Used Carbon Steel Tanks

Stock# 49653003

Used- CMC Letco Industries Storage Pressure Vessel with Internal Helic Pipe Coil. Gallon, carbon steel shell. Vertical. Carbon steel internal coil is 13 (500 LF Total length) and 2" sch 160. Coil rated 150 psi at 800 degree F. Vessel is approximately 60" diameter x 16 OAH. Top mounted agitator. No information on agitator manufacturer or hp at this time. Equipped with Gaumer Process Heater. Rated 100 psi at 640 degree F. Year 2011. Klauss Union Magnetic Drive Pump (18kgal/hr) for hot fluid transfer included in sale.

Stock# 50467003

Used- Edlon-PSI 50 Gallon Receiver Tank, Carbon Steel, PFA Lined Construction. Approximately 20" diameter x 30" straight side, removable dish top, dish bottom. Internal rated 150 psi and full vacuum at 350 degrees F. Openings 4", (4) 2" top. 2" Bottom outlet. Mounted on legs. Eldon -PSI SC-7005 PFA coating. Serial # 5235-3. National Board # 90. Built 2000.

Stock# 50467020

Used- Edlon-PSI 50 Gallon Receiver Tank, Carbon Steel PFA Lined Construction. Approximately 20" diameter x 30" straight side, removable dish top, dish bottom. Internal rated 150 psi and full vacuum at 350 degrees f. Openings: 4", (4) 2" top, 2" bottom outlet. Mounted on legs. Eldon -PSI SC-7005 PFA coating. Serial# 5235-1, National Board # 88, built 2000.

Stock# 50467025

Used- Edlon-PSI 50 Gallon Receiver Tank, Carbon Steel PFA Lined Construction. Approximately 20" diameter x 30" straight side, removable dish top, dish bottom. Internal rated 150 psi and full vacuum at 350 degrees F. Openings: 4", (4) 2" top, 2" bottom outlet. Mounted on legs. Eldon -PSI SC-7005 PFA coating. Serial # 5235-4, National Board # 91, built 2000.

Stock# 51358001

Used- Silvan Industries Air Receiver Tank, Approximately 750 Gallons, Carbon steel, Vertical. Approximately 44" diameter x 116" straight side, dished top & bottom. Internal rated 150 psi at -20 to 450 degrees F. 14" x 10" Manway with cover, (2) 6" outlets, 1-1/2" Threaded inlet/outlet, 2" threaded side port. CRN # L151151346 78640. National Board / Serial # 799682, Built 2015.

Stock# 51146003

Used- 1100 Gallon Vertical Carbon Steel Tank. 10/12 gauge double-wall, 82" Diameter x 73.2" High. 22.5" bolted access plate, 6" threaded and capped hose connection. Last used to store new oil.

Stock# 51146004

Used-1000 Gallon Vertical Carbon Steel Tank. 10/12 gauge double-wall, 82" Diameter x 73.2" High, 22.5" bolted access plate, 6" threaded and capped hose connection. Last used to store new oil.

Stock# 51146001

Used- 1100 Gallon Vertical Carbon Steel Tank. 10/12 gauge double-wall, 82" Diameter x 73.2" High, 22.5" bolted access plate, 6" threaded and capped hose connection. Last used to store new oil.

Stock# 51146002

Used- 1100 Gallon Vertical Carbon Steel Tank. 10/12 gauge double-wall, 82" Diameter x 73.2" High, 22.5" bolted access plate, 6" threaded and capped hose connection. Last used to store new oil.

Stock# 51114001

Used- Hamilton Engineering Hot Water Tank, Approximately 1,350 Gallon, Model HET01500. Carbon Steel, Horizontal. Approximate 60" diameter x 93" straight side, Dished ends. Internal rated 125 psi @ 210 degrees F. Openings top: 3", 1", 1/2". (2) 3" bottom outlets. Mounted on saddles. ASME Code. National Board # 11216. Built 2001.

Stock# 51103001

Used- Bendel Tank and Heat Exchanger Tank, 3,500 Gallon, Carbon steel, Vertical. 10 Diameter x 6 high. Dish Top, Flat Bottom. Internal rated Atmospheric at 200 degree F, Design specific gravity: 10. Top Head: Top head is SA516-70 Carbon steel. Bottom and Shell are SA36 Carbon steel. Top Head, Shell and Bottom are all 3/8" thick. Top lifting lugs. Side round manway with cover and davit arm. API Standard 650, Year 2012.

Stock# 51027001

Used- Reitz Fuel Tank, 5,000 Gallon Capacity. Rectangular, 7'10" wide x 10'1" x 6'6" high. Primary and secondary containment Tanks. Top openings: (1) 24" x 30" reverse flange manway, (2) 2" gauge, (2) 4" fill, 6" vent, 8" vent, etc. Tank built to Institute Fireguard and UL 2085 Standards. Weight 17,600. Coated with Morning Mist Chemthane. Has a card reader system. Year 2011.

Stock# 50464001

Used - Carbon Steel Lined Clarifier Tank, 5,200 Gallon Capacity. 185" x 8 diameter, 500 gpm.

Stock# 50464002

Used - Carbon Steel Lined Clarifier Tank, 5,200 Gallon Capacity. 185" x 8 diameter, 500 gpm.

Stock# 50464003

Used - Carbon Steel Lined Clarifier Tank, 5,200 Gallon Capacity. 185" x 8 diameter, 500 gpm.

Stock# 50464004

Used - Carbon Steel Lined Clarifier Tank, 5,200 Gallon Capacity. 185" x 8 diameter, 500 gpm.

Stock# 50464005

Used - Carbon Steel Clarifier Tank, 5,200 Gallon Capacity. Unlined, 185" x 8 diameter, 500 gpm.

Stock# 50464006

Used - Carbon Steel Clarifier Tank, 5,200 Gallon Capacity. Unlined, 185" x 8 diameter, 500 gpm.

Stock# 50464007

Used - Carbon Steel Clarifier Tank, 5,200 Gallon Capacity. Unlined, Approximately 185" x 96" diameter, 500 gpm.

Stock# 50464008

Used - Carbon Steel Clarifier Tank, 5,200 Gallon Capacity. Unlined, 185" x 8 diameter, 500 gpm.

Stock# 48863005

Used- Continental Fabricators Tank, 7,000 Gallon, Carbon Steel, Vertical. Approximate 96" diameter x 18' 10" inside straight side. Slight cone top, slope bottom. Internal rated 14.9 psi at 100 degrees F. Serial# C3025, built 1990.

Stock# 49631002

Unused - Modern Welding Company Tank, 7,000 Gallon. 9 OD x 18 long Tangent to Tangent. Carbon steel shell with Carboline Plasite 3070L internal lining. Horizontal on carbon steel welded saddles. Internal rated atmospheric at ambient temp. Dished Ends. 2" end bottom outlet. Never had any acid put in it. Tank still at Mfg site.

Stock# 49631003

Unused - Modern Welding Company Tank, 7,000 Gallon. 9 OD x 18 long Tangent to Tangent. Carbon steel shell with Carboline Plasite 3070L internal lining. Horizontal on carbon steel welded saddles. Internal rated atmospheric at ambient temp. Dished Ends. 2" end bottom outlet. Never had acid put in the tank. Still at tank manufacturer site.

Stock# 51223001

Used- Insulated 8,000 Gallon Carbon Steel Tank. Angle Bottom Discharge, 12' Diameter x 10' High.

Stock# 51223002

Used- Insulated 8,000 Gallon Carbon Steel Tank. Angle Bottom Discharge, 12' Diameter x 10' High.

Stock# 51583001

Used- Mueller 8000 Gallon Vertical Carbon Steel (SA36) UL-142 Storage Tank. 96" Diameter x 264" Straight Side. Flat Bottom, Cone Top. 24" Side Bottom Manway with Cover. Bottom Head is 1/4" Thick. Shell is 3/16" Thick. (2) Side Lifting Lugs. (2) Top Lifting Lugs. 2" Flanged End Bottom Outlet. Miscellaneous top openings. Built in 2006. Venting Capacity- 354,000 cuft/hr.

Stock# 51573001

Used- Roy E. Hanson Jr. Vertical Ammonia (NH3) Storage Tank, Carbon Steel, 9,949 Gallon Capacity. Internal rated 14.7 psig @ 120 deg F. Shell is SA-516-70 carbon steel. Vertical. Dished heads. Year 2006.

Stock# 43622018

Used - Carbon Steel Storage Tank, 10,000 Gallon, Horizontal. Approximately 10' 6" diameter x 15' 6" straight side. Dished ends. Openings top (1) 1', (2) 4", 17" man way with cover. Bottom (1) 1", (1) 4". No saddle supports or legs.

Stock# 11453400

Used- Hamilton Tank, 30000 Gallon. Carbon steel construction. Approximately 12' diameter x 35' straight side, dish top and bottom. (2) 6", (2) 4" top nozzles, 24" side bottom manway, 4" center bottom outlet. On 4 legs with approximately 24" discharge height, approximately 44' overall height. Built 1993.

Stock# 11453401

Used- Hamilton Tank, 30000 Gallon. Carbon steel construction. Approximately 12' diameter x 35' straight side, dish top and bottom. (2) 6", (2) 4" top nozzles, 24" side bottom manway, 4" center bottom outlet. On 4 legs with approximately 24" discharge height, approximately 44' overall height. Built 1993.
