Unused - Krauss Maffei Horizontal Injection Molding Machine
Unused - Krauss Maffei Horizontal Injection Molding Machine, 1760 Tons, Model 1600-17200 MX. 1760 Ton Clamp Force. 17200 plasticizing size. Approximate 241.97 oz. (6.86 kg) shot size. Platens approximate 100.3937" x 82.67717", Distance between tie bars 73.6" x 55.9", Mold opening stroke 13.39", Maximum daylight 133.85", 7 heating zones, 135mm screw diameter, 10mm nozzle radius, 4mm nozzle bore, 460 volt/60Hz . Includes: MC6 Control, PV-closed loop control for injection unit, hydraulic-mechanical 2 platen clamping system. (4) locking devices and (4) pressure pads. Wedge type anti-vibration pads; Shim plates; Horizontal stops for fixing machine; Electric screw motor; Blue Power-Servo pump drive; Steel hopper; Cylindrical valve type shut-off nozzle HSVS; Pneumatic valves on moving and fixed platens for blow function; Pneumatic cascade control; Maintenance unit for treatment of oil-free compressed air; Hydraulic cascade control; Electric interface on fixed platen; Mold fixing platens; Mechanical robot interface; Mechanical preparation for future retrofitting of a mechanical progressive drop-in bar; Hydraulically actuated ejector plate; Hydraulic operated safety gate; Tie bar retraction system; Internal oil filtration; Level sensor for oil drip tray; Increased oil cooler; Pressure gauge; Pressure accumulator; Hydraulic core pull system on moving and fixed platens; Hydraulic ejector and cores on moving platen; Twin pressure check valves for hydraulic core pulls; Extended parallel movements of injection unit; Cooling water connections; 2 Additional circles; Cold slug ejection; Control cabinet cooling fan; TN-C/TN-C-S/TN-S power supply capability; Separate heat and power circuit connections; Additional temperature zone for nozzle heater; Data logbook; Stabilized power supply unit; Quality monitoring package; Cycle time recording/analysis; TFT color screen; Graph displays; Automatic maintenance alerts; PV-closed loop control; 110 and 220V outlets; Electronic coding
