Used Inline Piston Fillers

Stock# 70480001

Used- Cozzoli Model LF840-8 Inline Continuous Motion Walking Beam Style Piston Filler. Machine is capable of speeds from 40 to 120 containers per minute. Container size range: diameter 7/8" - 4" or 22mm to 102mm, height up to 12" or 305mm. Maximum fill size range: 600cc (with changeparts). Currently set up with 355cc pistons pumps. Has 3/8" diameter nozzles, Utilizes flighted table top chain conveyor designed for container in puck handling. And was last used on lotions. OAD 180" long X 48" wide X 82" high.3/60/230V

Stock# 70480003

Used- Cozzoli Model LF840-8 Inline Continuous Motion Walking Beam Style Piston Filler. Machine is capable of speeds from 40 to 120 containers per minute. Container size range: diameter 7/8" - 4" or 22mm to 102mm, height max up to 12" or 305mm. Maximum fill size range 600cc (with changeparts). Currently set up with 355cc piston pumps. Has 3/8" diameter nozzles, Utilizes flighted table top chain conveyor designed for container in puck handling. And was last used on cosmetics lotions. 3/60/480 V

Stock# 70480006

Used- Cozzoli Model LF840-8 Inline Continuous Motion Walking Beam Style Piston Filler. Machine is capable of speeds from 40 to 120 containers per minute. Container size range: diameter 7/8" - 4" or 22mm to 102mm, height max up to 12" or 305mm. Maximum fill size range 600cc (with changeparts). Currently set up with 60cc pistons. 3/60/230V. Has 3/8" diameter nozzles, Utilizes flighted table top chain conveyor designed for container in puck handling. And was last used on lotions.

Stock# 70480012

Used- Cozzoli Model LF840-8 Inline Continuous Motion Walking Beam Style Piston Filler. Machine is capable of speeds from 40 to 120 containers per minute. Container size range: diameter 7/8" - 4" or 22mm to 102mm, height max up to 12" or 305mm. Maximum fill size range 600cc (with change parts). Currently set up with 250cc piston pumps. 3/60/230V. Has 3/8" diameter nozzles, Utilizes flighted table top chain conveyor designed for container in puck handling. And was last used on lotions.

Stock# 70480015

Used- Cozzoli Model LF840-8 Inline Continuous Motion Walking Beam Style Piston Filler. Capable of speeds from 40 to 120 containers per minute. Container size range: diameter 7/8" - 4" or 22mm to 102mm, height max up to 12" or 305mm. Maximum fill size range 600cc (with changeparts). Currently set up with 260cc pistons. 3/60/230V. Has 3/8" diameter nozzles, Utilizes flighted table top chain conveyor designed for container in puck handling. And was last used on lotions.

Stock# 71267004

Used- Cozzoli Model VR-840-8 Inline Piston Filler. Machine is capable of speeds from 40 to 120 containers per minute. Has a container size range of: 7/8" - 4" (diameter - or 22mm to 102mm); up to 12" (height - or 305mm). Currently set up with 120cc pistons (4 oz) fitted with 'O-Rings'. Has a maximum fill size range of 600cc (with proper change-parts). Has 3/8" (diameter) nozzles with air operated positive shut off valves, diving nozzles & pin indexing system. Last used in pharmaceutical application. 1/60/208V. Does not include controls, machine does not run.

Stock# 71424001

Used- IWKA Hassia Model SWB-021820 TLR Dosing Filler. Machine is capable of dispensing up to a 60cc fill of soft paste product from a jacketed product hopper. Fed by a servo driven piston through a 0.5" diameter product nozzle, C.I.P. capable. Last used with Multivac Rollstock Thermometer. Uses an Indel AG PLC Mounted on Casters. 6 amps. 3/60/400V.

Stock# 71458008

Used- Holmatic Single Head Piston Filler. Stainless steel contact parts. Equipped with a 3" diameter x 15" length piston with an approximate volume of 97.48 ounces. Pneumatically operated. For mounting on a main packaging machine or line.

Stock# 70675001

Used- Orics Model VF-ND-3200 Volumetric Piston Filler. Dual piston pump heads, XX fill range, rated at speeds up to 50 fills per minute. Semi-automatic pneumatic operation with foot switch control. Has 2 x 1 Gallon, 5" diameter x 12" long pistons with 3" diameter fill nozzles. Designed for hopper (not included) or pipeline product feed using tri-clamp connections. Has stainless steel contact parts and mounted on casters. 10 Cfm @ 90 psi.

Stock# 71047003

Used- PackWest Model 8BPF-RF-P-SW-RL Inline Piston Filler. 8 pistons, 22 oz capacity (2" inside diameter piston with a 13" stroke)

Stock# 71747009

Used- Pack West Model 6BPF-QT-RF-RL-CT (6)-Head Inline Piston Filler. Currently set up with 32 oz piston pumps for 8oz-32 oz fill range Is capable of handling up to 2.5 gallon F" style bottles with piston pump change. Right to left operation and last doing edible oils in salad dressing operation. 0.75" Nozzle Diameters, set up on adjustable centers. 5" wide Conveyor. Positive Shutoff Nozzles. Drip Tray. Neck Guides. 20 Amps. 3/60/208/240V.

Stock# 71796002

Used- Simplex Model AS200 Twin Piston Filler and Accumulation Tables. Capable of speeds from 5 to 15 cycles per minute (speeds dependent on materials, application and machine configuration). Fill volume range: up to 8.9 oz. Equipped with 4-1/2" wide x 120" long stainless steel Delrin indexing conveyor. Has 1/2" diameter nozzles with positive cut off. Includes std stainless steel product hopper plus 2 smaller 6 gallon hoppers for small batch runs, and includes rotary feed table and rotary accumulation table for pack off. 1/2 hp, 3/60/480V. Filler OAD: 124" long x 55" wide x 85" high.
