Used Dewatering Incline Screeners

Stock# 48239002

Used- US Screen Hydratower. odel 72 Tandem Static Screen, 304 Stainless steel enclosure. 8" 150 lb. flanged inlet. 14" 150 lb. flanged discharge. Expanded feedbox, side access door. 304 stainless steel deep-arch looped wedge wire screens. .040" upper screen slot opening. .020" lower screen slot opening.

Stock# 81968

Used- Eimco Rotary Drum Concentrator, Approximately 126 Square Feet, Stainless Steel/Plastic Product Contact. 4' diameter x 8' long 7 section drum with plastic outer screen, top mounted low pressure spray bar, 4" end feed. End bottom discharge with chute. Bottom collection pan, plexiglass side covers. Drum driven by a 1.5 HP, 180 Volt, 1750 RPM DC gearmotor. Unit includes a mono Merlin open throat solids discharge pump, model CCF2M2R2, driven by a 5 HP SEW varispeed motor and 1 control panel.

Stock# 47567001

Used- Parkson Corporation Roto-Guard Rotary Drum Screener, Model 500 X 1.0M, 304 Stainless Steel. (1) Approximate 12" diameter x 20" long horizontal drum, driven by a 0.24hp, 3/60/230/460 volt, 1700 rpm gear motor, ratio 49.62 to 1. Top mounted rinse pipe with nozzles, 3" diameter side feed, 6" liquid bottom outlet, approximate 4" x 10-1/2" solids bottom outlet, top access cover. Serial# 568C, built 1994.

Stock# 47567002

Used- Parkson Corporation Roto-Guard Rotary Drum Screener, Model 500 X 1.0M, 304 Stainless Steel. (1) Approximate 12" diameter x 20" long horizontal drum, driven by a 0.24hp, 3/60/230/460 volt, 1700 rpm gear motor, ratio 69.47 to 1. Top mounted rinse pipe with nozzles, 3" diameter side feed, 6" liquid bottom outlet, approximate 4" x 10-1/2" solids bottom outlet, top access cover. Serial# 568A, built 1994.

Stock# 48168001

Used- Parkson Hycor ThickTech Rotary Drum Thickener, Model RDT 400, Stainless Steel. Capacity 400 gallons per minute, inlet flow 0.5%-1.5% solids, outlet flow 5%-8% solids, typical polymer usage 5-10 pounds / 1- ton sludge, 98% + solid capture. With flocculator and control. Mounted on a carbon steel frame. Serial# P0510042402, project# P05100424.
