Used Cryogenic Tanks and Used Gases Tanks

Stock# 53364001

Used- Process Engineering Inc Cryogenic Storage Tank, 50,000 Gallon, Horizontal. For LOX/ Liquid oxygen or nitrogen. Approximately 10' 5.375" diameter x 86' 2.6875" straight side. Elliptical 2:1 heads. Internal rated 76 psi at -320 to 100 degrees F. Openings: 3.5" bottom fill, 4.5" vent & safety, 3.5" top fill, 4.5" liquid withdraw, 4.5" dip tube withdraw, 3.5" P.B. vapor return. Saddle mounted.

Stock# 53364002

Used- Process Engineering Inc Cryogenic Storage Tank, 50,000 Gallon, Horizontal. For LOX/ Liquid oxygen or oxygen. Approximately 10' 5.375" diameter x 86' 2.6875" straight side. Elliptical 2:1 heads. Internal rated 76 psi at -320 to 100 degrees F. Openings: 3.5" bottom fill, 4.5" vent & safety, 3.5" top fill, 4.5" liquid withdraw, 4.5" dip tube withdraw, 3.5" P.B. vapor return. Saddle mounted.

Stock# 53364003

Used- Union Carbide Corp Cryogenic Storage Tank, 30,000 Gallon, Horizontal. For LOX, liquid oxygen. Approximate 104" diameter x 67' 6" straight side. Elliptical 2:1 heads. Internal rated 76 psi at -320 to 100 degrees F. Saddle mounted.

Stock# 53364004

Used- Union Carbide Corp Cryogenic Storage Tank, 30,000 Gallon, Horizontal. For LOX, liquid oxygen. Approximate 104" diameter x 67' 6" straight side. Elliptical 2:1 heads. Internal rated 76 psi at -320 to 100 degrees F. Saddle mounted.

Stock# 53364005

Used-Cryogenic Storage Tank for LOX, 1,800 Gallon. Vertical.

Stock# 53364006

Used-Cryogenic Storage Tank for LOX, 1,800 Gallon. Vertical.

Stock# 53164001

Used- Pittsburgh Tank Corp. 42,000 Gallon Ammonia Storage Tank, Carbon Steel, Horizontal. Approximate 132" diameter x 684" straight side. Dished ends. Internal design pressure 15 psi at -20 to 110 degrees F., design vacuum -0.5 psi. Side Ladder with top platform. Openings top: 24" manway, various different nozzles. 6" Bottom outlet. Mounted on (3) saddles. Built 2002.

Stock# 53164002

Used- Pittsburgh Tank Corp. 42,000 Gallon Ammonia Storage Tank, Carbon Steel, Horizontal. Approximate 132" diameter x 684" straight side. Dished ends. Internal design pressure 15 psi at -20 to 110 degrees F., design vacuum -0.5 psi. Side Ladder with top platform. Openings top: 24" manway, various different nozzles. 6" Bottom outlet. Mounted on (3) saddles.

Stock# 53164003

Used- Pittsburgh Tank Corp. 42,000 Gallon Ammonia Storage Tank, Carbon Steel, Horizontal. Approximate 132" diameter x 684" straight side. Dished ends. Internal design pressure 15 psi at -20 to 110 degrees F., design vacuum -0.5 psi. Side Ladder with top platform. Openings top: 24" manway, various different nozzles. 6" Bottom outlet. Mounted on (3) saddles.

Stock# 53164004

Used- Pittsburgh Tank Corp. 42,000 Gallon Ammonia Storage Tank, Carbon Steel, Horizontal. Approximate 132" diameter x 684" straight side. Dished ends. Internal design pressure 15 psi at -20 to 110 degrees F., design vacuum -0.5 psi. Side Ladder with top platform. Openings top: 24" manway, various different nozzles. 6" Bottom outlet. Mounted on (3) saddles.
