Used 500 to 999 Gallon Stainless Steel Tanks

Stock# 53570005

Used- Viatec 500 Gallon Stainless Steel Mix Tank, 304 Stainless Steel, Vertical. Approximate 48" diameter x 65" straight side. Flat top, conical bottom. Agitator bridge with top entering dual (4) turbine agitator, approximately 1-3/4" diameter x 50" long shaft. Driven by a 1.5hp, 3/60/230/460 volt, 1740rpm gear motor, 17.21:1 ratio. Openings Top: 3", 2.5", 2". 2" Center bottom outlet with valve, 17-1/2" discharge height. Mounted on (4) legs. Serial# 107251-2.

Stock# 53244001

Used- Cherry Burrell Jacketed Tank, Approximately 575 Gallons, 316 Stainless Steel, Vertical. Approximately 54" diameter x 54" straight side. Dished top and bottom. 304 Stainless steel channel jacket, approximate 19 sq ft. Openings Top: 18" manway with cover, 8" for agitator, (3) 3", (3) 2". Approximately 3" center bottom outlet with 11" discharge height. 304SS sheathed with 1" high density mineral wool insulation on sidewall only. Mounted on (3) stainless steel legs. Serial# 88E-114.

Stock# 52848001

Used- G2 Material Handling Agitated Tank, 700 Gallon Capacity, 304 Stainless Steel, Vertical. Approximate 58" diameter x 52" straight side, 10 degree slope. Dome Top, slope bottom. Top center entering agitator, 4-blade Turbine with 48" long x 1-1/2" diameter shaft. Driven by a 1-1/2hp, 3/60/208-230/460 volt, 1755rpm motor through a reducer. Openings Top: 18" manway, 6" for agitator, 3", (2) 2", 1-1/2", 13" x 8" wide vent, 2" side bottom outlet, 6" side bottom outlet with slide gate. Includes (2) spray balls, (3) baffles. Mounted on (4) legs. Serial# 333555. Built 2013.

Stock# 53304005

Used- Apache Stainless Pressure Tank, Approximate 600 gallon capacity. 316L Stainless Steel, Vertical. Dished top and bottom. Internal rated 35/FV psi at 100 degrees F. Serial # 10452-3, Built 1997.

Stock# 53304006

Used- Jacketed Tank, Approximate 600 gallon. Stainless Steel, Vertical. Dish top, cone bottom.

Stock# 53304012

Used- Chester-Jensen 600 Gallon Mix Tank, Stainless Steel, Vertical. Top entering agitator. Sidewall baffle. Side bottom outlet.

Stock# 53400001

Used- ACE Stainless Steel Jacketed Mix Tank, Model ACE-M. 2500 L (660 gallon) capacity. Jacket rated (reported by OEM): 4bar; Internal pressure: -0.1~2bar; 0-110 degree C (32-230 degree F) working temperature. 316L SS contact parts; dish top and bottom; (3) four-blade agitator; baffles; center bottom outlet; topside manway cover. On (4) ss legs. With control cabinet. 1720 RPM, 37 kW (50 HP), 3/60/480V drive included but not installed. Built 2019.

Stock# 50345011

Used- 6 Compartment Rectangular Tank, Approximate 700 Total Gallons, 304 Stainless Steel. (4) Compartments each approximate 20" wide x 36" long x 34" deep, each with a spray ball, each with a 1" diameter shaft with a 3 blade turbine, each driven by a 1/2 hp gear motor, each with a 11" x 15" top man way with door, each with a 2" tri-clamp off center bottom outlet. (1) Compartment 40" wide x 36" long x 34" deep with a spray ball, 1" diameter shaft with a 3 blade turbine, driven by a 1/2 hp gear motor, 11" x 15" top man way with door, 2" tri-clamp off center bottom outlet. (1) Compartment approximate 20" wide x 36" long x 34" deep, 11" x 15" top man way with door, 3" tri-clamp off center bottom outlet. Mounted on 8 stainless steel legs. No manufacturers tag.

Stock# 53267017

Used- Circleville Metal Works Inc. approximately 750 gallon Mix Tank. 304 stainless steel vertical 60" diameter X 60" high straight side. Internal rated 0.25 PSI @ 212 F. S/N CMW-940. Dished top and bottom. Top fittings: 20" manway, (2) 1.5", (2) 2", (3) 3", and (1) 4". 2" center bottom drain. Equipped with anchor style agitator driven by Philadelphia right-angle drive Model MT04. S/N 508380 rated 1750 RPM input, 84 RPM output. Powered by 5HP 3/60/230-460 volt motor. Mounted on (4) legs giving 27" clearance. Built 1975.

Stock# 10151500

Used- Alloy Fabricators Approximately 820 Gallon 304 Stainless Steel Tank with Internal Coils. 52" diameter x 72" straight side; Dished top and bottom; Coils rated 85 psi at 335 degrees F; Mounted on legs. Serial # 1-147A; Built 1991.

Stock# 53147044

Used- C.E. Howard 850 Gallon Stainless Steel Jacketed Tank. Constructed of 304 stainless steel. Vessel measures 5' diameter X 6-1/2' straight side with dished top and bottom (7''1" internal height from dish to dish). Internals includes (2) baffles and top entering agitator shaft with two sets of 2-blade paddles, driven by top mounted drive through gear reducer, 2 HP, 1700 RPM, 230/460V, 3/60Hz, SEW Eurodrive gear motor, resulting in 61 output RPM. Vessel is mounted on 3'3" high stainless steel legs. Top head includes 20" diameter manway, 8" diameter flanged connection for motor mounting and (4) 2" inlets. Bottom head includes 3" diameter center bottom outlet. Also includes 2" diameter jacket connections. Vessel is fully jacketed with dimpled jackets on straight side and bottom head, ASME rated jacket, rated for 75 PSI. Tank was used for beverage processing.

Stock# 52845001

Reportedly Unused Gemmer Process Partners 855 Gallon Pressure Tank, 316L Stainless Steel, Vertical. Approximate 51" diameter x 78" straight side. Dished bolt-on top, dished bottom. Internal rated 10 bar (145 psi) at 184 degrees C (363 F). Internal pipe coil, approximate 65.5 gallon volume, rated 0 bar (0 psi) at 184 degrees C (363 F). Openings: N6 - 600mm (23.6"), N5 - 80mm (3"), N4 - 50mm (2"), N3 - 50mm (2"), N2 - 40mm (1-1/2"), N1 - 40mm (1-1/2"). Mounted on (3) legs. Serial# 16-0052, Built 2016. Was designed saturated steam (tanks side), sugar solution (coil side).

Stock# 53458004

Used- Bavarian Brewery Technologies Brew Tank, Model F30. Gross Volume 37.2 BBL, Approximately 900 Gallons. 304 Stainless Steel, Approximately 54" diameter x 86" straight side 48" cone. Dished Top, Cone Bottom. Jacket rated 14.8psi. Openings Top: 2-1/2". 2", Side: 17" manway with cover, (2) 1-1/2", 1-1/2" center bottom outlet with 7" discharge height. Mounted on (3) stainless steel legs. Serial# 0211.

Stock# 53267019

Used- Alloy Fabricators Inc. approximately 950 gallon 304 stainless steel vertical Mix Tank. 57" diameter X 84" high straight side. Internal rated ATM @ 200 F. Dished top and bottom Top Fittings: 21" manway, (1) 1.5", (1) 2", and (1) 4". Has a 4" center bottom drain equipped with manual flush valve that reduces down to 3". Has (3)1.5" side inlets and (1) 5" side bottom outlet. Has (4) internal baffles. Equipped with screw type agitator but currently has no drive. Mounted on (4) legs giving 28" clearance.

Stock# 53570003

Used- Feldmeier Approximate 986 Gallon Jacketed Mix Tank, 316 Stainless Steel, Vertical. Approximately 65" diameter x 62" straight side. Dished top and bottom. 304 Stainless Steel Jacket rated 90 psi at -20 to 350 degrees F. Center agitator bridge with anchor style agitation with scrapers and inner bar. Anchor driven by a 5hp, 3/60/230/460 volt, 1770 rpm gear motor, approximately 120.03:1 ratio. Inner bar agitator driven by an approximate 3hp, gear motor. 2" Center bottom discharge with valve, 9" discharge height. Mounted on (4) legs. National Board# 1408. Serial# 5221-A1.
