Used Basket Top Unload Centrifuges

Stock# 50489001

Used- Western States Basket Centrifuge, Model QC-120. 30" diameter x 18" deep. Perforate basket. Top Load/Bottom unload centrifuge. Maximum speed 1450 rpm at 900 gravities. 4" top cap, 11.8' screen area, 3.4' maximum holding capacity. Full welded construction and dynamically balanced. Vertical weld in basket drum radiographed. Maximum load 255 pounds (75 pounds / foot). Constructed of 316 stainless steel. Exclusive Western states Machine Company Drive featuring A-C Variable Frequency Inverter in a NEMA 1 enclosure, complete with a Siemens PE-21, 20 hp. Class 1 Group "D" Division 2 high efficiency motor for 460 VAC, 3 Phase, 60 Hertz. CURB - All welded construction, complete with 22-3/4" I.D. flanged solids outlet and a 4" flanged tangential liquid discharge outlet. Constructed of 316 stainless steel. Feed Pipe. Unbalance Switch, Vibra Switch, Wash Pipe.

Stock# 40374002

Used-Rousselet Basket Centrifuge, type RC50PXME. Material of construction is stainless steel on product contact parts. 19.5" (500mm) diameter x 9.75" (250 mm) straight side basket. Top unload, lift out bag. Driven via a variable speed drive unit by an 8.25 hp/5.5 kW-380 volt/50 cycle/3 ph flame proofed motor, oxy/nitrogen purge. Mounted on a platform.

Stock# 63342

Used- Ellerwerk Perforated Basket Centrifuge, Type 733C. 316 Stainless steel TI construction. 20" Diameter x 16" straight side basket (500 mm dia x 400 mm st side). Top load/unload. Gas tight design. Driven by a 7.5 kw/11.25 hp 380 volt/50 cycle/3 ph/2905 rpm XP motor with air cooling fan.

Stock# 85088

Used- Tolhurst 24" x 10" Perforated Basket Centrifuge. Kynar lined product contact areas, top load/unload. Approximate maximum bowl speed 1200 rpm. Tripod suspension, top cover with sightglass. Driven by an approximate 5 hp XP motor.

Stock# 71942

Used- Ametek/Tolhurst Center-Slung 26" x 12" Perforated Basket Centrifuge, Rubber Lined (Product Contact Areas). Top load/unload, max bowl speed 1200/600 RPM, basket rated @ 96 lbs per cubic foot, tripod suspension system, PVC feed pipe, rinse pipe with nozzles. Top cover with inspection door and sightglass. Driven by a 2 HP, 3/60/440 Volt, 1700 RPM XP motor.

Stock# 62090

USED: Ellerwerk vertical basket centrifuge, type 734. 316 stainless steel construction (V4A). Belt driven by a 33 hp/22 kw-380 volt/50cycle/3 ph XP motor turning the basket with 2300 rpm.

Stock# 11059021

Used-Tolhurst Ametek 30" Basket/Batch Rubber Lined Center-Slung Centrifuge, Model 1-B-1. Perforated basket, top load/unload, basket speed 500/1000 rpm, max bulk density 70 lbs/cubic foot, 3/1.5 hp, 480V, 1720/850 rpm drive.

Stock# 11059027

Used-Sanborn Basket/Batch Type Centrifuge, Model 40, 40" x 20". Stainless steel contact parts, top load/unload, perforated basket, max speed 850 rpm, temp 150 deg F, max bulk density 85 lbs/cubic foot, explosion proof, 5 hp, 440V, 1120 rpm, XP controls.

Stock# 63340

Used- Heine/Ellerwerk Perforated Basket Centrifuge. 316 stainless steel construction, 40" diameter x 16" deep (1000 mm dia x 400 mm deep) basket. Top load/unload design. Gas tight design. Pneumatically operated liftable half top cover. Maximum basket speed 1000 rpm.

Stock# 63343

USED: Heine perforated basket centrifuge. 316 stainless steel TI construction. 40" diameter x 25" straight side (1000 mm dia x 630 mm st side). Top load/unload. Half top cover liftable. Gas tight design. Max basket speed 1200 rpm.Temp sensor. 19.5" diameter (500 mm) feed pipe. Driven by a hydraulic power pack.

Stock# 62095

USED: Kraus Maffei/Ellerwerk vertical basket centrifuge, type ZE640- PZ-IO-1200. 316 stainless steel (VA1.4571) construction. 46.8" diameter x 23.4" straight side (1200 mm dia x 600 mm st side). Max basket speed 1000 rpm.

Stock# 62093

USED: Alfa Laval vertical basket centrifuge, type PAZ12506. 316 stainless steel construction. 48.7" diameter x 23.4 straight side (1250 mm dia x 600 mm st side) basket. Max basket speed 950 rpm. Max filling 880 lbs (400 kilos product).

Stock# 62094

USED: Alfa Laval vertical basket centrifuge, type PAZ12506. 316 stainless steel construction. 48.7" diameter x 23.4 straight side (1250 mm dia x 600 mm st side) basket. Max basket speed 950 rpm. Max filling 880 lbs (400 kilos product).

Stock# 69318

Used- ATM DeLavla 48" x 20" Perforated Basket Centrifuge, Stainless Steel Construction (product contact areas). Top load, top unload, tri-pod suspension system, top cover with inspection door, feed pipe, rinse pipe, 10 hp drive motor, manual brake.

Stock# 69321

Used- ATM DeLaval 48" x 20" Perforated Basket Centrifuge, Stainless Steel Construction (product contact areas). Top load, top unload, tri-pod suspension system, top cover with inspection door, feed pipe, rinse pipe, 10 hp drive motor, manual brake.
