Kettles
Stock No.:
53023001Pre-Owned APV Crepaco 600-Gallon Vertical Kettle – 304 Stainless Steel
Used- APV Crepaco Stainless Steel Jacketed Kettle, Approximate 600 Gallon, 304 Stainless Steel, Vertical. Approximate 66" diameter x 35" straight side. Dished top, cone bottom. Jacket rated for 315 degrees at 75 PSI, refrigerant side jacket rated for 100 degrees at 150 PSI. Vessel rated for 15 PSI. Opening top: 18" manhole. Removable top entering baffle. Serial# 20173, National Board# 2492-DUPL.
MFR: APV/Crepaco
Stock No.:
52720010Used Lee 75-Gallon Tilt-Back Dual Motion Agitator – 316 SS, XP Motor, Industrial Mixer
Used- Lee Floor Mounted 75 Gallon Dual Motion Tilt Back Agitator Assembly, Model 9M, 316 Stainless Steel. Approximate 30" wide anchor style agitator. Inner bars 11" x 1.5" wide x 5/16" thick. Outer bars 11.5" x 1.5" x 5/16" thick. Driven by a 2hp, 3/60/230/460 volt, 1725 rpm XP motor, thru dodge gearbox. Has tilt mounted stainless steel frame. Serial# 17378-2.
MFR: Lee Ind
Stock No.:
54296006Used Walker 800 Gallon Stainless Steel Jacketed Processor Kettle – Anchor Agitat
Used Walker Model PZ-CB-SP vertical 800-gallon processor kettle fabricated from 304L stainless steel, designed for heating, cooling, and mixing viscous products in food, dairy, cosmetic, pharmaceutical, and chemical applications. Vessel measures approximately 58" diameter x 72" straight side with a dished top and slight cone bottom. Atmospheric-rated vessel with a 304 stainless steel jacket rated 50 PSI (-20F to 300F) providing approximately 64 sq. ft. of heat transfer surface. Equipped with a top-entering anchor-style scrape agitator driven by a 5 HP, 3/60/460 volt motor through a 97.89:1 gear reducer for slow-speed, high-torque mixing and efficient wall scraping. Features a 20" manway, 16" x 12" top opening, multiple process nozzles, 4" center bottom outlet with approximately 24" discharge height, 1-1/2" side outlet, and is mounted on (3) stainless steel legs. Serial #8210, National Board #3136, built 1994.
MFR: Walker
