Used Pre Made Bag Horizontal Form and Fill

Stock# 71281001

Used- AB Tech Preformed Pouch Packager with Liquid Filler. Machine is capable of speeds up to 25 preformed pouches per minute. Designed for preformed pouches with pouch size range: Width of 165mm to 350mm (6.5"-13.7"); Length of 150mm to 406mm (5.9"-15.9"). Equipped with Liquid Piston filler for 10ml to 314ml fills. Has 8-rotary pouch gripping stations. Stainless steel construction. Last running approximately 200mm width x 420mm length (8" x 16-1/2") pouch with fittment in bottom and 30mm unsealed opening in top for filling and then sealing in machine. Has an Allen Bradley PanelView touchscreen HMI panel and an Allen Bradley MicroLogix 1500 PLC control system. 3/60/220V.

Stock# 72020001

Used-Bodolay Form & Fill Horizontal Pre Made Bags, Model P60

Stock# 71526001

Used- Laudenberg Model PMP20 Duplex Pre-Made Pouch Packager. Capable of speeds up to 80 pouches per minute. Currently set up for 4.5" wide x 7" tall pre-made pouches with zipper and stand-up construction. Has a pouch size range: 80mm - 130mm or 3.15" - 5.12" wide x 120mm - 350mm or 4.72" - 13.87" height. Servo driven turret, has Allen Bradley PLC 5/60 controls and Allen Bradley Panelview 1000 HMI control panel (New PLC/HMI upgrades available upon request). Has duplex powered pouch magazine feed, mechanical/pneumatic pouch and zipper opening station, fill station with funnels on 7" centers, hole punch, seal station and discharge conveyor. Last running tandem zipper stand up pouches of cat pet food treats. Does not include filler. 3/60/480V. See video of machine running on web page. Machine can be integrated with product filler, control package upgrades and set-up at additional cost subject to project. Please contact an AEK sales representative for details.

Stock# 71803001

Used- MFG Preformed Pouch Packager model XL. Accepts pouch size range 4" to 10" wide, up to 18" high, 8 station rotary design, Automation Direct DL-205 PLC with C-More HMI. Offered reconditioned, 8 week lead time. 3/60/230V

Stock# 70705003

Used- Urania Pouch Pro Model 3500 Pouch Packager. Designed and tooled for a 5.75" wide x 10" long pouch. System takes pre-made pouch, indexes to a single station indexing conveyor product loader. Loader was pushing pipette trays into bag, inserting a pouch desiccant and a prefolded leaflet, then pouch was sealed. Sealing belts made of Teflon coated fiberglass. Sealing bars tri-axial self-adjusting. Temperature range 100 degree C to 300 degree C. 304 Stainless steel and anodized 6061 aluminum construction. Machine includes (1) Azco Model SP-4D desiccant feeder capable of speeds up to 100 pouches per minute. 1/60/110V. Last used in on reagent diagnostics product.

Stock# 70988008

Used- PakSource PSG Mini PMP Liquid Pouch Filler/ Sealer. Stainless steel contact parts, piston fill, rated up to 8 pouches per minute. Can handle pouches up to 15" wide x 20" high, presently with 10" heating and sealing bars. Mounted on base with casters.

Stock# 71201001

Used- PSG Lee Model RP-8TZ-36 Premade Pouch Packager. Machine is capable of speeds from 15 - 30 pouches per minute, subject to pouch and product variables. Pouch size range: Width of 8.5" - 15" or 216mm - 381mm; Length of 13.8" - 21.7" or 350mm - 550mm. Weight Range: up to 20 pound or 10 kg. Designed for pouches with gusset, stand-up bottom, and zipper seal. Has an 8-station turret for: #1 pouch pick-up, #2 coding (coder not included), #3 zipper open, #4 pouch bottom open with pouch present detection, #5 open pouch transfer to fill station with product settler, #6 gas flush, #7 heat seal, #8 seal, quench, and discharge. Fill station can be adapted for product filler per application, last used with Ishida scale filling for PVA dry detergent pouches (scale filler not included). Uses an Allen Bradley SLC 504 PLC, Proface HMI, and Allen Bradley PowerFlex VFDs. Is of stainless steel construction with barrier guarding. 10 cfm at 90 psi. 3/60/220V. Offered in Good Running Condition, Set-up for 1 size pouch. Controls can be upgraded at an additional cost. Ask your AEK sales representative for details.

Stock# 71265006

Used- PSG Lee Model RP-8TZ-36 Premade Pouch Filler/Sealer. Speeds from 15 - 30 pouches per minute, subject to pouch and product variables. Pouch size range: 8" - 15" Width, 13.8" - 21.7" Height, Weight up to 20lb, Designed for pouches with gusset, stand-up bottom, and zipper seal. 8-station turret for: pouch pick-up, coding (coder not included), zipper open, pouch bottom open open pouch transfer to fill station with product settler, gas flush, heat seal, seal, quench, and discharge. Allen Bradley SLC 504 PLC, Proface HMI, and Allen Bradley PowerFlex VFDs. 10 cfm at 90 psi. 3/60/220V. * * * Price is AS-IS. This unit is a candidate for reconditioning * * *

Stock# 71973001

Used- PSG Lee Horizontal Pre-Made Pouch Packager, Model RP-84T/Z-36, with Coder, Lee Pack Powder Auger Filler with Bulk Feeder, and Finished Pouch Conveyor Metal Detector. Machine is capable of speeds from 15 to 40 pouches per minute, subject to pouch and product variables. Pouch size range: 6.3" - 11.4" or 160mm - 290mm (width) x 6" - 16.9" or 150mm - 430mm (height). Weight Range: up to 4 pounds or 2 kg. Designed for pouches with gusset, stand-up bottom, and zipper seal. Has an 8-station turret, extended pouch magazine, PSG-Lee Servo (Mitsubishi) auger filler. Air: 10 cfm at 90 psi. Electrical: 3/60/220V. Has Allen Bradley SLC 5/05 and Allen Bradley Panelview 600 HMI touchscreen. Machine offered in Good Running Condition. Controls can be upgraded at an additional cost. Ask your AEK sales representative for details. Last running 32 oz pouches of black pepper with zipper opening attachment.

Stock# 71912003

Used- Roberts, Model IMP-1500 Horizontal Pre Form Pouch Machine. Capable of speeds up to 50 pouches per minute (depending on application, bag size and product fill). Bag size range: 4" - 12" or 100mm - 305mm (width) x 6" - 15" or 150mm - 380mm (height) x 0" - 5" or 0mm - 125mm (gusset). Servo drive, PLC controls. Last running with Ishida scale (not included).

Stock# 71981001

Used-Toyo Jidoki Model TT9CW Preformed Pouch Machine. Capable of speeds from 30-80 pouches per minute, speeds are dependent on fill volume and pouch material. Pouch size range: Width - 80mm - 150mm or 3.15" - 5.9" , Length - 130 mm - 255 mm or 5.12" - 10.0" . Fill volume range: up to 500cc. Capable of running flat or stand up pouches, Duplex 2-up operation. Turret stations consist of: pouch pick and place into turret clips, pouch top opener, pouch bottom opener, pressure product fill with piston pump fills using 19mm diameter nozzles, two stage heat seal stations, seal quench and pouch discharge. Last used on beverage mixed cocktail products.Allen Bradley CompactLogix PLC controls, serial number A01156, mfg 2102. Requires 90 ps air and 3/60/480V.

Stock# 71981002

Used-Toyo Jidoki Model TT9CW Preformed Pouch Machine. Capable of speeds from 30-80 pouches per minute, speeds are dependent on fill volume and pouch material. Pouch size range: Width - 80mm - 150mm or 3.15" - 5.9" , Length - 130 mm - 255 mm or 5.12" - 10.0" . Fill volume range: up to 500cc. Capable of running flat or stand up pouches, Duplex 2-up operation. Turret stations consist of: pouch pick and place into turret clips, pouch top opener, pouch bottom opener, pressure product fill with piston pump fills using 19mm diameter nozzles, two stage heat seal stations, seal quench and pouch discharge. Last used on beverage mixed cocktail products.Allen Bradley CompactLogix PLC controls, serial number A01312, mfg 2102. Requires 90 ps air and 3/60/480V.

Stock# 72003001

Used- WeighPack Systems Swifty Bagger Model 3600 Preformed Pouch Packager with Triangle Combination Scale and Platform. Capable of speeds up to 45 bags per minute. Has a bag size range: 3.5" - 8" (width) x 5.5" - 20" (length). Bagger has Allen Bradley Micrologix1400PLC with and Allen Bradley Panel view 600 plus HMI. Has a 30" long discharge conveyor. Includes Triangle Selectacom 360 Model A10C8 radial dimpled bucket combination scale. Originally designed for USDA specifications. Embossed scale surfaces. Bucket volume: 512 cubic inch. Maximum volume discharge: 2560 cubic inch. Bucket opening: 8" x 8". Last filling fish products 2 lbs up to 10 lbs. Includes stainless steel mezzanine with stairs, inclined cleated belt product elevator to scale. Machine can be set to size and tooled for your application. Ask your AEK sales representative for details. Set up quotes available upon receipt of samples and project specifications.
