Used 0-499 Gallon Stainless Steel Kettles

Stock# 53876002

Used XFD Dual Tilting Kettle/Popcorn Maker, Model DX-1000. 36" diameter x 16" depth kettle interior; Stainless steel construction; Bottom scrape agitation; Hydraulic tilt discharge; Top mounted agitation drive motor on each kettle. OAD: 131" W x 67" D x 108" H. 2 HP agitation motor. 3/60/380V.

Stock# 11059338

Used Lee 5 Gallon (20L) Jacketed Dual Motion Vacuum rated Mixing Kettle. Internal Rated 15 PSI/Full Vacuum. Jacket rated 90 PSI @ 332 Deg.F, MDMT -20F @ 90 PSI. Drawings and manuals on file. EST DIMS: 40x70x66.

Stock# 53043001

Used Groen Table Top Kettle, Model TDH-40, 40 Quart Capacity, Stainless Steel. Approximate 16-1/2" diameter x 14" deep. Self-contained steam jacketed unit with natural gas heated steam source contained within unit. Input rated 52,000 btu / hr. 2/3 bottom jacket rate 50 psi at 300 degrees F. Manual tilting with pour lip. Mounted on a base. National Board# 12100, Serial# 1988-10.

Stock# 53043002

Used Groen Model TDH-40 Table Top Kettle, 40 Quart Capacity, Stainless Steel. Approximate 16-1/2" diameter x 14" deep. Self-contained steam jacketed unit with natural gas heated steam source contained within unit. Input rated 52,000 btu / hr. 2/3 bottom jacket rate 50 psi at 300 degrees F. Manual tilting with pour lip. Mounted on a base. National Board# 13816, Serial# 1989-4. 1/60/110 Volt.

Stock# 53043004

Used Groen Stainless Steel Table Top Kettle, Model TDH/40-SP, 40 Quart Capacity. Approximate 16-1/2" diameter x 14" deep. Self-contained steam jacketed unit with natural gas heated steam source contained within unit. Input rated 52,000 btu / hr. 2/3 bottom jacket rate 50 psi at 300 degrees F. Manual tilting with pour lip. Mounted on a base. National Board# 32385, Serial# 32385. 1/60/110 Volt.

Stock# 53844001

Used Groen Model DN/TA-10 Industrial Jacketed Vacuum Kettle with Mixer, 10 Gallon, 316 Stainless Steel. Dished clamp-on top, Hemispherical bottom. Approximate 16" diameter. Internal rated 15psi / vacuum. Jacket rated 45 psi at 300 degrees F. Top enter Groen TA scraper agitator. includes Dart Controls Mixer Speed Controller, temperature gauge, pressure gauge. Manual Tilting, pouring lip. Mounted on legs with casters. National Board# / Serial# 131790. Power Requirements: 120VAC.

Stock# 53043003

Used Groen 40 Quart Capacity Table Top Kettle, Model TDH-40, Stainless Steel. Approximate 16-1/2" diameter x 14" deep. Self-contained steam jacketed unit with natural gas heated steam source contained within unit. Input rated 52,000 btu / hr. 2/3 bottom jacket rate 50 psi at 300 degrees F. Manual tilting with pour lip. Mounted on a base. National Board# 29964, Serial# 29964. 1/60/110 Volt.

Stock# 50757001

Used Gifford-Wood AGI-Mixer, Model V/P-A, Consisting of: (1) J.C. Pardo & Sons Vacuum Kettle, 40 Gallon, 316 Stainless Steel. Approximate 26" diameter x approximate 26" deep. Lift out clamp on domed top cover, hemispherical bottom. Internal rated 15 psi or full vacuum at 250 degrees F. 304 Stainless steel jacket rated 40 psi at 287 degrees F. Tilt out agitator bridge with inner bar agitator and an anchor style scrapper agitator. (1) Gifford Wood homogenizer mixer, all set up for hydraulic drive. 2" Center bottom outlet. Mounted on (4) legs. Serial# 4402, National Board# 2158. Includes an operator panel, control panel, 0.75hp circulation pump and a Watlow electric heater. Mounted on a common carbon steel base.

Stock# 53920001

Used Lee Industries Model D7S 50 Gallon Mix Kettle, Stainless Steel, Vertical. 316 Stainless steel vessel. Flat top, hemispherical bottom. Steam jacket on hemispherical bottom rated 125 psi at -20 to 353 degrees F. Top stainless steel bridge with top entering anchor style agitator with scraper blades. Center bottom outlet. Mounted on 3 legs. National Board# 5673, Serial# B8508A.

Stock# 53356001

Used Flowtam Sanitary Process Equipment Kettle, Model GJC-020P, 52.8 Gallon (200L) working capacity. 304 Stainless Steel. Vertical. Approximately 36" diameter x 24" straight Side. Clamp on dish top, hemispherical bottom. Jacketed. Anchor style agitator with scrapers, driven by a 1.5kw (2hp), 1/60/220 volt, 1720rpm motor through reducer, 1:75 ratio. Openings Top: 8" manway with cover, 7.5" for agitator, 3" with sight glass, 2", (2) 1-1/2", 1-1/4", 2" bottom off center outlet, with approximately 16" discharge height. Manual Tilt, (1) spray ball. Includes Greerco vacuum pump, and Control Panel. Serial# 01704191, built 2017.

Stock# 53356002

Used Flowtam Sanitary Process Equipment Model GJC-020P Kettle, 200 Liter (52.8 Gallon) Working Capacity, 304 Stainless Steel, Vertical. Approximately 36" diameter x 24" straight Side. Clamp on dish top, hemispherical bottom. Jacketed. Anchor style agitator with scrapers, driven by a 1.5kw (2hp), 1/60/220 volt, 1720rpm gear motor, 1:75 ratio. Openings Top: 8" manway with cover, 7.5" for agitator, 3" with sight glass, 2", (2) 1-1/2", 1-1/4", 2" bottom off center outlet, with approximately 16" discharge height. Manual Tilt, (1) spray ball. Includes Greerco vacuum pump, and Control Panel. Serial# 01704192, built 2017.

Stock# 52905001

Used Groen Model DTA-3-60 SP Twin 60 Gallon Kettles with Twin Pivoting Agitator. National Board stamped jackets rated 45 PSI @ 300 Deg F. Stainless steel common frame, rinse faucet. Elec: 3/60/230/460V.

Stock# 52720010

Used Lee Floor Mounted 75 Gallon Dual Motion Tilt Back Agitator Assembly, Model 9M, 316 Stainless Steel. Approximate 30" wide anchor style agitator. Inner bars 11" x 1.5" wide x 5/16" thick. Outer bars 11.5" x 1.5" x 5/16" thick. Driven by a 2hp, 3/60/230/460 volt, 1725 rpm XP motor, thru dodge gearbox. Has tilt mounted stainless steel frame. Serial# 17378-2.

Stock# 51240002

Used Ross Mix Kettle, Model 361-100. Approximately 125 Gallon, Stainless Steel, Vertical. Approximate 35" diameter x 30" straight side, flat top and bottom. Bolt on cover with hinged access panel. Jacket with no rating. Carbon Steel agitator bridge with top mounted double motion drive. 3 tier dual blade impellers with (4) wall mounted baffles. Driven by a 10hp/7.5hp 3/50/60hz, 230/460 // 190/380volt 1760/1465 rpm motor through a reducer, 41.50:1. Approximate 6" cbo with bolt on cover. Mounted on (3) Carbon Steel legs, discharge height approximately 28". Includes Tothill Meter. No Serial #.

Stock# 51240004

Used Ross Model 361-100 Mix Kettle. Approximately 125 Gallon, Stainless Steel, Vertical. Approximate 35" diameter x 30" straight side, flat top and bottom. Bolt on cover with hinged access panel. Jacket with no rating. Carbon Steel agitator bridge with top mounted double motion drive. 3 tier dual blade impellers with (4) wall mounted baffles. Driven by a 10hp 3/60/230/460v, 1725 rpm belt driven motor through a reducer, 14-2/3:1. Approximate 6" cbo with bolt on cover. Mounted on (3) Carbon Steel legs, discharge height approximately 30". Includes a Series 800C Fill-Rite Meter. Serial# 50022

Stock# 51240005

Used Ross 125 Gallon Mix Kettle, Model 361-100, Stainless Steel, Vertical. Approximate 35" diameter x 30" straight side, flat top and bottom. Bolt on cover with hinged access panel. Jacket with no rating. Carbon Steel agitator bridge with top mounted double motion drive. 3 tier dual blade impellers with (4) wall mounted baffles. Driven by a 10hp/7.5hp 3/50/60hz, 208-230/460 // 190/380volt 1765/1470 rpm belt driven motor through a reducer, 14-2/3:1. Approximate 6" cbo with bolt on cover. Mounted on (3) Carbon Steel legs, discharge height approximately 25"". Includes a Series 800C Fill-Rite Meter. Serial# 39062-2

Stock# 51240006

Used Ross Model 361-100 125 Gallon Stainless Steel Mix Kettle, Vertical. Approximate 35" diameter x 30" straight side, flat top and bottom. Bolt on cover with hinged access panel. Jacket with no rating. Carbon Steel agitator bridge with top mounted double motion drive. 3 tier dual blade impellers with (4) wall mounted baffles. Driven by a 10hp/7.5hp 3/50/60hz, 208-230/460 // 190/380volt 1765/1470 rpm belt driven motor through a reducer, 14-2/3:1. Approximate 6" cbo with bolt on cover. Mounted on (3) Carbon Steel legs, discharge height approximately 25". Includes a Series 800C Fill-Rite Meter. Serial# 51039041

Stock# 53920002

Used Feldmeier Approximate 100 Gallon Jacketed Process Kettle, Stainless Steel, Vertical. 36" Diameter X 20" straight side. 316L vessel. Flat top, hemispherical bottom. 304 Stainless steel shell (channel) and bottom (dimple) jacket 100 psi at -20 to 350 degrees F. Top agitator bridge with top center entering Anchor style agitator with sidewall & bottom scrapers. Offset high shear Admix Rotosolver, model 112xP94. 2" Center bottom outlet. Insulation 1-1/2" chloride & asbestos free soft fiberglass (sidewall & bottom). Mounted on (3) legs. National Board# 5181, Serial# E-167-00.

Stock# 52932007

Used Groen Agitated Kettle, Model N-125 SP, Approximately 125 Gallon Capacity, 316 Stainless Steel, Vertical. Approximate 38" diameter x 34" deep. Open top, hemispherical bottom. 304 Stainless steel Jacket rated 125 psi at 353 degrees F. Top entering high shear homogenizing agitator, driven by a 3hp, 3/60/230/460 volt, 3450 rpm motor. 1-1/2" Center bottom outlet with valve, 19" discharge height. Mounted on 3 legs with casters. National Board# 68679, Serial# 1974.

Stock# 51240001

Used Mix Kettle, Approximately 125 Gallon, Stainless Steel, Vertical. Approximate 35" diameter x 30" straight side, flat top and bottom. Bolt on cover with hinged access panel. Jacket with no rating. Carbon Steel agitator bridge with top mounted double motion drive. 3 tier dual blade impellers with (4) wall mounted baffles. Driven by a 10hp/7.5hp 3/50/60hz, 230/460 / 190/380volt 1760/1465 rpm motor through a reducer, 41.50:1. Approximate 6" cbo with bolt on cover. Mounted on (3) Carbon Steel legs, discharge height approximately 29-1/2". Includes a Series 800C Fill-Rite Meter.

Stock# 53844013

Used Walker Stainless Model PZ-4 Mix Kettle / Tank, 150 Gallon, 316 Stainless Steel, Vertical. Approximate 45" diameter x 24" straight side. Dished top and slight coned bottom. Internal rated 10psi / FV at 250 degrees F. Jacket rated 75psi at 250 degrees F. Top entering anchor style agitator with sidewall and bottom scrapers, bottom supported, driven by 1.5hp, 3/60/230/460 volt, 1660 rpm gear motor, 46.11 to 1 ratio. 2" diameter x 26" long Top offset 4 blade agitator, driven by a 2hp, 3/60/230/460 volt gear motor, 7.56 to 1 ratio. Top entering baffle. Opening top: 16" manway with cover, 3-1/2", (3) 3", (2) 2" center bottom outlet, with 24-1/2" discharge height. Mounted on stainless steel frame with casters. ASME# 726, Serial# 1282, National board# 178.

Stock# 53624001

Used Hamilton Style CW Tilting Kettle, 150 Gallon, 316 Stainless Steel. Approximate 44" diameter x 40" deep. Open top, jacketed hemispherical bottom. 304 Stainless steel jacket rated 100 psi at -20 to 328 degrees F. Top entering angled anchor style agitator with scrapers, driven by a 2 hp, 3/60/208-230/460 volt, 1750 rpm gear motor, approximate 44.32 to 1 ratio (no gearbox tag). Air operated agitator tilt, motorized bowl tilt, pouring lip. 3" Center bottom outlet with valve. Mounted on a stainless steel frame with (3) leg. National Board # 17. Serial # F-4662-3. Built 2002.

Stock# 53624002

Used Hamilton Style CW Tilting Kettle, 150 Gallon, 316 Stainless Steel. Approximate 44" diameter x 40" deep. Open top, jacketed hemispherical bottom. 304 Stainless steel jacket rated 100 psi at -20 to 328 degrees F. Top entering angled anchor style agitator with scrapers (missing 1 scraper), driven by a 3 hp, 3/60/208-230/460 volt, 1750 rpm gear motor, approximate 44.32 to 1 ratio (no gearbox tag). Air operated agitator tilt, motorized bowl tilt, pouring lip. 3" Center bottom outlet with valve. Mounted on a stainless steel frame with (3) leg. National Board # 278. Serial # F-5817-2. Built 2004.

Stock# 53624003

Used Hamilton Style CW Tilting Kettle, 150 Gallon, 316 Stainless Steel. Approximate 44" diameter x 40" deep. Open top, jacketed hemispherical bottom. 304 Stainless steel jacket rated 100 psi at -20 to 328 degrees F. Top entering angled anchor style agitator with scrapers (missing 2 scraper), driven by a 2 hp, 3/60/208-230/460 volt, 1750 rpm gear motor, approximate 44.32 to 1 ratio. Air operated agitator tilt, motorized bowl tilt, pouring lip. 3" Center bottom outlet with valve. Mounted on a stainless steel frame with (3) leg. National Board # 279. Serial # F-5817-3. Built 2004.

Stock# 53621002

Used Lee Industries 200 Gallon Agitated Kettle, Model 200U7S, 316 Stainless Steel, Vertical. Approximately 36" diameter x 46" straight side. Flat top, dished bottom. 304 Stainless steel uniflow jacket rated 100 psi at -20 to 338 degrees F. Top center entering single motion anchor style agitator with scraper blades, driven by a 3hp, 3/60/230/460 volt, 1730 rpm gear motor, 59 to 1 ratio. Admix Rotostat model 100XP81, offset top entering high shear mixer, driven by 5hp, 3/60/208-230/460 volt, 3450 rpm motor. 6" Center bottom outlet with valve to 3" tri-clamp. Top entering baffle. Mounted on (3) legs. National Board# 5618, Serial# B8348A, Built 1993.

Stock# 11252214

Used Hamilton 200 Gallon Agitated Kettle, stainless steel construction with 3/4 jacket, rated for 120 PSI at 342 degrees F. Features top mounted full sweep agitator, currently less drive. Hinged lid top covers. Hemispherical bottom with 2-1/2" diameter center bottom outlet.

Stock# 52905003

Used Hamilton 200 Gallon Triple Motion Stainless Steel Kettle. 48" dia x 36" deep. Hemispherical bottom. Side/bottom scrape triple agitation with pivoting bridge. Jacket rated 125 PSI @ 345 Deg F. 5HP drive, 3/50/60/230/460V. Split stainless lids. 3" Tri-Clamp discharge fitting. Serial# 2475, National Board# A8223. Last used in food.

Stock# 53147035

Used Cherry-Burrell 200 Gallon Cone-Bottom Stainless Steel Jacketed Processor Tank with Scrape Surface Agitation. Vessel measures 48" diameter x 30" deep with bridge mount agitation, hinged lids, and 2-1/2" center bottom outlet with tri-clamp connection. Agitator is driven by 3 HP, 230/460V, 3/60 Hz, 1700 RPM motor thru right-angle gearbox with 85.65:1 ratio, resulting in 20 output RPM. Vessel includes self contained heating system for jacket with an electrically heated inline heater and small centrifugal circulation pump. Unitized on stainless steel frame with (4) legs. Serial number E-524-9. Previously used at dairy processing facility.

Stock# 53264018

Unused- Lee Industries 200 Gallon Kettle, 200 CHD9MT, 316 Stainless Steel, Scrape Agitation. Jacket rating: 90 psi @ 332 deg.f. Interior dimensions: 48'' diameter x 36'' deep. Center discharge: 2'' tri-clamp, with valve. With counter current scrape agitation. Motor: 2 hp, 575 volt, 99 output rpm, With variable speed drive. Tilt-out agitator, Tilting bowl, With two top hinged lids, With temperature probe. Kettle is on three stainless steel legs with pads. Serial# 64701-1. National board# 11992.

Stock# 11585097

Used JC Pardo Approximately 250 Gallon Triple Motion Stainless Steel Sanitary Vacuum Kettle. Internal rated 10 PSI/FV@239 Degrees F. Jacket rated 60 psi @ 330 degrees F. Triple Motion Agitation, with homogenizer head - dual motion sweep scraper agitator. Hydraulic tilt out agitation and cover. Center bottom outlet. Includes control panel. Serial# 4845. National Board Number 2269.

Stock# 11059226

Used Lee 400 Gallon Jacketed Vacuum Pan. Mix Kettle with Scrape Agitation. Model 400D7S. Sanitary Vessel Rated for Full Vacuum. Jacket Rated 90 PSI at 332 Degree F. Agitator is 3/2 HP, 230/460-190/380 Volt, 1760/1460 rpm into gear box with 18:1 ratio. National Board # 6444. Kettle is 13' OAH x 5'3" OD at the jacket. 3" CBO.
