Kettles

Used Groen TDH-40 Table Top Kettle – 40 Quart, Gas-Heated, Steam Jacketed

Used- Groen Table Top Kettle, Model TDH-40, 40 Quart Capacity, Stainless Steel. Approximate 16-1/2" diameter x 14" deep. Self-contained steam jacketed unit with natural gas heated steam source contained within unit. Input rated 52,000 btu / hr. 2/3 bottom jacket rate 50 psi at 300 degrees F. Manual tilting with pour lip. Mounted on a base. National Board# 12100, Serial# 1988-10.

MFR: Groen

Commercial Tabletop Kettle for Sale – Groen TDH-40, Natural Gas Heated

Used- Groen Model TDH-40 Table Top Kettle, 40 Quart Capacity, Stainless Steel. Approximate 16-1/2" diameter x 14" deep. Self-contained steam jacketed unit with natural gas heated steam source contained within unit. Input rated 52,000 btu / hr. 2/3 bottom jacket rate 50 psi at 300 degrees F. Manual tilting with pour lip. Mounted on a base. National Board# 13816, Serial# 1989-4. 1/60/110 Volt.

MFR: Groen

Commercial Stainless Steel Groen TDH-40 Kettle – 40 Qt, Self-Contained Steam

Used- Groen Stainless Steel Table Top Kettle, Model TDH/40-SP, 40 Quart Capacity. Approximate 16-1/2" diameter x 14" deep. Self-contained steam jacketed unit with natural gas heated steam source contained within unit. Input rated 52,000 btu / hr. 2/3 bottom jacket rate 50 psi at 300 degrees F. Manual tilting with pour lip. Mounted on a base. National Board# 32385, Serial# 32385. 1/60/110 Volt.

MFR: Groen

Industrial Groen TDH-40 Tabletop Steam Kettle – 40-Quart, Tilting, Natural Gas

Used- Groen 40 Quart Capacity Table Top Kettle, Model TDH-40, Stainless Steel. Approximate 16-1/2" diameter x 14" deep. Self-contained steam jacketed unit with natural gas heated steam source contained within unit. Input rated 52,000 btu / hr. 2/3 bottom jacket rate 50 psi at 300 degrees F. Manual tilting with pour lip. Mounted on a base. National Board# 29964, Serial# 29964. 1/60/110 Volt.

MFR: Groen

Groen 100 Gal Steam Jacketed Kettle – 125 PSI | Radicon Drive | TA100 SP

Used Groen Kettle, Model TA100 SP, 100 Gallon, Stainless Steel. Approximately 36" diameter x 30" deep. Open top, hemispherical bottom. Jacket rated 125 psi. Bridge Mounted Radicon Drive with Anchor Agitator. Provision for Teflon Wipers (Wipers not Included). Driven by a 2hp 3/60/230/460 volt, 1755 rpm gear motor 63:1 ratio. Openings top: (2) 4", 2", 1-1/2", 2-1/2" center bottom outlet with 10-1/2" discharge height. Serial# 88772. Mounted on 3 legs.

Used Lee 1,000 Gallon Double Motion Jacketed Agitated Tank – 316L SS Scraper Mixer with Dual 10 HP Drives

Used- Lee 1,000 Gallon SS Double Motion Jacketed Scraper Agitated Tank, Model 1000U9MS. Features dual stacked 10 HP drives for counter rotating inner agitator and outer scraper agitator. 316L SS contact parts, internal sanitary finish 20-30 RA, welds ground smooth and flush, dished bottom with center bottom outlet. Agitator support channel with two piece hinged SS cover. Maximum Jacket Pressure 100 PSI, @ 338 Degrees F. NB # 10427. Controls include (2) VFDs. Serial# 41807-1. Built 2005.

MFR: Lee Ind

Used Groen N-125 SP Agitated Kettle – 125 Gallon, High-Shear, 316 SS

Used- Groen Agitated Kettle, Model N-125 SP, Approximately 125 Gallon Capacity, 316 Stainless Steel, Vertical. Approximate 38" diameter x 34" deep. Open top, hemispherical bottom. 304 Stainless steel Jacket rated 125 psi at 353 degrees F. Top entering high shear homogenizing agitator, driven by a 3hp, 3/60/230/460 volt, 3450 rpm motor. 1-1/2" Center bottom outlet with valve, 19" discharge height. Mounted on 3 legs with casters. National Board# 68679, Serial# 1974.

MFR: Groen

13 Gallon (50 Liter) Agi-Mixer Triple Motion Greerco Jacketed Vacuum Kettle

13 Gallon (50 Liter) Agi-Mixer Triple Motion Greerco Jacketed Vacuum Kettle. 316 Stainless Steel. Has counter rotating sweep mixer with scrapers and high shear mixer. Internal rated Full Vacuum. Jacket rated 40 PSI @ 300 Deg.F..Top Drive motor Disconnected for removal. Test results: The previous owner reports that all components of the homogenizer are fully functional. Fully tested with H2O. The homogenizer and inner and outer paddles work as do their RPM meters. The cover lifting hydraulics is fully functional. The cover lift mechanism is functional as well as the homogenizer and the two blades. The jacket was pressure tested and vessel was vacuum tested - no leaks. The chart recorder is out of service as well as the hour meter. The light bulb that gave me trouble in the video was replaced.Note: The outer paddles must be jogged to index, (amber light), before the cover will open. The limit switch with long arm to contact tank, must be in the correct position for lifting and for paddle operation. Last used in sanitary cosmetics facility. Video of unit running available.

MFR: J C Pardo & Sons

Used Lee RA-150 150-Gallon 316 Stainless Steel Jacketed Kettle with Scrape Surface Agitation

Used Lee RA-150 150-Gallon 316 Stainless Steel Jacketed Kettle with Scrape Surface Agitation. Serial Number 84164-1-4. 316 Stainless Steel construction. Jacket Rated 90PSI at 332 Deg F, 90PSI at -20 Deg F at 90PSI. Inside dimensions: 42" ID x 40.5" deep. Center bottom outlet 2 " ferrule for Cherry Burrell valve (no valve). Single motion scrape surface agitation w/1.5HP drive and baffle. Two-piece cover. Has Thermometer and Sprayball. Built in 2014.

MFR: Lee Ind

Used Hamilton Style CW 150-Gallon Tilting Kettle – 316 Stainless Steel, Jacketed

Used- Hamilton Style CW Tilting Kettle, 150 Gallon, 316 Stainless Steel. Approximate 44" diameter x 40" deep. Open top, jacketed hemispherical bottom. 304 Stainless steel jacket rated 100 psi at -20 to 328 degrees F. Top entering angled anchor style agitator with scrapers, driven by a 2 hp, 3/60/208-230/460 volt, 1750 rpm gear motor, approximate 44.32 to 1 ratio (no gearbox tag). Air operated agitator tilt, motorized bowl tilt, pouring lip. 3" Center bottom outlet with valve. Mounted on a stainless steel frame with (3) leg. National Board # 17. Serial # F-4662-3. Built 2002.

MFR: Hamilton

Industrial Hamilton CW 150-Gallon Steam Jacketed Kettle – Motorized Tilt

Used- Hamilton Style CW Tilting Kettle, 150 Gallon, 316 Stainless Steel. Approximate 44" diameter x 40" deep. Open top, jacketed hemispherical bottom. 304 Stainless steel jacket rated 100 psi at -20 to 328 degrees F. Top entering angled anchor style agitator with scrapers (missing 1 scraper), driven by a 3 hp, 3/60/208-230/460 volt, 1750 rpm gear motor, approximate 44.32 to 1 ratio (no gearbox tag). Air operated agitator tilt, motorized bowl tilt, pouring lip. 3" Center bottom outlet with valve. Mounted on a stainless steel frame with (3) leg. National Board # 278. Serial # F-5817-2. Built 2004.

MFR: Hamilton

Hamilton 150-Gallon Tilting Kettle – Stainless Steel, Steam Jacketed, Food-Grade

Used- Hamilton Style CW Tilting Kettle, 150 Gallon, 316 Stainless Steel. Approximate 44" diameter x 40" deep. Open top, jacketed hemispherical bottom. 304 Stainless steel jacket rated 100 psi at -20 to 328 degrees F. Top entering angled anchor style agitator with scrapers (missing 2 scraper), driven by a 2 hp, 3/60/208-230/460 volt, 1750 rpm gear motor, approximate 44.32 to 1 ratio. Air operated agitator tilt, motorized bowl tilt, pouring lip. 3" Center bottom outlet with valve. Mounted on a stainless steel frame with (3) leg. National Board # 279. Serial # F-5817-3. Built 2004.

MFR: Hamilton
