Used Twin Screw CoRotate Extruders

Stock# 49338001

Used- Prism TSE 24-TC Twin Screw Extruder. 25:1 L/D. 24 mm diameter screws, co-rotating, split barrel design, electrically heated, water cooled. Max screw speed is 500 rpm via a gearbox by a 3.7 Kw-415volt/50cycle/3Ph motor. Includes: Brabender feeder/hopper, water bath, pelletizer end TSE systems control panel. Table mounted. New year 1995. Previously used in a Masterbatch application.

Stock# 10147152

Used- Krupp Werner & Pfleiderer, Type ZSK 25 WLE. 25 mm diameter screws. 28:1 L/D. Electrically heated, water cooled barrel 2 degassing zone. Max screw speed 610 rpm via a PIV21.1 P 82 gearbox, ration 3.22:1 by a 22.5 hp/15Kw 500volt/50cycle/3Ph Siemens 1ML 8166 4AB51 AC motor. On 4 wheels. No control panel included. New 1999. Overall dimensions: 8 5" (2600 mm) long x 33" (1000 mm) width x 52" (1600 mm).

Stock# 10147124

Used-Werner Pfleiderer Stuttgart Double Screw Extruder. Screw diameter 0.08" (25 mm). Co-rotating, L/D 40, (6) heating zones. Electric heating (18 x 500 watts). DC motor 13.94 hp (10.4 kW). Screw speed 50-500 rpm. Manufactured 1990.

Stock# 49582001

Used- Coperion Werner & Pfleiderer Twin Screw Extruder, Type ZSK 26MC Megacompounder. 26 mm diameter screws. 40:1 L/D. Electrically heated, water cooled barrel 2 degassing zone. Maximum screw speed 1200 rpm via a gearbox by a 43.5 hp/29Kw AC motor. On 4 wheels. Incliudes: control panel and Brabender feeding system. New 2009. (1) Coperion Werner & Pfleiderer twin screw side feeder, type ZS-B 25. Frame mounted on 4 wheels. (1) Melt pump system on wheels, Includes: additional infrastructure. Previously used in a R&D Application.

Stock# 47193001

Used- Leistritz 27mm Co-Rotating Twin Screw Extruder, Model ZSE 27/GL-36D. 36 to 1 L/D Ratio, 9 Zone, (8) electrically heated, water cooled barrel zones, (2) top vented, (1) feed section no hopper. Approximate 1.05" (27mm) diameter x 40" (1016mm) long screws. Maximum Screw speed 600 rpm, approximate 41.5" (1054.1mm) center-line height. Driven by a 16.3 kW (22 hp), 460 volt 2310 rpm motor with 3.5:1 gearbox ratio. Control panel with SITOP Power 20 drive. Leistritz Macromatex II operator panel and temperature control. Includes (2) Brabender feeders, Model DDW-P3-FW40-S-40, and Model DDW-H31-FW33/0-35. Serial # 2827. Built 1999.

Stock# 48026001

Used- Leistritz 27mm Co-Rotating Twin Screw Extruder, Model ZSE 27 GL 40D. 40 to 1 L/D ratio. 10 Zone, (9) Electrically heated, water cooled barrel zones, (2) top vented, (1) feed zone, no hopper. Maximum screw speed 1200 rpm. Approximate 42" centerline height. Driven by a 22 kW / 33 hp, 380 volt, 50 cycle, 3 Phase motor thru a gearbox. Includes an 6 hole strand die, (1) Leistritz operator panel, (1) control panel. Has Modicon TSX premium PLC, and Telemecanique drives. Mounted on a carbon steel frame. Serial # 3397. Built 2005.

Stock# 10147151

Used- Baker Perkins-Stoke on Trent Twin Screw Extruder, Type MPC/V30. 30 mm diameter twin screws. Co-rotating. 14:1 L/D. Electrically heated, water cooled barrel 3 degassing zone (blocked). Max screw speed 500 rpm via a Electro Power Gears gearbox, ratio 6.032:1 by a 4.5 hp/3 Kw 180volt/50cycle/3Ph Durslev Mawdsleys DC motor. Includes: feeding system and die head. On wheels. Overall dimensions: 6 5" (2000 mm) long x 33" (1000 mm) width x 65" (2000 mm). Weight 1804 lbs. (820 kgs). Previously used on toner. Reported to be reconditioned.

Stock# 48594001

Used- Leistritz Type LSM 34 GG Twin-Screw Extruder, Co-rotating. 1.34" (34 mm) screw diameter. 6 barrel sections (1) vented, (1) feed section, electrically heated, air-cooled. 42.5" center line height. Max screw speed 300 rpm via a gearbox by a 14 kw-380volt/50 cycle 73Ph motor. (1) Leistriz Macromatex III control panel. Last used in a masterbatch application. Built 1992.

Stock# 48780001

Used- Berstorff 40mm Twin Screw Extruder, Model ZE 40/40A. 28:1 L/D. Approximate 41" long screw x 40-1/2" center line height. (7) Total zones, (6) barrels, electrically heated, air cooled (1) water cooled feed section, (1) Degassing port. No side feeder. Maximum screw speed 427 rpm via a gearbox by a 56 hp / 42 kW, 3/50/440 volt, 3470 rpm motor. (1) Control panel with quick connectors. Built 1993.

Stock# 48821001

Used- Berstorff Twin Screw Extruder, Type 40AX44D-UTX, 40mm screw diameter. Approximate 44:1 L/D ratio. Approximate throughput 90 to 200 kg per hour. Approximate 45-1/2" center line height. Approximate 77" long screws, co-rotating side by side design. 11 barrel sections, (10) zone sections, 2 plugged, (1) feed section. Electrically heated, water cooled, water cooled feed throat. Driven by a 205 hp (153 kW) motor. (1) side feeder, driven by a 2.99 hp (2.2 kW) motor. Control panel with Siemens drive. (1) Berstoff operator panel. Spare parts for extruder. Built 2002.

Stock# 49253001

Used- Coperion Werner & Pfleiderer 40mm Twin Screw Extruder, Type ZSK 40 MCC. Approximate 68" long screws, approximate 68" center line height. Approximate 44:1 L/D Ratio. Co-Rotating side by side screw design. 10 Barrel sections, (1) feed section, no hopper, (4) sections top vented. Electrically heated, water cooled. Maximum screw speed 1200 rpm. Driven by a 112 kW, 400 volt 1776 rpm motor with gearbox. (1) Krupp Werner & Pfleiderer twin screw side feeder Model ZS-B 40, driven by a 2.2 kW motor. (1) Autotherm cooling unit Model AW 95-0/2. Control panel. Operators panel. Miscellaneous spare parts. New 2001.

Stock# 10151201

Used- 40mm Berstorff Model ZE40, 35/1 L/D, Co-Rotating Twin Screw Extruder. New in 1988. Serial #22-E71.00, E.O. # 3491/88, project #301-4964. Electrically heated, air cooled barrel, water cooled feed throat. Belt driven by a 40 hp motor and SCR drive. Rated at 440 rpm screw speed at 2200 rpm input. Includes operator control panel with 6 zone barrel utilizing Eurotherm 808 instruments and 13 die zones Eurotherm utilizing 2208 instruments. Includes hopper and vent stack.

Stock# 43385002

Used- Dr. Collin Extrusion Line. Consists of a pilot plant continuous granulation for studies on the process of extrusion of thermoplastic compounds. Single screw extruder E45P 45 mm. Tank cooling, pelletizer, vacuum pump, forced power supply side, out put 30 kg/H. New 2005 only used for 200 hours. Length 2700 mm with 1180 mm, height 1770 mm, weight 1000 kg. Mfg. 2005.

Stock# 49820001

Used- Steer Mega 58mm Twin Screw Extruder. Includes: extra set of shafts, solenoids, pressure transducer, shaft coupler, heating cartridges, thermocouples, (1) side stuffer, (1) extended side stuffer, (1) vacuum side stuffer. 6628 hours.

Stock# 49253003

Used- Coperion Werner & Pfleiderer twin screw side feeder model ZS-B 58, driven by a 5.5 KW motor, built 2001, Serial# 20475727.

Stock# 47929001

Used- Theysohn Twin Screw Extruder, Type N 60-36D 5096. 2.34" (60mm) diameter 33:1 L/D. Co-rotating. 8 housing sections, electrically heated, water cooled. (1) Vent port. Max screw speed 450 RPM via a 150 HP/100 Kw gearbox, type 50 B2N10210 EXT-KPL, Ratio 5:1, by a 150HP/100Kw400volt/50cycle/3Ph motor. Complete with control panel. Mfg. 1996. Last used in a plastic recycling application.

Stock# 48001001

Used- Berstorff 75mm Twin Screw Extruder, Model ZE75A. 4 barrel Zone electrically heated, water cooled system including pump and heat exchanger. Approximate 2.95" diameter approx. 16:1 L/D Ratio,water cooled feed throat, no hopper. Driven by a 120kW (approximate 160hp), 1800 rpm motor. Approximate 45" center line. No controls. Mounted on a carbon steel base. E0.0190/87

Stock# 49407002

Used- Werner & Pfleiderer ZSK 90 F385E Twin Screw Extruder. 32:1 L/D. Co-rotating, 8 housing sections, electrically heated, water cooled. Max screw speed is 300 rpm via a gearbox by a 447 hp/298Kw-1440 rpm-380volt/50cycle/3Ph motor. Screw torque 3850 Nm. Includes support frame, control panel and further infrastructure. No side feeder included. New year 1991. Previously used in a Masterbatch application.

Stock# 49596001

Used- Werner & Pfleiderer ZSK 92 Twin Screw Extruder. 36:1 L/D. Co-rotating, 9 housing sections, electrically heated, water cooled. Max screw speed is 400 rpm via a gearbox by a 525 hp/350Kw motor. Includes support frame. Includes (3) Brabender loss in weight feeding system consisting of (2) Brabender pellet loss in weight feeder for up to 2200lbs/hr (1000kg/hr). (1) Brabender liquid loss in weight feeder for up to 44 lbs/hr (20kg/hr). (1) Gneuss screen changer, (1)Werner & Pfleiderer watering pelletizer, type WRG 200 including pellet dewatering and drying unit (1) SOMOS pellet drier by SOMOS, (1) Pellet Classifier, (1) SWECO Sifter/Separator. (1) Control panel and further infrastructure. No side feeder included. New year 1997. Previously used in a Masterbatch application.

Stock# 10147004

Used- Werner & Pfleiderer Double Screw Extruder, Type ZSK-170 W-1750 5G, Serial No. 221 071, new 1986, screw diameter 170 mm (7"), screw length 2500 mm (100"), L/D 14.7, co-rotating, electric heating on housing no. 2, 3, 4 and 5, 65.8 kW (88 hp), DC motor 760 kW (1013 hp), 6000 volt, screw speed 198 rpm, without switchgear, used on DMD, floor space 14.0 x 4.0m (46' x 13'), weight 21.000 kg (23 tons), with sieve changer SWZ-1200 oval plus hydraulic unit, 2.2 KW (3hp), 500 volt, with "Wasserringgranulierung", motor 15 kW (20 hp).

Stock# 42275038

Used- Twin Screw Waste Material Processor, PE PP PS EPS ABS Mixed Plastics, RDF, Organic Waste. Only 200 worked hours automatic process. Dries up and agglomerates material at a rate of 300-500 kg/h. Can be used for a variety of applications as RDF, briquettes, wood plastic compounds or just to agglomerate moist plastics for further pelletizing. Average power consumption 0,14 kw/kg. Steel loading bunker feeding done by 2 augers with adjustable speed iron steel shaking board for adjusting material flow body of the machine made by steel boards lined with anti-wear material. Gearbox agglomerating process is performed by twin screws 300 mm diameter. Main engine 90 kw, Siemens PLC, inverter, touch screen control board. Automatic process, no need for full-time operator PES 300 is designed to operate under heavy loads, so all components are manufactured for strength and sturdiness. Operating forces are well balanced and the main drive motor is generously oversized in order to maintain the production rates even in the presence of more difficult material. Under normal conditions, the motor runs at only about 60% of its maximum capacity. The PLC control system monitors several parameters continuously, including electrical power consumption and temperature of the extruded material. This machine is offered with reconditioning performed in our workshop.Reported to be reconditioned.

Stock# 10749087

Used- Werner Pfleiderer Twin Screw Extruder; Model ZSK 300. 8 barrel sections, 164 rpm screw speed, single speed gearbox. Motor: 5000 hp, 1190 rpm, 4000 volts, 37,244 lbs. estimated weight. Diverter valve: 120 mm diameter, 110 =% travel, 100 % divert. Screen changer: Model #SWZ-1900. Basket Type, 1,900 CM2 area. Die plate: 2.4 mm hole diameter, oil heating, 54-4003 pelletizer: meg by W&P, underwater type, 100 hp, 900 prm (variable). 30-254003 main motor. 30-254003.5 aux motor. 30-448 pelletizer motor. SWZ1900 screen changer. 5' x 3' 5" feed hopper. Mfg. 1986.

Stock# 42275037

Used- Twin Screw Waste Material Processor, PE PP PS EPS ABS Mixed Plastics, RDF, Organic Waste. Automatic process, dries up and agglomerates material at a rate of 1000/2500 kg/h. Can be used for a variety of applications as RDF, briquettes, wood plastic compounds or to agglomerate moist plastics for further pelletizing. Average output above 2000 kg/hr. Average power consumption 260 kw/h 0,12 kw/kg. Type PES 600-M 400 steel loading bunker mm.1004x3000x1400 feeding done by 2 augers diameter 400 mm with adjustable speed Iron steel shaking board for adjusting material flow body of the machine made by steel boards lined with anti-wear material gearbox agglomerating process is performed by twin screws 600 mm diameter. Main engine 400 kw, 6 poles Siemens PLC, inverter, touch screen control board. Dimensions: 5100 wide x 2500 long x 3410 high mm. Automatic process, no need for full-time operator PES 600 is designed to operate under heavy loads, so all components are manufactured for strength and sturdiness. Operating forces are well balanced, and the main drive motor is generously oversized in order to maintain the production rates even in the presence of more difficult material. Under normal conditions, the motor runs at only about 60% of its maximum capacity. The PLC control system monitors several parameters continuously, including electrical power consumption and temperature of the extruded material, so that operation can be adjusted accordingly. Reported to be reconditioned.
