Used Plastics Grinders & Plastics Granulators

Stock# 46523001

Used- Size Reduction Specialists (FBE) Corp., Bi-Cutter Screenless Granulator, Model SR1517, Carbon Steel. Cutting chamber is 15" wide x 17" long. Cutter size 8 mm (.35") x 10 mm (.39"). Approximate 35 to 65 throughput per hour. Stage 1 cutter 18 rpm, stage 2 cutter 60 rpm. Driven by 2 hp (1.5 kW), 3/60/208-230/460 volt gear motor, 20 to 1 ratio. Has custom hopper, set up for blower discharge (no blower). Includes control panel with Allen Bradley PLC. Mounted on carbon steel frame with casters. Serial# 140454-3. Built 2003.

Stock# 45288018

Used- AEC Nelmor AK Series Auger Fed Granulator, Model AK68. Carbon Steel. Approximate 7-1/2" wide x 6" diameter (3) bolt on blade open rotor. Approximate 6" diameter x 32" long screw feed with enclosed tube. Includes a feed hopper, bottom catch box, set up for blower discharge with a 1hp blower, approximate 5/16" diameter screen, and controls. Screw driven by a 1hp gear motor, blades driven by a 5hp, 3/60/230/460 volt, 1755 rpm motor. Mounted on a cast carbon steel base with casters. Serial# 00E03908.

Stock# 10147133

Used-Dreher Type S 26-41 Granulator. Rotor width 16.1" (410 mm). Rotor diameter 10.2" (260 mm). (3) Rotor knives. (2) Stator knves. Roll feeding. Variable speed drive. Motor 7 hp (5.5 kW). 380V/50 hz.

Stock# 45282005

Used- Cumberland Sheet Grinder, Model 1628X. Approximate 16" x 28" feed throat with hopper. (3) Blot on blade open rotor. Includes a screen and an approximate 20hp motor.

Stock# 46877001

Used- Seishin Enterprise Orient Cutter Type Mill, Model VM-32, Carbon Steel. Approximately 7-1/2" wide x 12" diameter 3 bolt on blade closed rotor. Driven by an approximate 10hp motor. Includes a tilt back feed hopper, (4) bed knives, approximately 3/8" diameter screen holes. Bottom discharge with drawer. Mounted on a base with casters.

Stock# 47737002

Used- Wor-tex Granulator, Model UP-755, Carbon Steel. Approximately trough-put up to 1000 pounds per hour (depending on type of material). (4) 30" Wide bolt-on blades, (2) bed knives. Star roll design infeed driven by 1 hp, 3/60/230 volt. Tilt back hopper approximately 7" x 36". 3/8" Diameter screen holes. Driven by a 10 hp, 3/60/230 volt. Set up for airveyor discharge, blower size WB1212, driven by a 3 hp, 3/60/230/460 volt, 3495 rpm motor. Serial# 2875. Built 1987.

Stock# 49215001

Used- Wortex Granulator, Model UP-755, Carbon Steel. Approximate maximum through-put 1,000 pounds per hour. 5" x 55" Long feed throat with (2) approximate 4" diameter feed rolls driven by a 1-1/2" HP, 3/60/208-230/460 volt, 1740 rpm motor with 30:1 gearbox ratio. (4) 30" wide off set bolt on blades, closed rotor, (2) bed knives. Driven by a 10 HP, 3/60/230/460 volt, 1170 rpm motor. 1/4" diameter screen holes. Set up for blower discharge, driven by a 5hp, 3/60/230/460 volt, 3480 rpm motor. Mounted on a carbon steel base with casters. Built 1982.

Stock# 49215002

Used- Wortex Granulator, Model UP-755-D, Carbon Steel. Approximate maximum through-put 1,000 pounds per hour. 5" x 55" Long feed throat with (2) approximate 4" diameter feed rolls driven by a 1-1/2" HP, 3/60/208-230/460 volt, 1740 rpm motor with 30:1 gearbox ratio. (4) 30" Wide off set bolt on blades size L-30-755-D, closed rotor, (2) bed knives. Driven by a 10 HP, 3/60/230/460 volt, 1170 rpm motor. 3/8" Diameter screen holes. Set up for blower discharge, driven by a 5hp, 3/60/460 volt, 3505 rpm motor. Mounted on a carbon steel frame with casters. Serial# D100-902, Built 1981.

Stock# 47827004

Used- RML Commander Grinder, Model TS1-SH-16--316-20. Staggered blade rotor. Driven by a 20hp, 3/60/575 volt, 1170 rpm motor. Set up for blower discharge, includes 5hp blower. Approximate 3/8" diameter screen. Mounted on a carbon steel frame. Serial# 22-16-688, built 1988.

Stock# 73071

Used- Rapid Granulator, Model 1224K. 12" Diameter x 24" wide 3 bolt on slanted blade open rotor, 2 bed knives. Pelican style feed hopper, bottom discharge drawer. Approximate 1/4" diameter screen holes. Driven by a 25 hp motor.

Stock# 49599001

Used- Hosokawa Alpine Mill, Model UPZ500. Series LFH257725005. 30 HP Motor, 460 Volt.

Stock# 49599002

Used- Hosokawa Alpine Mill, Model UPZ500. Series LFH257725006 / 37566.1. 30 HP Motor, 460 Volt.

Stock# 49599003

Used- Hosokawa Alpine Mill, Model UPZ500. Series LFH257725007 / 37566.2. 30 HP Motor, 460 Volt.

Stock# 49599004

Used- Hosokawa Alpine Mill, Model UPZ500. Series LFH257725007 / 37566.3. 30 HP Motor, 460 Volt.

Stock# 49599005

Used- Hosokawa Alpine Mill, Model UP500. Series LFH257725007 / 37566.4. 30 HP Motor, 460 Volt.

Stock# 44496015

Used- Sprout Waldron Granulator, 15" x 18" feed. 30 Hp motor. Previously used for recycling polyester film edge trim.

Stock# 44496016

Used- Sprout Waldron Granulator, 15" x 18" feed. 30 Hp motor. Previously used for recycling polyester film edge trim.

Stock# 44496018

Used- Sprout Waldron Granulator, 15" x 18" feed. 30 Hp motor. Previously used for recycling polyester film edge trim.

Stock# 45282011

Used- Nelmor Granulator, Model G1628. Approximately 16" x 28" feed throat, 3 bolt-on blade closed rotor. Bolt-on feed hopper, ratchet open. Approximately 3/4" diameter screen holes. Mounted on a frame. Requires an Approximate 40hp motor. Serial# 9605-38091.

Stock# 45282012

Used- Nelmor Granulator. Approximately 19" x 28" feed throat, 3 bolt-on blade closed rotor. No hopper. Approximately 3/4" diameter screen holes. Driven by a 40hp, 3/60/230/460 volt, 1765 rpm motor. Mounted on a frame.

Stock# 88471

Used- Hydro Claim Dual Chamber Film Grinder. Approximately 12" x 18" primary feed. Bolt on blades with an open rotor. Driven by a 40 hp motor.

Stock# 48660001

Used- Rapid Granulator, Model 1831K, Carbon Steel. 3 Knife open rotor, 2 bed knife, newer style tangential cast cutting chamber. Approximate 18" x 31" feed throat. Approximately 5/16" diameter holes screen. Belt Driven by approximate 40 hp, 3/60/230/460 volt motor. Includes insulated tray feed hopper and body panels. 6" OK160 Left hand airveyor discharge. Serial# 70.344. Built 1990.

Stock# 46227001

Used- Tria Granulator, Carbon Steel. Approximate 20" x 26" feed throat with a bolt on feed hopper. Approximate (4) rows bolt on blades, open rotor, set up for bottom blower discharge with a 2.2kw blower. Granulator driven by a 37kw (50hp), 3/50/380-415 volt, 1450 rpm motor. Approximate 7/16" diameter screen holes. Mounted on a frame. Includes a sound enclosure. No manufacturers tag.

Stock# 40857004

Used- Cumberland Granulator Model 28B, 18 x 28" cutting chamber, 3 knife, steep angle open rotor (requires blades). 28" x 21" top feed hopper, bottom discharge with 3/8'' screen holes. Driven by a 50 hp, 3/60/208-230/460 volt, 1765 rpm motor. Mounted on legs. No tag.

Stock# 45902001

Used- Tria Granulator, Type 80-49/DN-SL, Carbon Steel. Approximate 33" (840mm) x 19" (490mm) feed opening. Cutting capacity 400 to 800 kg/hr (880 to 1760 lbs/hr) depending on product. Approximate 17" (450mm) diameter 3-blade open rotor, requires knives, has (2) bed knives. Driven by a 55kw (82.5hp), 3/50/380-415/660-720 volt, 1450 rpm/66kw (99hp), 3/60/460/790 volt, 1450 rpm motor. Approximate 1/2" (13mm) diameter screen holes. Includes sound enclosure, and hopper. Serial# 33204175, built 2004.

Stock# 47560005

Used- Cumberland Granulator, Model 37. Approximate 18" x 37" feed opening with standard tray feed hopper. 3 Knife open rotor. Belt driven by an approximate 100hp motor. Serial# 50210-6616.

Stock# 47827002

Used- Nelmor Grinder, Model G1436MR. Approximate 14" x 36" feed. 3 knife closed rotor, 2 bed knives, approximate 5/16" screen-holes. Requires motor. Set up for blower discharge with 10hp blower. Serial# 77068850. Control panel Extra hopper with control panel and pull rolls.

Stock# 44496008

Used Cumberland Model 18X37 Granulator. 18" X 37" Feed Throat. 5-Knife Steep Angle Step Adjustable Rotor Knives (10 Segments). 2- Bed Knives. Designed for Film Granulation. Belt Driven by a 100 HP, 460 Volt, 1780 RPM Motor. Gravity Discharge. 6" Diameter x 37" Wide Knurled and Grooved Offset Position Feed Roll Infeed with Pneumatic Pinch. Feed Roll Infeed Trumpet, Feed Rolls are Chain and Sprocket Driven by a 7.5 HP, 1750/1930 RPM Continuous Duty, DC Motor Thru a Reliance 2.76/1 Gearbox. All Mounted on Leg Base. Swing Out Chamber Door on Downstroke Side. Starter and Controls are not included.

Stock# 10755029

Used-Condux Model OS650/200III-A Granulator. 2 x 8" x 80" feed openings, 7 knife beam support rotor, (5) 15.5" segments each knife, tear type bed knives, 150 hp, 480 volt motor, hydraulically opened cutting chamber, 2 pc 1.5" holes screen, Airveyor discharge, film feed hopper, starter and controls not included. 1986 model year.

Stock# 45282013

Used- Tria FN Series Granulator, Model 120-80 FN. Approximate 31.4" x 48.8" feed throat with a bolt on feed hopper. Approximate 27.5" diameter cutting circle with (5) rows of (2) bolt on 1-1/4" thick blades, open rotor, bottom discharge. Driven by an approximate 150 hp motor. Approximate 1" diameter screen holes, approximate 2204-4409 pounds an hour throughput. Mounted on a base. Includes a 24" wide x 224" long belt conveyor, driven by a 2 hp, 3/60/208-230/460 volt, 1725 rpm gear motor. Serial# 8-1427-6.

Stock# 48212003

Used- Cumberland X-Series Granulator, Model X1400. Approximate 24" x 56" feed throat, 5 knife twin shear / high shear rotor, 2 bed knife, belt driven by a Lincoln 150 hp, 3/60/460 volt, 1780 rpm motor with a 445t frame, 167 maximum amps. Approximate 14" OD airveyor discharge, mounted on plate base, conveyor in-feed hopper with new 2 hp electronic jack tilt back assist and a motorized drop down screen cradle, needs new screens, starter and controls for granulator and electronic jack assemblies is not included. Serial# 48250-94002. Built 1994.

Stock# 49153001

Used- Cumberland X Series Granulator, Type X 1400, Carbon Steel. Approximate 24" x 56" (615 mm x 1400 mm) throat size. Maximum throughput depending on material 3,500 pounds per hour. Open (3) bolt-on rotor knives and 2 bed knives. Approximate rotor speed 620 RPM. Driven by a 165 HP/110 kW, 3/50/380 volt, 1480 rpm motor. Blower discharge. Motorized tilt, driven by a 2 hp, 1/50/115 volt, 1725 rpm gear motor. Approximate 1/2" diameter screen size installed. Customer closed top infeed cover with (2) 8" diameter openings. Includes screw conveyor, approximate 8-1/2" diameter x 12' long screw, 7-1/2" flight, driven by a 2.2 kW, 3/50/290/500 volt, 1410 rpm gear motor, top discharge 10-1/2" diameter. 4 kW blower for discharge. Control panel. Serial # 48280-96010. Built 1996. Previous used on PVC.

Stock# 45617001

Used- Cumberland "Hog" Granulator, Model 50-H GRAN. 18KN. Approximate 20 x 50 feed throat with bolt on hopper. (18) Carbon steel blade helical hog solid rotor, (2) bed knives. Approximate throughput 4000 pounds per hour. Approximate 1/2" diameter screen holes. Driven by a 200 hp, 3/60/460 volt, 1190 rpm motor. Set up for blower discharge with a Sterling blower, driven by a 15 hp, 3/60/208-230/460 volt, 3505 rpm motor. Cumberland Serial # 551000-805.

Stock# 10755121

Used- CUMBERLAND MODEL C1400 GRANULATOR, S/N 53320-14001, 18? X 56? FEED THROAT, 5 KNIFE TWIN SHEAR / HIGH SHEAR ROTOR, 2 BED KNIFE (OFF SET), 200 HP 460 VOLT 1190 RPM MOTOR, BELT DRIVEN ROTOR WITH DUAL FLY WHEELS, HYDRAULIC ASSISTED HOPPER TILT BACK AND SCREEN CRADLE VIA 1.5 HP HYDRAULIC SYSTEM, 10? RIGHT HAND AIRVEYOR DISCHARGE, MOUNTED TO PLATE, STARTER / CONTROLS NOT INCLUDED.

Stock# 10288034

Used-Mitts & Merrill Hog Grinder, 300 hp, 15" x 27" feed opening, 18 knives. Discharge screen has .44" diameter holes. Equipped with outboard roller bearings. Motor 3/60/460V, 1180 rpm direct coupled. Size 6 motor starter and Square D disconnect.

Stock# 44496013

Used- Cumberland Granulator, 20” x 72”, (5) knife open rotor. Direct connected to a 300 hp, 460 volt, 1185 rpm motor. Serial #66300-791, built 1979.

Stock# 44496003

Used- Pallmann Horizontal Ram Fed Granulator, Model PSR16-12. Material chamber approximately 45” wide x 120” long with hydraulic ram feed for assisting feeding of low bolt density material into side feed rotor. (11) Knife rotor, approximately 300 hp motor. Includes operator control panel.

Stock# 44496014

CUMBERLAND MODEL 20X72-5KN GRANULATOR, S/N 66300-91002, 20" X 72" FEED THROAT, 5 KNIFE STEEP ANGLE STEP ADJUSTABLE KNIFE ROTOR (10 SEGMENTS), 2 BED KNIFE, 2 AUXILIARY BED KNIVES, 1 TEAR BED KNIFE, DESIGNED FOR FILM GRANULATION AND FILM BLOW IN IN-FEED, DIRECTLY DRIVEN BY DUAL 200 HP 1190 RPM 460 VOLT ONLY MOTORS, 18" AIRVEYOR DISCHARGE, APPROXIMATELY 3/8" HOLES CLOSE FITTING SCREENS, DOES NOT INCLUDE STARTER/CONTROLS OR BLOW IN IN- FEED HOPPER, REBUILT IN 2004
