Used Form and Pack Tray Formers and Packers

Stock# 71276001

Used- Arpac Model EL-2222 Intermittent Motion End-Load Tray/Case Erector and Packer. Machine is capable of speeds up to 25 trays/cases per minute. Can handle a tray size range of: 5" to 14" (length); 7" to 18" (width); 2" to 10" (height); and 1.5" to 4" (tray wall height). Can handle a case size range of: 5" to 14" (length); 9" to 18" (wide); and 4" to 8" (height). Equipped with multi-lane container infeed with pneumatic laning device (currently set to 6-lanes). 25 amp. Uses an Allen Bradley SLC 5/03 PLC controller and a Parker GV6 Gemini Servo drive. Air requirements: 20 SCFM at 80 PSI. 3/60/460V. Last running bottles of pet shampoo.

Stock# 72069001

Used- Arpac Traystar Inline, Continuous Motion Gallon Can Tray Packer. Dual lane container infeed to grouping section with flight bar feed to tray blank. Extended magazine for tray blanks. Nordson Problue tray flap gluing. Ran at 30+ trays per minute. New 2011.

Stock# 71967001

Used- EDL Offset Inline Automatic Wrapping System. Includes intermittent wrap-around tray former and high efficiency shrink tunnel. Single lane, automatically fed. Corrugate tray with bulls eye wrap. Low density polyethylene with film gauge from 1.5 to 3.0 mil. Film width up to 22". Mfg. 2016. Last used for spice containers.

Stock# 71544001

Used- IMA (BFB) Model FR100 Hooded Style Tray Former and Bottle Loader. Capable of speeds up to 60 trays per minute. Tray size range of 60mm-250mm long; 50mm-300m wide; and 30mm-150mm tall. Has Nordson Problue 7 hot melt glue system. Siemens AC2 PLC controls. Equipped with two Fanuc robotic pick and place arms. Last used in pharmaceutical solid dosage packaging operation. Includes 115" long x 8" infeed conveyor, 41" long x 8.5" discharge conveyor. 23.9 amps. 3/60/480V.

Stock# 71524002

Used- Krones Model Variopac Tray Pack Shrink Bundling System. Capable of running up to 30 cases/trays per minute, trayless or with tray option. 8 lanes with oscillating lane guides, flight bar with vertical pin pack group separation. Floor level film reels print registered film (30" maximum film web width). Floor level 25" wide x 12' long tray blank magazine, Nordson Pro-Blue hot melt glue m3D melter. Includes a Krones ST 72 Shrink Tunnel with 26" wide x 16" high x 34" deep aperture, 4 heat zones with 1 cooling zone. Uses Allen Bradley FlexLogix 5434 PLC controls with AB Panel view pendant HMI. 3/60/460V.

Stock# 72081001

Used Multivac M860F Roll Stock Thermoformer. 14.58" (374 mm) foil width. Equipped with 2 types of forms/molds. (1) Over/under mold (WZ-Nr. 71561) 12.48" (320 mm) x 12.01" (308 mm) x 5.07" (130 mm) deep mold. Packaging size 13.06" (335 mm) x 12.87" (330 mm), single row. (1) Over/under mold (WZ-Nr. 71562) 12.48" (320mm) x 12.01" (143 mm) x 5.57" (130mm) deep mold. Packaging size 13.06 (335 mm) x 6.4" (165 mm), single row. Incl. 2 roll feeders for upper and lower foil, heating device, cleaning devise, drive, infrastructure and control panel. On 6 legs. Weight 2.1 tonnes. Serial # 2168. New year 1995. Previously used in pharmaceutical industry for medical genetic testing.

Stock# 71286004

Used- Standard Knapp Continuum Tray Form and Pack, Model: Continuum, Serial Number 296-108. Capacity as used: 50 cases per minute of 16 oz 4 x 3 Pack. Largest size packed 32 oz 4 x 3 Pack. Nordson Series 3500 V Hot Melt Glue. Speed: 50, up to 70 TPM. Product Sizes: 202 diameter to 603 diameter. Products: Glass Jars, Metal and Fiber Cans. Magazine: Continuous loading vertical hopper approximate 500 blank capacity. Pack patterns: 2 x 2, 3 x 2, 4 x 3, 6 x 4. Exterior dimensions: 72'L x 86" W x 80" H.

Stock# 70037086

Used- Standard Knapp, Model 296P, Continuous Tray Packer and Shrink Wrapper. Stainless steel side rails, capable of speeds of 70 TPM. 8 Lanes wide. 25" wide film width, 1.75" - 6.25" bottle diameter range, vertical tray magazine for approximately 500 blanks for continuous loading, Nordson glue station. Skid 1-Main Machine-41' long x 8' wide x 8' tall-16,000 pound. Skid 2-Heat Tunnel-24' long x 8' wide x 8' 6" tall - 10,000 pound. Skid 3-Infeed and lane conveyors- 24' long x 8' wide x 6' tall-5,000 pound. Skid 4-Corrugate Magazine- 12' long x 8' wide x 4' tall -2,500 pound.

Stock# 70623001

Used- Standard Knapp Model 296P Continuum Tray Packer and Registered Film Shrink Wrapper. Capable of speeds up to 100 trays per minute. Five lane container infeed design, capable of expanding up to 8 lanes. 25" Wide film width. Handles containers from 1.75" up 6.25" diameter. Has 500 tray blank magazine. Has Allen Bradley SLC5/04 PLC with AB Panelview 1000. Set up for registered film, single roll technology. Last running 1 liter and 1.5 liter bottles at 60 trays per minute.

Stock# 72081002

Used- GEA Tiromat Powerpack Type 660 Roll Stock Thermoformer. 14.58" (374 mm) foil width. Equipped with molds. Includes 2 roll feeders for upper and lower foil, heating device, cleaning devise, drive, infrastructure and control panel. Stainless steel covers. On 10 legs. Serial # 671/0101-98. New year 1998. Previously used in pharmaceutical industry for medical genetic testing.

Stock# 71932012

Used- Wepackit Machinery 250 CE Auto-Bottom Carton Erector. Carton size range Minimum 3" x 3" x 3", maximum 17" x 13" x 13". 220/3/60. Serial# 250CE-2885.
