Used Winding & Unwinding Equipment

Stock# 51555001

Unused - Martin Automatic Transfer Rewind, Model LRD 02-26-24, Maximum Transfer Speed: 150 FPM 46 MPM Maximum Web Width: 26 IN 660 MM Customer Maximum Web Width: 24 IN 610 MM Maximum Roll Weight: 550 LB 249 KG Maximum Roll Diameter: 24 IN 610 MM Number of Pneumatic Spindles: 2 Total 2 Total Spindle Diameter: 3 IN 76 MM Minimum Core Outer Diameter: 3.5 IN 89 MM Maximum Tension: 54 LB 240 N Minimum Tension: 5 LB 22 N Web Running Direction: From left to right when viewed from the operator side Material: .0006 inch PET film. Year 2012.

Stock# 11453404

Used- Black Clawson Turret Winder. 60" wide, 1.5" core with 3" shaft, approximate 36" take up, tensioning, Accuguide unit, 7.5 hp DC winder motors, 4.9 hp 208-230/460 volt volt turret motor.

Stock# 10151037

Used-72" Dusenberry Model 815 Duplex Score Cut Slitter-Rewinder. Having a 25 hp DC and 15 hp DC dual drive system with score slitting assembly duplex differential center wind. Presently set up for one zone control per winding shaft for maximum 28" diameter rolls on 3" cores. Separate Dusenbery Model 863 AK single station unwind for 40" diameter mill rolls on 3" cores with fife guide edge system.

Stock# 76515

Used- GEC Dual Turret Winder, Model 123-12638-2. Approximately 80" wide and 18" diameter rolls.
