, 4", 3", 4", 12", 4" with 1" diptube, and 2". 12" center bottom drain reduced to 3" and (1) 3" off-center drain. Side fittings: 8", 8", 8", 4", 8", 24" manway, 4" with 1" inlet, 4" with 2" inlet, 4" with 1" inlet, 4", 4", and 4". Has (3) 304 stainless steel stiffening rings. Mounted on (4) carbon steel legs. Serial# 95-131, National Board# 3265.
