Used Basket Bottom Dump Centrifuges

Stock# 10151307

Used- Ametek/Ketema Mark III 48" x 30" Deep 316 Stainless Steel Basket Bottom Dump Centrifuge. Sanitary design. 30 hp hydraulic drive. Includes control panel.

Stock# 11453397

Used- Western States 30" x 18" Perforated Basket Centrifuge, Model Q-120. 316 product contact surfaces, top load, bottom unload, maximum bowl speed 1450 rpm. Basket rated at 80# / cubic foot, pneumatic full length plow assembly (missing actuator cylinder), tri-pod suspension, 25 hp XP drive motor (460/3/60), VFD controller, controls.

Stock# 13048020

Reconditioned- Sanborn 60 x 30 Perforate Basket Centrifuge, 316 stainless steel construction (product contact areas), maximum bowl speed 900 rpm, 20 cubic feet cake solids capacity, tri-pod suspension system, vapor-tite inspection door, full length single motion plow assembly, cake detector, feed pipe, rinse pipe. (New) perforated basket electric drive, and control system package, to operate a Sanborn 60 X 30 Basket Centrifuge. It is understood that the machine will operate in a Class 1, Division 1, Group D environment. The system control panel will be placed in a non-classified area, away from the actual process area. A local XP control station, will be provided for placement near the machine. Also a multiple, Pneumatic valve, and pressure switch interface in an XP enclosure will be furnished to directly actuate the pneumatic cylinders and receive limit switch signals from the centrifuge. The centrifuge will be furnished with a 50 hp, 1200RPM, Class 1 Division 1 electric motor, line regenerative variable frequency inverter, and graphic interface PLC control system. The power and logic enclosure will contain a power disconnect, variable frequency drive, and PLC logic components. Additionally, the enclosure will house a graphic "Touch Screen", and operators controls. A second enclosure in XP construction, will be provided to house the pneumatic control valves and limit switch interface. An Allen-Bradley "Control Logix", PLC will be utilized for machine cycle control and monitoring. Reported to be reconditioned.

Stock# 50001003

Used- US Centrifuge M412 Solid Wall Basket Centrifuge, Carbon Steel. Hinged top cover with feed pipe, bottom driven with motor. Includes a sludge tank with (2) Wilden diaphragm pumps and a control panel with an Emerson Commander SK drive. Mounted on a common frame.

Stock# 50035001

Used Ametek 40" Batch-Master Basket Centrifuge. Titanium product contact surfaces, 304/316 stainless steel non-contact surfaces. 40" diameter x 20" deep perforated basket, top load, bottom unload, Titanium clad case, curb and cover, rated 85 pounds per cubic foot. Multi-actuation plow discharge, feed and rinse pipes, 1080 RPM, tripod suspension, hydraulically driven with 30hp, oil gear pump, 230/460 volt XP motor.

Stock# 43719001

Used- Kokusan 26" x 12" Solid Bowl Basket Centrifuge. 304 Stainless steel construction (product contact areas). Maximum bowl speed 2600 rpm (2300 x "G" force), top load, bottom unload, tri-pod suspension system, double motion plow assembly, skimmer assembly, feed pipe, top cover with inspection door, spindle bearing lubrication system, 11kw main drive motor 220/3/60. Includes a control panel and stand.

Stock# 50489001

Used- Western States Basket Centrifuge, Model QC-120. 30" diameter x 18" deep. Perforate basket. Top Load/Bottom unload centrifuge. Maximum speed 1450 rpm at 900 gravities. 4" top cap, 11.8' screen area, 3.4' maximum holding capacity. Full welded construction and dynamically balanced. Vertical weld in basket drum radiographed. Maximum load 255 pounds (75 pounds / foot). Constructed of 316 stainless steel. Exclusive Western states Machine Company Drive featuring A-C Variable Frequency Inverter in a NEMA 1 enclosure, complete with a Siemens PE-21, 20 hp. Class 1 Group "D" Division 2 high efficiency motor for 460 VAC, 3 Phase, 60 Hertz. CURB - All welded construction, complete with 22-3/4" I.D. flanged solids outlet and a 4" flanged tangential liquid discharge outlet. Constructed of 316 stainless steel. Feed Pipe. Unbalance Switch, Vibra Switch, Wash Pipe.

Stock# 61456

Used- Sharples SP-5500 Sludge-Pak Solid Bowl Basket Centrifuge, 316 Stainless Steel. Maximum bowl speed 1500, tri-pod suspension system, 40" x 24" basket, pneumatic single motion plow assembly, pneumatic skimmer assembly, 3-way skimmer valve, vibration switch, feed pipe, 40 hp oilgear hydraulic drive system, control.

Stock# 73131

Used- Tolhurst 40" x 24" Perforated Basket Centrifuge, 316 stainless steel basket, 316 stainless steel lined curb, 316 stainless steel top, top load, bottom unload, double action plow assembly, tri-pod suspension, center cone feed distributor, feed pipe, rinse pipe, hinged inspection door.

Stock# 40037028

Used- Tolhurst 40" x 24" Centerslung Batch-O-Matic Top Load, Bottom Discharge Centrifuge. Hastelloy C276 construction on product contact areas. Rated 82 lbs/cubic foot, 0 to 1180 rpm perforated basket. Lined curb, solid 316 stainless steel lid. Designed for nitrogen purge. Unit has a wash pipe, center feed, cake detector, hinged inspection cover. Tri-Pod suspension. Set up for hydraulic drive, no power pack.

Stock# 73133

Used- Tolhurst 48" x 24" Perforated Basket Centrifuge, T316L Stainless Steel Contacts. Includes rinse tube, feed tube, vibration switch, cake detector, cover switch, double action plow assembly. Basket type 316L stainless steel. No drive.

Stock# 76006

Reconditioned- Delaval ATM 48" x 30" Perforated Basket Centrifuge. 316 Stainless steel construction (product contact areas). Maximum bowl speed 1150 rpm top load, bottom unload. 16 cubic feet basket solids holding capacity, tri-pod suspension system, full length single motion plow assembly with replaceable blade, feed pipe, rinse pipe, top cover with inspection door. (Motor not included. Motor can be provided at additional cost).

Stock# 69324

Used- Western States 48" x 30" Perforated Basket Centrifuge, Hastelloy C276 Construction (product contact areas). Top load, bottom unload, tri-pod suspension system, max bowl speed 1200 rpm, pneumatic single motion full length plow assembly, feed pipe, rinse pipe.

Stock# 10151290

Used- Ametek/ATM 48" x 30" Mark III Perforated Basket Centrifuge. 316 stainless steel construction (product contact areas), top load, bottom unload, (missing feed and rinse pipe), single motion full length plow assembly. Tri-pod suspension system.

Stock# 10151291

Used- Ametek/ATM 48" x 30" Mark III Perforated Basket Centrifuge. 316 stainless steel construction (Product contact areas), top load, bottom unload, (missing feed and rinse pipe), single motion full length plow assembly, tri-pod suspension system,

Stock# 10151292

Used- Ametek/Tolhurst 48" x 30" Perforated Basket Centrifuge. Hastelloy construction (product contact areas). Max basket speed 1140 rpm, top load, bottom unload, tri-pod suspension system double motion plow assembly, center cone feed design, feed pipe, rinse pipe (PVC construction), curb housing, top cover with inspection door, Oilgear hydraulic pump with 30 hp motor.

Stock# 44635007

Used- Western States 48" X 30" Perforated Basket Centrifuge, Stainless Steel. Top load, bottom unload, single action plow discharge, tri-pod suspension on base. No motor or power pack.

Stock# 47919

Used- Sharples Model SP6500 Sludge Pak 48'' X 30'' Perforated Basket Centrifuge. 316 stainless steel construction (product contact areas). Top load, bottom unload. Pneumatically actuated plow assembly. Bottom driven with a 40 hp hydraulic motor.

Stock# 48460

Used- Escher Wyss Ploughing Centrifuge Type V-130 with Stainless Steel Nitrogen Purged Bowl 1,250mm Dia X 600mm Deep with Hydraulic Plough Centrifuge and Drive Motor 30 kW. Hydromatic Drive with Rexroth Hydraulic Pneumatic Sequence Controls. 950 rpm. Made in 1977.

Stock# 49891001

Used- Sharples 48" x 30" Perforated Basket Centrifuge, stainless steel. Maximum bowl speed 1150 rpm, top load, bottom dump, tri-pod suspension system, single motion full length plow assembly, feed pipe, rinse pipe, curb housing, top cover with inspection door, hydraulic drive motor with overhung load adapter. (Missing triangle base frame can be provided for $5200.00).

Stock# 13140007

Used-Tolhurst Semi-Batch-O-Matic 48" x 24" Perforated Basket Centrifuge. Hastelloy wetted parts. Bottom dump design. Driven by a 30 hp explosion proof motor thru oil gear hydraulic drive. Hydraulic 316 stainless steel plow discharge assembly and cover interlock. Basket speed 0-1080 rpm.

Stock# 40037012

Used- ATM 48" x 30" Perforated Basket Centrifuge.Top load, bottom discharge centrifuge. Hastelloy C276 construction on product contact areas. Lined curb and lid. Designed for nitrogen purge. Unit has a wash pipe, feed pipe, cake detector, hinged inspection cover. Tri-Pod suspension. Set up for hydraulic drive, no power pack.

Stock# 40037014

Used- ATM 48" x 30" Perforated Basket Centrifuge.Top load, bottom discharge centrifuge. Hastelloy C276 construction on product contact areas. Approximate 1080 basket rpm, lined curb and lid. Designed for nitrogen purge. Unit has a pneumatic full length single motion plow, wash pipe, feed pipe, cake detector, hinged inspection cover. Tri-Pod suspension. Set up for hydraulic drive, no power pack.

Stock# 50370001

Used- Sharples 48" x 30" Perforated Basket Basket Centrifuge. Stainless steel (product contact areas), top load, bottom dump, single motion full length plow assembly with "Air-knife", tri-pod suspension, base, curb housing, top cover with hinged inspection door w/window, feed pipe, rinse pipe, cake detector, 75 hp drive motor (460/3/60).

Stock# 50370002

Used- Sharples 48" x 30" Perforated Basket Basket Centrifuge. Stainless steel (product contact areas), top load, bottom dump, single motion full length plow assembly with "Air-knife", tri-pod suspension, base, curb housing, top cover with hinged inspection door w/window, feed pipe, rinse pipe, cake detector, 75 hp drive motor (460/3/60).

Stock# 50370003

Used- Sharples 48" x 30" Perforated Basket Basket Centrifuge. Stainless steel (product contact areas), top load, bottom dump, single motion full length plow assembly with "Air-knife", tri-pod suspension, base, curb housing, top cover with hinged inspection door w/window, feed pipe, rinse pipe, cake detector, 75 hp drive motor (460/3/60).

Stock# 50370004

Used- Sharples 48" x 30" Perforated Basket Centrifuge. Stainless steel (product contact areas), top load, bottom dump, single motion full length plow assembly with "Air-knife", tri-pod suspension, base, curb housing, top cover with hinged inspection door w/window, feed pipe, rinse pipe, cake detector, 75 hp drive motor (460/3/60).

Stock# 50370005

Used- Sharples 48" x 30" Perforated Basket Basket Centrifuge. Stainless steel (product contact areas), top load, bottom dump, single motion full length plow assembly with "Air-knife", tri-pod suspension, base, curb housing, top cover with hinged inspection door w/window, feed pipe, rinse pipe, cake detector, 75 hp drive motor (460/3/60).

Stock# 50370006

Used-Sharples Basket Centrifuge, Stainless steel, 48" diameter x 30" straight side, Perforate Basket, Top load, Bottom Dump. No drive.
