Used Other Complete Packaging Lines

Stock# 73100001

Used Can Filling Line 3 The line is set to run a 154 mm can. Will do 154 cans at 60/min. Infeed (Outside critical hygiene) 1. Vacuum Transfer 2. Shifter filler in feed. 3. Lid / Can UV sterlizer Filling Room (Critical Hygiene) 1. Spoon drop 2. Boekels check weigher 3. Colby 8-head filler 4. Angelus clinching seamer Gassing Oven 5. Cap inserter Packing (Outside Critical Hygiene) 1. Kawasaki Palletizing Robot 2. Anritsu check weigher with the kick-off post-case packer

Stock# 73100002

Used CAN FILLING LINE 1 SPECIFICATION 1. The line is set at 198 mm cans (approximately 90 cans / minute) 2. The line can be fed by 25 kg bags or bins; running bins last 3 years. 3. The line is comprised of the following equipment. A. Infeed (outside critical hygiene) 1. Kawasaki depalletizing robot, model ZX130L, & associated conveyors 2. 2 X Busch vacuum pump Type: RA 0305 D 502 QOBC 3. Denphase transfer system 4. Busch vacuum pump SB 0530 D OHO UJ XX B. Infeed (inside hygiene area) 1. Infeed to Bin Tipper, Bin Tipper, Outfeed from Bin Tipper. 2. KOR Centreline unit (Kraft Outer Bag remover) 3. HBD unit (Hygienic Bag Disposal) 4. Nu Con sifter that feeds down to filler in the filling room below 5. Vacutrans unit & 2 vacuum pumps C. Filling Room (critical hygiene) 1. Spoon insert/detection system 2. Mateer 4 head filler. 3. Mettler Toledo Garvens GmbH auto weigher, type C 3350, year 2019 4. John Heine cincher unit Model: 201D series 1 S/N: 22 5. a gassing oven that is using a CO2/Nitrogen blend. 6. John Heine post-gas seamer, Model 201 D Series 1, S/N 21 Can Cleaning Unit 7. Sartorious check weigher type: EWK 1000PLUS / WS 3 kg. 8. Del Packing Inc Reclosure inserter. Model: IVCL S/N 930184 (soft plastic lid) D. Packing (outside critical hygiene) 1. Invopac IWS 2007 4187 Case packer Includes all connecting conveyors and some services. The plant will be supplied and packed into your containers.

Stock# 73375001

Used Multivac R535 Thermoforming Line for Medical Device, Syriiges or Swab Sticks. Like New Condition. Line consists of the following: (2) Shibuya Hoppmann Centrifugal Bowl Feeder. Stainless steel construction with operator startion, JR Automation Orienting and Feeding System,. Consists of: infeeds from (2) Shubuya-Hoppmann Centrifugal Bowl Feeders, Model FT-50, (2) Stainless Steel Operator Platforms, (1) Rexroth Active Mover System with billet trays, (1) Fanuc SR-6iA Robot with touch pad controller, (1) Fanuc SR-12iA with touch pad controller, and (1) Allen Bradley Control Cabinet with Integrated Vision System. Has pneumatic actuators, and right-angle feed orientation. Multivac Horizontal Thermoformer, Model R-535. Features (1) Donaldson Static Eliminator and Dust Collector with Simco "Neutro-Vac" web cleaning system. Has dual web arbors, stainless steel construction, Multivac I 420 Inspection system, and dual scrap rewind. Multivac controls, Glen Dimplex chiller, Multivac Robotic Case Packer, Model H130. Stainless steel construction. Has SCARA-type robotic arm with pneumatic pick-n-place packing head. Includes U-shaped flexlink conveyor. Lantech C-2000 case erector with bottom taper feeds cases into the robotic loader, Lantech Case Sealer, Model CS-300. Has Lantech top-tape applicator, ProMAch ID Technology Print and Apply Labeler, Model ZE500. Bayonette-style mounting with casters and leveling legs. Utilizes Zebra Technologies print head. Pearson Packaging Systems Robotic Palletizing System, Model O. Consists od (1) Integrated TGW powered roller conveyor, (1) Pallet magazine, (1) Fanuc Robot model M-710iC50H, (1) Lot of safety fencing with light safety doors, (1) Fanuc R-30iB Plus control system with Soft-Touch operator pad. 3/60/480V. Line was set up for test swabs and had limited production. The price will be in addition to an 18% buyer's premium. The customer is responsible for removal. Located in Portland, TN.

Stock# 72419001

Used Paper Converting Machine Company Barry-Wehmiller Wet Wipes Complete System. Exfoliating facial cleansing wet wipe system. Marlin Flex cross folder, Model CF01-00013, unwinder, heated embossing unit, wetting applicator, Allen Bradley panelview 1500p, Sterling water chiller, SS single wall tank, 36" diameter x 36" straight side, Cleveland agitator, 20" diameter manway, CIP spray ball, 2 hp SS centrifugal pump with AB powerflex40, Multi-conveyor 90 degree conveyor, white plastic interlock belt, 8" wide x 36" tall, overall 48" long x 36" wide, SS frame, washdown motor, Multi conveyor compression conveyor, white vinyl belt, 60" long x 8" wide x 36" tall, SS frame, washdown motor and drive; Allen Bradley Controls; Cut speed: 2000 wipes per minute; Stacker speed: 100 stacks per minute (25 stacks per minute per lane); Stack count range: 4-100; Stack height range 10 mm (0.39") to 90 mm (3.54"); Cutoff length range: 170 mm (6.69") to 210 mm (8.26") maximum Folded width range: 50 mm (1.97") to 115 mm (4.5"), (change parts required for 65 mm to 90 mm folded width); 480V, 60 Hz, 3 phase; Maximum Undwind Roll width: 860 mm (34"); Maximum unwind roll diameter: 1500 mm (60"); Parent roll core diameter: 171 mm (6.75"). Includes Bosch Linium model 611 Horizontal wrapper and integrated conveyor. Film registration. Last running embossed wet wipes with 75% alcohol content.

Stock# 72544001

Used New in 2020! Teknoweb Model Exide Dual Lane Wet Wipes Forming, Cutting, Stacking and Wrapping Line. Dual lane unit capable of speeds up to 1600 wipes per minute. Capable of single and double Z folding on the same unit. Stack height range: 5mm - 60mm. Count range: 5 wipes to 150 wipes. Folded length range: 75m - 110mm. Folded width range: 50mm - 100mm. Lotion rate: 200% - 300%. All servo driven unit. Lane width range: 150mm - 210mm. Include Teknoweb Model Gensispack Basic Horizontal flow wrapper with film print registration. Has two labelers with hot swap Etipak strong 100. Dual independent stack feeding conveyors, Long dwell transversal sealing head. Like new condition and immediately available!

Stock# 73209002

Used WeighPack Systems High Speed Jar/Bottle Filling Line. System includes a Primo Combi 14 Head Combination Scale with 0.5L buckets, vibratory feeder, support stand, 8'L x 6"w indexing conveyor, 48" diameter bottle infeed table. Weighpack (Paxiom) Valtara chuck capper capable of speeds up to 30 caps per minute. Includes cap sorter. Cap range: 20mm - 105mm (with changeparts). Max container height: up to 200mm. Weighpack Valtara wraparound pressure sensitive labeler. Label size range: 10mm - 140mm (width) x 10mm - 300mm (length). Includes Weighpack Induction cap sealer. Cap range: 20mm - 100mm with Siemens touch controls. Also available a model V-25 electronic track counter for bottles. 1/60/230V.

Stock# 72444001

Used PPE Face Mask Converting and Wrapping Line. Line consists of assembly line that takes nonwoven material into folder where is sandwiches three layers of material together, and ultrasonically welds the material together, transfers masks to two earloop machines where the strings are ultrasonically welded onto masks. Masks are then transferred and stacked in variable counts into (2) horizontal flow wrappers. Last running a 5 count stack. System was purchased new in 2020. Equipment was manufacturer nu Henan Zhengyang Machinery.
