Robots

Stock# 51800001

Used-Turbo Spray Duel Zone Robotic Liquid Application Cell; 80' Chain On Edge System; MCC and Touch Screen Interface: NEMA 2 Enclosure; AB503 Processor; Motor Starter and VFD; Remote Sensor and Fiber Optic Part Detect; Fluid and Air Delivery: Fluid Pressure; Fan Air; Atomization Air; Robotics: Staubli RX60 with Valpaint Software; Teach Pendant; Interfaced with PLC; Ovens: Flash/Pass 1 250 degrees F Maximum; 50 kW Electric Heaters; Filtered Recirculation; Reported to be Reconditioned.

Stock# 53227001

Used- Motoman 6-Axis Robot Arm, Type ES200N with NX100 Controller. 200kg (440.92 lbs) payload; 2651 MM (104.37 in) reach; NS4.51.00A(JP/US-00) Software version. Built 2008.

Stock# 71895009

Used- Fanuc 4-Axis Palletizing Articulating Robot, Model M-410iB/700 with Control System. Is rated for up to 700kg payloads. Has a maximum reach of 3143 mm. Has up to 4-Axes of manipulation. Includes Fanuc R-30iB Plus control system. Built 2021. 3/60/480V.

Stock# 72110002

Used- Fanuc 4-Axis Articulating Robot, Model M-410ic/500. Has up to 500kg payload capacity and up to 3143 mm of reach. Includes stand and end of arm tooling. Last used in palletizing operation. Has Fanuc controller. 3/60/460V.

Stock# 72110003

Used- Fanuc 4-Axis Articulating Robot, Model M-410ic/500. Has up to 500kg payload capacity and up to 3143 mm of reach. Includes stand and end of arm tooling. Last used in palletizing operation. Has Fanuc controller. 3/60/460V.

Stock# 72110004

Used- Fanuc 4-Axis Articulating Robot, Model M-410ic/500. Has up to 500kg payload capacity and up to 3143 mm of reach. Includes stand and end of arm tooling. Last used in palletizing operation. Has Fanuc controller. 3/60/460V.

Stock# 72110005

Used- Fanuc 4-Axis Articulating Robot, Model M-410ic/500. Has up to 500kg payload capacity and up to 3143 mm of reach. Includes stand and end of arm tooling. Last used in palletizing operation. Has Fanuc controller. 3/60/460V.

Stock# 71895006

Used- Yushin American Cartesian-Style "Take-Out" Robot, Model YCII-150S-15-9.5. Is rated for a maximum payload of 5kg with a variable clamping force of 80-300tf. Has a maximum traverse stroke of 1500mm, kick stroke of 625mm and a vertical stroke of 800mm. Last used in plastics operation. Built 2021. 1/60/230V.

Stock# 71895007

Used- Yushin American Cartesian-Style "Take-Out" Robot, Model YCII-150S-15-9.5. Is rated for a maximum payload of 5kg with a variable clamping force of 80-300tf. Has a maximum traverse stroke of 1500mm, kick stroke of 625mm and a vertical stroke of 800mm. Last used in plastics operation. Built 2021. 1/60/230V.

Stock# 73238001

Used- Yaskawa 6-Axis Articulating Robot with Large Format Conveyor System, Model MOTOMAN MH180. Has a maximum payload capacity of 180 kg. Has a motion range of up to 2702 mm and has 6-axes of manipulation. Uses Yaskawa's DX200 control system and learning pendant. 3/60/480V.

Stock# 71895008

Used- Fanuc 4-Axis Delta Robot With Controller, Model M1iA/0.5S. Is rated for up to 0.5 kg load (at wrists). Up to 4-axis of control with a maximum reach of 280mm and 720 degrees of motion. Includes Fanuc learning pendant and R30iB Controller. Built 2015. 1/60/200-230V.

Stock# 73218001

Used- Fanuc M-900iA/350 w/ R-30iA Control System and Learning Pendant. Uses HandlingTool Ver 7.3 software. Capable of up to 770 lbs payload with a horizontal reach of up to 104.3in. Up to 6-axes of motion. 3/60/480V.

Stock# 73218002

Used- Fanuc Articulating 6-Axis Robot, Model M-200iD/7L. Rated for up to a 7kg payload with a horizontal reach up to 911mm. Includes Fanuc i-Pendant controller, and Fanuc R-30iB control system. Has appx 1800 running hours. Built 2018. 3/60/230V.

Stock# 70057002

Used- Fanuc 6-Axes Articulating Robot, Model R-2000iB/250F. Has a 2655mm (approx. 104.5") maximum reach and a maximum wrist load capacity of 250kg (550lbs). Servo driven. Includes Fanuc R-30iB CPU controller and learning pendant. Built 2015. 3/5/60/480V.

Stock# 71544001

Used- Set of (2) Fanuc LR Mate 100iB Robots. Payload 3 kg each. Reach 620mm. 5 Axes. Fanuc controllers. Serial# R05334502 & R05634S51. Tag# E-19891.

Stock# 71895004

Used- Melton Welding Robot, Model "Robotic Weld Cell." Features Oscillating head and adaptive torch guaging. Includes protective guarding. 3/60/480V.

Stock# 72751001

Unused - Milacron M-5X-25 Servo Robot; 120-450 Ton; 1500 - 6000mm Horizontal Stroke; 1200mm Vertical Stroke; 700mm Demold Stroke- Traverse Layout; Maximum Load 10 kg; Visual 3 Controls. Built 2016, but never put into production.

Stock# 73069001

Used-ABB Articulated 6-Axis Welding Robot, Model IRB 1600. Robot can handle up to 7kgs of tooling with full 360 degree manipulation of 6-axiis. Integrated Lincoln Wolf Welder, Cool arc water cooler, Wire feeder, Torch Cleaner, and ABB R300 positioner controls. Appx 1000 kWa at max speed. Floor mounted. EEC Compliant. 3/60/480V. Last used in welding operation.
