Used Continuous Compounding Equipment

Stock# 11499021

Used- Berstorff / Gala 40mm Twin Screw Pelletizing Line. 43.7mm Barrel Bore Diameter, 37mm Center Distance, 51:1 L/D Ratio, Water Cooled, 8 Barrel Segments, With Vent, Side Port With Screw Feeder, 110 KW Siemens AC Motor and Drive, Direct Drive To Flender Gear Box, 1,200 Maximum rpm. 530 NM Maximum Torque Per Shaft, Gala MB 500 Pelletizing System. Including, Spin Dryer, Model 1200, Water System With Plate and Frame Heat Exchanger, Immersion Heater. Comes With Gala CBF, Continuous Band Filtration Designed for Continuous Separation of Fines. 24" Vibrating Screener and Vibrating Spiral Conveyor Vibra Schultheis, Model WFT 6.3/3-12.5DV. Controlled By Integrated Siemens PLC Previously Running TPE/TPV, Mfg. 2001. Does Not Include Gala Polymer Diverter Valve.

Stock# 41757016

Used- Berstorff Compounding Line, Model 60R x 24D UTX. 600-800 kg/hour, 24:1 L/D, 2 x 69.1mm screw, 68 AC kW Motor, Segmented Screws and Cylinder, Co-Rotational, Screw speed 400 rpm, Venting, Busch Vacuum Pump, Sidefeeder, ZSFE 65, Metal Separator, Noise protection hood, ECON hot face cutter KBM ELG 1000, Siemens Controls S7 with HMI. Mfg. 2016.

Stock# 50515002

Used- Buss Ko-Kneader Extruder, Model TCS 100-16 D. 100mm (3.93") Diameter heated screw, 16 to 1 L/D ratio. Approximate 57-1/4" centerline height. (6) Jacketed barrel sections, side feeder, also has top center port. Screw driven by a 125 hp, 3/60/460 volt, 1785 rpm AC motor. Has (4) Regloplas P160 temperature controllers. Serial # 452126-1, Sales Order # 96/4521. Includes cooling conveyor, belt approximate 39-3/8" wide x 18 long, (2) cored rolls 8" diameter & 16" diameter, Netzsch-Condux small granulator at the end of the cooling conveyor. Has Vac-U-Max Bulk collection system with Roots Model 33 U-RAI rotary lobe blower, (4) Sterling Model M2B2010-D temperature controllers, Sterling Model GRT45-5-4 pump tank. Operators panel with Siemens/Moore PLC, (6) Door control panel with ABB ACS 600 main drive, ABB ACS 300 feeder drive, Square D Telemecanique Altivar 18 drive granulator drive.

Stock# 42314001

Used- Draiswerke Inc Gelimat Thermokinetic Mixing/Compounding Machine, Model G-100S, 316 Stainless Steel. Nominal volume 100 liter, batch size 70 pounds. Jacketed clamshell design chamber, cored mixing paddle. Top feed, bottom discharge with door. Includes 1000hp, 4160 volt, 1195 rpm, XP motor, control panel with safetronics. Base mounted.
