Used Ampoule Vial Syringe Monoblock Pharmaceutical Fillers

Stock# 71993001

Unused- Orwin Automatic Syringe Barrel Assembly System. Designed for disposable drug delivery pens. Includes the following: Automated testing mechanism to inspect pre-defined critical features of the pen assembly line. Cartridge vision system. Label print-out vision system. Label alignment vision system. Automatic Laser label printer/applicator. Close loop automated rejection systems for defective components and/or assemblies. Label rework station. In-process sampling port. Assembly Machine - Packaging Machine transfer conveyor. Built-in statistical process control system to measure machine and manufacturing metrics. Currently fitted to handle SYMLINPEN 60 and SYMLINPEN 120.

Stock# 70053008

Used-Bausch & Strobel Ampoules Filling Line consisting of: One (1) used model FAW1000 washer designed to handle 35 mm maximum diameter x 140 mm maximum height ampoules, rated up to 4000 ampoules/hour, new 1994. One (1) model AFV 2010 intermittent motion rotary ampoule filler, stainless steel contact surface, designed to handle ampoules, presently set up for 20 ml ampoules at 3000/hour, with flame sealer, 480 volt, new 1994.

Stock# 71221005

Used- Bosch (Strunck) Model ALK 3040 Pharmaceutical Ampoule Filler and Flame Sealer. Capable of speeds up to 200 ampoules per minute. 4 head flush/fill/flush and flame seal. Ampoule size range: (Diameter) 9mm - 26mm; (Height) 60mm - 160mm. Fill size range: .5ml - 25ml with change parts. Currently set up on 10ml ampoules. Equipped with a slant tray infeed to a timing helix screw, automatic star wheel feeding ampules into 4 up indexing conveyor, 4 head flush / fill /flush head, (4) 10ml piston pumps, 4 head gas sealing station, Last running in a pharmaceutical operation. Has Bosch CPU.

Stock# 71221006

Used- Bosch (Strunck) Vial Injectable Filling Line. Consists of a Bosch RUR HO4 rotary vial washer, Bosch TLQ T36 depyrogenation tunnel oven, Bosch ZSA A12.5 vial filler and stoppering machine set on on 10ml with 13mm stoppers. Has a main control panel with Bosch PLC controls. Has 4 piston pumps, 60 cpm.

Stock# 70527001

Used- Chase Logeman (Hull) Model FSS4.12 Vial Filling and Stoppering Machine. Capable of speeds from 8 - 120 vials per minute. Has a vial size range of 1mL to 125mL vials up to 15.3 cm or 6" height. Equipped with National Instrument /Filamatic Piston Pumps. Currently set up with 13mm and 20mm diameter stopper feed components..

Stock# 70053009

Used-Cozzoli Liquid Vial Filling Line, Model LFTP-10. Consists of: Calumatic vial washer, model CRW, with infeed accumulating table, rotary vial washing station, circulation pump and controls, 220 volt, Cozzoli inline vial filler, model LFTP-10, 10 head, walking beam, liquid manifold, continuous motion with conveyor and misc spares, Calumatic capper, model RS5, with feed hopper and conveyor, 1.7 kw, 200 volt, Calumatic dual station tray loader, pneumatically operated vial loader, feed conveyor with controls, mfg 1992.

Stock# 70439021

Used- Cozzoli Filler, Model F329HA Hypak Style Syringe Filler. Will fill up to 1 tub of syringes in 35 seconds. All stainless steel base. Machine is missing piston pumps, valves and all syringe change parts. Fill size range up to 30ml. Fills aqueous to light oil products. 1/60/110V

Stock# 70650002

Used- Cozzoli FPS1 Automatic Ampoule Filler and Flame Sealer. Capable of speeds up to 60 ampoules per minute. Fill size range 1cc to 30cc (subject to piston pumps and nozzle change parts). Currently equipped with 10cc piston pump and valve block Requires nozzle per application (not included). Maximum container height 5-5/16". Maximum sealing height of 4-3/4".

Stock# 70653028

Used- Groninger Filling Line Set Up for 30ml, 120ml, 250ml, 500ml, Containers. Line consists of bottle feed station, Model KFVG 4211A Groniger monoblock for filling plugging and capping, with (4) piston filling station, vibratory bowl feeders for plugs with plugs and caps, and accumulation table. Serial# 7170, mfg 2006. Also includes, Mettler Toledo Hi Speed Model Model Starweight-XSPMWD checkweigher and Groninger Model Mag 105 tray loader, Serial# 8106. Built 2008. With change parts for 30, 120, 250 and 500 Ml plastic bottles.

Stock# 70733002

Used- M&O Perry Model SFA-1 Vial Cartridge Filling Unit. Machine includes (2) tiltable cartridge feed hoppers, (2) stainless steel vibratory feeders, and a stainless steel discharge chute with pneumatic reject arm. Machine has a rotating vial inverter with pneumatic pusher. System is set up with a 6' vial conveyor. Has an integrated Yamaha VK600X High Speed Scara articulated robot. Is set up with a 3 position plunging filler station. Also had pneumatic discharge arm with stainless steel discharge system. Has product sensing, (1) IVEK Digispense 800 controller, and (1) Quickpanel Jr Total Control panel. Has all stainless steel hopper with heating coil and a Talboys labratory stirring system with liquid level sensing. Has Allen Bradley SLC 5/03 PLC controls. 1/60/230V.

Stock# 70622002

Used- TL Systems (Bosch) Model FSM-1010 Vial Filling and stoppering monoblock consisting of: Model UD-1100 TL Systems infeed rotary table, stainless steel construction, 30" diameter table with 12" x 24" feed tray, Model FSM-1010 TL Systems vial filler, walking beam filling head, 4 head filler, with 6 mL and 50 mL pumps, filler designed to handle 2/5/10/20/50 and 100 mL vials at speeds of 154/154/133/100/76 and 50 vials/minute, and stoppering with vibratory feeder bowl. Equipped with Allen Bradley SLC-5/04 plc controls, control panel with Panelview 900 touch screen, 15" diameter transfer disk to 3" wide x 64" long discharge conveyor, also set up for dual tray off is needed, serial #1252, new 1998.
