Used Spiral Heat Exchangers

Stock# 40908004

Used- Kinetics Modular Systems Spiral Heat Exchanger, approximately 22 square feet, vertical. 304L stainless steel shell rated 90/fv psi at 300 deg F and -20 deg F at 90 psi. (1) 3/4'' diameter 316L stainless steel tube on a 1 1/4'' pitch x 35 turns rated 50/105 psi at 300 deg F and -20 deg F at 50 psi. Openings: shell (2) 1'', tubes (2) 3/4''. Skirt mounted. Built 2001.

Stock# 40908005

Used- Kinetics Modular Systems Spiral Heat Exchanger, approximately 22 square feet, vertical. 304L stainless steel shell rated 90/fv psi at 300 deg F and -20 deg F at 90 psi. (1) 3/4'' diameter 316L stainless steel tube on a 1 1/4'' pitch x 35 turns rated 50/105 psi at 300 deg F and -20 deg F at 50 psi. Openings: shell (2) 1'', tubes (2) 3/4''. Skirt mounted. Built 2001.

Stock# 50388079

Used- Alfa Laval Spiral Heat Exchanger, 50 Square Feet, Model 1H-L-1T, 316 Stainless Steel. Hot and cold side rated 160 psi at -7 to 500 degrees F. (4) 2" Inlets, outlets. Serial# 25947, National Board# 18734, built 2008.

Stock# 46971109

Used- Alfa Laval Spiral Heat Exchanger, Type ALSHE-LTL-8L, Approximate 94 Square Feet, 316 Stainless Steel. Multiple ratings from -14.5/152 at -40 to 200 degrees F., -14.5/152 at 300 degrees F., -14.5/150 psi at 400 degrees F., -14.5/136 psi at 500 degrees F., -14.5/126 psi at 600 degrees F., -14.5/103 psi at 700 degrees F., -14.5/87 psi at 752 degrees F. National Board# 4, serial# 31000-02-487, built 2009.

Stock# 50436001

Used- Alfa Laval Spiral Heat Exchanger, Type 1-H, 100 Square Feet Area. Shell 316 stainless steel, head carbon steel. Rated 120 psi at 400 Degrees F. 3" openings. Side lug mounted. Serial# 21318, Built 1994.

Stock# 50436002

Used- Alfa Laval Spiral Heat Exchanger, Type 1-H, 100 Square Feet Area. Shell 316 stainless steel, head carbon steel. Rated 120 psi at 400 Degrees F. 3" openings. Side lug mounted. Serial# 21063, Built 1993.

Stock# 46922001

Unused- Tranter Spiral Heat Exchanger, (115) Square Feet, Carbon Steel. Chamber and channel rated 98.8 psi at 32 to 250 degrees F. Cold side 2" inlet and outlet, hot side 2", 1-1/2" inlet and outlet. (4) 1" vents. Saddle mounted. Serial # SMAB567, National Board # 59779. Built 2012.

Stock# 47852026

Used- Alfa Laval Titanium Spiral Heat Exchanger, 945 Square Feet, Model 1H-L-1T. Titanium SB-265 grade 2 shell, titanium clad carbon steel heads rated 175 psi at -7 to 175 degrees F. 8" Cold side inlet and outlet, 6" hot side inlet and outlet, 2" hot and cold drains. Serial# 26013, National Board# 18692. Built 2008.

Stock# 48363001

Used- Alfa Laval Thermal Vertical Spiral Heat Exchanger, 995 Square Feet, Type 2-VH, 316 Stainless Steel Product Contact Areas. Hot side rated 75 and Full Vacuum psi at 200 degrees F. Cold side rated 75 psi at 200 degrees F. Carbon steel removable heads internally faced with 316 stainless steel. Openings 24", 10", (2) 4". Side mounting lugs cut off. National Board# 15052, Serial# 18736. Built 1988.

Stock# 40141019

Used- American Heat Reclaiming Horizontal Spiral Heat Exchanger, Type 1H, 1060 Square Feet, 316 Stainless Steel. Hot and cold side rated 100 psi at 200 degrees F. Carbon steel removable heads, (1) with 316 stainless steel clad. Inner pass cross section hot side 0.375'' x 48'', length 130.5'; outer pass cross section cold side 0.50'' x 48'', length 134.4'. Openings: hot side (2) 6", cold side (2) 6". Mounted on carbon steel saddles. Serial# 12109, National Board# 9555. Built 1977.

Stock# 40141020

Used- American Heat Reclaiming Horizontal Spiral Heat Exchanger, Type 1H, 1060 Square Feet, 316 Stainless Steel. Hot and cold side rated 100 psi at 200 degrees F. Carbon steel removable heads, (1) with 316 stainless steel clad. Inner pass cross section hot side 0.375'' x 48'', length 130.5', outer pass cross section cold side 0.50'' x 48'', length 134.4'. Openings: hot side (2) 6", cold side (2) 6". Mounted on carbon steel saddles. Serial# 12108, National Board# 9554. Built 1977.

Stock# 46971083

Used- Alfa Laval Spiral Heat Exchanger, Model 1V-L-2C, 1780 Square Feet, 316L Stainless Steel. Hot and cold sides rated 100 psi/Full Vacuum at -20 to 400 degrees F. Removable heads with 316L stainless steel facing. Cold side inlets (2) 6", cold side outlet 8", hot side inlet 10", hot side outlets (2) 8". National Board # 19061, Serial # 30112-68183. Built 2010.

Stock# 49843001

Unused- Tranter GmbH Horizontal Spiral Heat Exchanger. Total Surface Area 194.9 Square Meter (2098 Square Feet), Carbon Steel. Shell and coil each rated Full Vacuum/24.5 bar (355 psi) at -45 to 200 degrees C. (-49 to 392 degrees F.). Volume shell 2.225 cubic meters (587 gallon), volume coil 1.260 cubic meters (332 gallon). Openings hot side (2) 8", (2) 2", cold side (2) 6", (2) 2". Mounted on (2) saddles. Unit is nitrogen purged. National Board # 237, Serial # S-2858/2.15, CRN # W5688.2. Built 2015.

Stock# 49843002

Unused- Tranter GmbH Horizontal Spiral Heat Exchanger, Total Surface Area 194.9 Square Meter (2098 Square Feet), Carbon Steel. Shell & coil each rated Full Vacuum/24.5 bar (355 psi) at -45 to 200 degrees C. (-49 to 392 F.). Volume shell 2.225 cubic meters (587 gallon), volume coil 1.260 cubic meters (332 gallon). Openings hot side (2) 8”, (2) 2”, cold side (2) 6”, (2) 2”. Mounted on (2) saddles. Unit is nitrogen purged. National Board# 242, serial# S-2858/2.18, CRN# W5688.2, built 2015.

Stock# 49843003

Unused- Tranter GmbH Horizontal Spiral Heat Exchanger, Total Surface Area 194.9 Square Meter (2098 Square Feet), Carbon Steel. Shell & coil each rated Full Vacuum/24.5 bar (355 psi) at -45 to 200 degrees C. (-49 to 392 F.). Volume shell 2.225 cubic meters (587 gallon), volume coil 1.260 cubic meters (332 gallon). Openings hot side (2) 8”, (2) 2”, cold side (2) 6”, (2) 2”. Mounted on (2) saddles. Unit is nitrogen purged. National Board# 214, serial# S-2858/2.8, CRN# W5688.2, built 2014.

Stock# 49843004

Unused- Tranter GmbH Horizontal Spiral Heat Exchanger, Total Surface Area 194.9 Square Meter (2098 Square Feet), Carbon Steel. Shell & coil each rated Full Vacuum/24.5 bar (355 psi) at -45 to 200 degrees C. (-49 to 392 F.). Volume shell 2.225 cubic meters (587 gallon), volume coil 1.260 cubic meters (332 gallon). Openings hot side (2) 8”, (2) 2”, cold side (2) 6”, (2) 2”. Mounted on (2) saddles. Unit is nitrogen purged. National Board# 235, serial# S-2858/2.13, CRN# W5688.2, built 2015.

Stock# 49843005

Unused- Tranter GmbH Horizontal Spiral Heat Exchanger, Total Surface Area 194.9 Square Meter (2098 Square Feet), Carbon Steel. Shell & coil each rated Full Vacuum/24.5 bar (355 psi) at -45 to 200 degrees C. (-49 to 392 F.). Volume shell 2.225 cubic meters (587 gallon), volume coil 1.260 cubic meters (332 gallon). Openings hot side (2) 8”, (2) 2”, cold side (2) 6”, (2) 2”. Mounted on (2) saddles. Unit is nitrogen purged. National Board# 236, serial# S-2858/2.14, CRN# W5688.2, built 2015.

Stock# 49843006

Unused- Tranter GmbH Horizontal Spiral Heat Exchanger, Total Surface Area 194.9 Square Meter (2098 Square Feet), Carbon Steel. Shell & coil each rated Full Vacuum/24.5 bar (355 psi) at -45 to 200 degrees C. (-49 to 392 F.). Volume shell 2.225 cubic meters (587 gallon), volume coil 1.260 cubic meters (332 gallon). Openings hot side (2) 8”, (2) 2”, cold side (2) 6”, (2) 2”. Mounted on (2) saddles. Unit is nitrogen purged. National Board# 211, serial# S-2858/2.9, CRN# W5688.2, built 2014.

Stock# 49843007

Unused- Tranter GmbH Horizontal Spiral Heat Exchanger, Total Surface Area 194.9 Square Meter (2098 Square Feet), Carbon Steel. Shell & coil each rated Full Vacuum/24.5 bar (355 psi) at -45 to 200 degrees C. (-49 to 392 F.). Volume shell 2.225 cubic meters (587 gallon), volume coil 1.260 cubic meters (332 gallon). Openings hot side (2) 8”, (2) 2”, cold side (2) 6”, (2) 2”. Mounted on (2) saddles. Unit is nitrogen purged. National Board# 212, serial# S-2858/2.10, CRN# W5688.2, built 2014.

Stock# 49843008

Unused- Tranter GmbH Horizontal Spiral Heat Exchanger, Total Surface Area 194.9 Square Meter (2098 Square Feet), Carbon Steel. Shell & coil each rated Full Vacuum/24.5 bar (355 psi) at -45 to 200 degrees C. (-49 to 392 F.). Volume shell 2.225 cubic meters (587 gallon), volume coil 1.260 cubic meters (332 gallon). Openings hot side (2) 8”, (2) 2”, cold side (2) 6”, (2) 2”. Mounted on (2) saddles. Unit is nitrogen purged. National Board# 244, serial# S-2858/2.20, CRN# W5688.2, built 2015.

Stock# 49843009

Unused- Tranter GmbH Horizontal Spiral Heat Exchanger, Total Surface Area 194.9 Square Meter (2098 Square Feet), Carbon Steel. Shell & coil each rated Full Vacuum/24.5 bar (355 psi) at -45 to 200 degrees C. (-49 to 392 F.). Volume shell 2.225 cubic meters (587 gallon), volume coil 1.260 cubic meters (332 gallon). Openings hot side (2) 8”, (2) 2”, cold side (2) 6”, (2) 2”. Mounted on (2) saddles. Unit is nitrogen purged. National Board# 213, serial# S-2858/2.7, CRN# W5688.2, built 2014.

Stock# 49843010

Unused- Tranter GmbH Horizontal Spiral Heat Exchanger, Total Surface Area 194.9 Square Meter (2098 Square Feet), Carbon Steel. Shell & coil each rated Full Vacuum/24.5 bar (355 psi) at -45 to 200 degrees C. (-49 to 392 F.). Volume shell 2.225 cubic meters (587 gallon), volume coil 1.260 cubic meters (332 gallon). Openings hot side (2) 8”, (2) 2”, cold side (2) 6”, (2) 2”. Mounted on (2) saddles. Unit is nitrogen purged. National Board# 243, serial# S-2858/2.19, CRN# W5688.2, built 2015.

Stock# 45655005

Used- Alfa Laval Thermal Horizontal Spiral Heat Exchanger, 2385 Square Feet, Model 1-H. 304 Stainless steel product contact areas. Hot and cold side rated 150 psi at 20 to 220 degrees F. Carbon steel removable heads with 304L stainless steel clad. Openings (4) 4". Mounted on carbon steel saddles. National Board#15754, Serial#22003. Built 1995. New gaskets required.

Stock# 45655006

Used- Alfa Laval Thermal Horizontal Spiral Heat Exchanger, 2400 Square Feet, Model 1-H. 316 Stainless steel product contact areas. Hot and cold side rated 125 psi at 250 degrees F. Carbon steel removable heads with 316 stainless steel clad. Openings (4) 4". Mounted on carbon steel saddles. National Board# 13862, Serial# 18229. Built 1987.

Stock# 49843011

Unused- Tranter GmbH Horizontal Spiral Heat Exchanger. Total Surface Area 239.7 Square Meter (2580 Square Feet), Carbon Steel. Shell and coil each rated Full Vacuum/24.5 bar (355 psi) at -45 to 200 degrees C. (-49 to 392 degrees F.). Volume shell 2.080 cubic meters (549 gallon), volume coil 1.800 cubic meters (475 gallon). Openings hot side (2) 6", (2) 2", cold side (2) 6", (2) 2". Mounted on (2) saddles. Unit is nitrogen purged. National Board # 227, Serial # S-2858/1.25, CRN # W5665.2. Built 2015.

Stock# 49843012

Unused- Tranter GmbH Horizontal Spiral Heat Exchanger, Total Surface Area 239.7 Square Meter (2580 Square Feet), Carbon Steel. Shell & coil each rated Full Vacuum/24.5 bar (355 psi) at -45 to 200 degrees C. (-49 to 392 F.). Volume shell 2.080 cubic meters (549 gallon), volume coil 1.800 cubic meters (475 gallon). Openings hot side (2) 6”, (2) 2”, cold side (2) 6”, (2) 2”. Mounted on (2) saddles. Unit is nitrogen purged. National Board# 224, serial# S-2858/1.20, CRN# W5665.2, built 2015.

Stock# 49843013

Unused- Tranter GmbH Horizontal Spiral Heat Exchanger, Total Surface Area 239.7 Square Meter (2580 Square Feet), Carbon Steel. Shell & coil each rated Full Vacuum/24.5 bar (355 psi) at -45 to 200 degrees C. (-49 to 392 F.). Volume shell 2.080 cubic meters (549 gallon), volume coil 1.800 cubic meters (475 gallon). Openings hot side (2) 6”, (2) 2”, cold side (2) 6”, (2) 2”. Mounted on (2) saddles. Unit is nitrogen purged. National Board# 193, serial# S-2858/1.7, CRN# W5665.2, built 2014.

Stock# 49843014

Unused- Tranter GmbH Horizontal Spiral Heat Exchanger, Total Surface Area 239.7 Square Meter (2580 Square Feet), Carbon Steel. Shell & coil each rated Full Vacuum/24.5 bar (355 psi) at -45 to 200 degrees C. (-49 to 392 F.). Volume shell 2.080 cubic meters (549 gallon), volume coil 1.800 cubic meters (475 gallon). Openings hot side (2) 6”, (2) 2”, cold side (2) 6”, (2) 2”. Mounted on (2) saddles. Unit is nitrogen purged. National Board# 192, serial# S-2858/1.6, CRN# W5665.2, built 2014.

Stock# 49843015

Unused- Tranter GmbH Horizontal Spiral Heat Exchanger, Total Surface Area 239.7 Square Meter (2580 Square Feet), Carbon Steel. Shell & coil each rated Full Vacuum/24.5 bar (355 psi) at -45 to 200 degrees C. (-49 to 392 F.). Volume shell 2.080 cubic meters (549 gallon), volume coil 1.800 cubic meters (475 gallon). Openings hot side (2) 6”, (2) 2”, cold side (2) 6”, (2) 2”. Mounted on (2) saddles. Unit is nitrogen purged. National Board# 225, serial# S-2858/1.21, CRN# W5665.2, built 2015.

Stock# 49843016

Unused- Tranter GmbH Horizontal Spiral Heat Exchanger, Total Surface Area 239.7 Square Meter (2580 Square Feet), Carbon Steel. Shell & coil each rated Full Vacuum/24.5 bar (355 psi) at -45 to 200 degrees C. (-49 to 392 F.). Volume shell 2.080 cubic meters (549 gallon), volume coil 1.800 cubic meters (475 gallon). Openings hot side (2) 6”, (2) 2”, cold side (2) 6”, (2) 2”. Mounted on (2) saddles. Unit is nitrogen purged. National Board# 226, serial# S-2858/1.22, CRN# W5665.2, built 2015.

Stock# 49843017

Unused- Tranter GmbH Horizontal Spiral Heat Exchanger, Total Surface Area 239.7 Square Meter (2580 Square Feet), Carbon Steel. Shell & coil each rated Full Vacuum/24.5 bar (355 psi) at -45 to 200 degrees C. (-49 to 392 F.). Volume shell 2.080 cubic meters (549 gallon), volume coil 1.800 cubic meters (475 gallon). Openings hot side (2) 6”, (2) 2”, cold side (2) 6”, (2) 2”. Mounted on (2) saddles. Unit is nitrogen purged. National Board# 200, serial# S-2858/1.10, CRN# W5665.2, built 2014.

Stock# 49843018

Unused- Tranter GmbH Horizontal Spiral Heat Exchanger, Total Surface Area 239.7 Square Meter (2580 Square Feet), Carbon Steel. Shell & coil each rated Full Vacuum/24.5 bar (355 psi) at -45 to 200 degrees C. (-49 to 392 F.). Volume shell 2.080 cubic meters (549 gallon), volume coil 1.800 cubic meters (475 gallon). Openings hot side (2) 6”, (2) 2”, cold side (2) 6”, (2) 2”. Mounted on (2) saddles. Unit is nitrogen purged. National Board# 216, serial# S-2858/1.16, CRN# W5665.2, built 2014.

Stock# 49843019

Unused- Tranter GmbH Horizontal Spiral Heat Exchanger, Total Surface Area 239.7 Square Meter (2580 Square Feet), Carbon Steel. Shell & coil each rated Full Vacuum/24.5 bar (355 psi) at -45 to 200 degrees C. (-49 to 392 F.). Volume shell 2.080 cubic meters (549 gallon), volume coil 1.800 cubic meters (475 gallon). Openings hot side (2) 6”, (2) 2”, cold side (2) 6”, (2) 2”. Mounted on (2) saddles. Unit is nitrogen purged. National Board# 232, serial# S-2858/1.28, CRN# W5665.2, built 2015.

Stock# 49843020

Unused- Tranter GmbH Horizontal Spiral Heat Exchanger, Total Surface Area 239.7 Square Meter (2580 Square Feet), Carbon Steel. Shell & coil each rated Full Vacuum/24.5 bar (355 psi) at -45 to 200 degrees C. (-49 to 392 F.). Volume shell 2.080 cubic meters (549 gallon), volume coil 1.800 cubic meters (475 gallon). Openings hot side (2) 6”, (2) 2”, cold side (2) 6”, (2) 2”. Mounted on (2) saddles. Unit is nitrogen purged. National Board# 201, serial# S-2858/1.11, CRN# W5665.2, built 2014.

Stock# 49843021

Unused- Tranter GmbH Horizontal Spiral Heat Exchanger, Total Surface Area 239.7 Square Meter (2580 Square Feet), Carbon Steel. Shell & coil each rated Full Vacuum/24.5 bar (355 psi) at -45 to 200 degrees C. (-49 to 392 F.). Volume shell 2.080 cubic meters (549 gallon), volume coil 1.800 cubic meters (475 gallon). Openings hot side (2) 6”, (2) 2”, cold side (2) 6”, (2) 2”. Mounted on (2) saddles. Unit is nitrogen purged. National Board# 204, serial# S-2858/1.14, CRN# W5665.2, built 2014.

Stock# 49843022

Unused- Tranter GmbH Horizontal Spiral Heat Exchanger, Total Surface Area 239.7 Square Meter (2580 Square Feet), Carbon Steel. Shell & coil each rated Full Vacuum/24.5 bar (355 psi) at -45 to 200 degrees C. (-49 to 392 F.). Volume shell 2.080 cubic meters (549 gallon), volume coil 1.800 cubic meters (475 gallon). Openings hot side (2) 6”, (2) 2”, cold side (2) 6”, (2) 2”. Mounted on (2) saddles. Unit is nitrogen purged. National Board# 184, serial# S-2858/1.1, CRN# W5665.2, built 2014.

Stock# 49843023

Unused- Tranter GmbH Horizontal Spiral Heat Exchanger, Total Surface Area 239.7 Square Meter (2580 Square Feet), Carbon Steel. Shell & coil each rated Full Vacuum/24.5 bar (355 psi) at -45 to 200 degrees C. (-49 to 392 F.). Volume shell 2.080 cubic meters (549 gallon), volume coil 1.800 cubic meters (475 gallon). Openings hot side (2) 6”, (2) 2”, cold side (2) 6”, (2) 2”. Mounted on (2) saddles. Unit is nitrogen purged. National Board# 220, serial# S-2858/1.19, CRN# W5665.2, built 2015.

Stock# 49843024

Unused- Tranter GmbH Horizontal Spiral Heat Exchanger, Total Surface Area 239.7 Square Meter (2580 Square Feet), Carbon Steel. Shell & coil each rated Full Vacuum/24.5 bar (355 psi) at -45 to 200 degrees C. (-49 to 392 F.). Volume shell 2.080 cubic meters (549 gallon), volume coil 1.800 cubic meters (475 gallon). Openings hot side (2) 6”, (2) 2”, cold side (2) 6”, (2) 2”. Mounted on (2) saddles. Unit is nitrogen purged. National Board# 230, serial# S-2858/1.26, CRN# W5665.2, built 2015.

Stock# 49843025

Unused- Tranter GmbH Horizontal Spiral Heat Exchanger, Total Surface Area 239.7 Square Meter (2580 Square Feet), Carbon Steel. Shell & coil each rated Full Vacuum/24.5 bar (355 psi) at -45 to 200 degrees C. (-49 to 392 F.). Volume shell 2.080 cubic meters (549 gallon), volume coil 1.800 cubic meters (475 gallon). Openings hot side (2) 6”, (2) 2”, cold side (2) 6”, (2) 2”. Mounted on (2) saddles. Unit is nitrogen purged. National Board# 215, serial# S-2858/1.15, CRN# W5665.2, built 2014.

Stock# 49843026

Unused- Tranter GmbH Horizontal Spiral Heat Exchanger, Total Surface Area 239.7 Square Meter (2580 Square Feet), Carbon Steel. Shell & coil each rated Full Vacuum/24.5 bar (355 psi) at -45 to 200 degrees C. (-49 to 392 F.). Volume shell 2.080 cubic meters (549 gallon), volume coil 1.800 cubic meters (475 gallon). Openings hot side (2) 6”, (2) 2”, cold side (2) 6”, (2) 2”. Mounted on (2) saddles. Unit is nitrogen purged. National Board# 231, serial# S-2858/1.27, CRN# W5665.2, built 2015.

Stock# 49843027

Unused- Tranter GmbH Horizontal Spiral Heat Exchanger, Total Surface Area 239.7 Square Meter (2580 Square Feet), Carbon Steel. Shell & coil each rated Full Vacuum/24.5 bar (355 psi) at -45 to 200 degrees C. (-49 to 392 F.). Volume shell 2.080 cubic meters (549 gallon), volume coil 1.800 cubic meters (475 gallon). Openings hot side (2) 6”, (2) 2”, cold side (2) 6”, (2) 2”. Mounted on (2) saddles. Unit is nitrogen purged. National Board# 228, serial# S-2858/1.23, CRN# W5665.2, built 2015.

Stock# 49843028

Unused- Tranter GmbH Horizontal Spiral Heat Exchanger, Total Surface Area 239.7 Square Meter (2580 Square Feet), Carbon Steel. Shell & coil each rated Full Vacuum/24.5 bar (355 psi) at -45 to 200 degrees C. (-49 to 392 F.). Volume shell 2.080 cubic meters (549 gallon), volume coil 1.800 cubic meters (475 gallon). Openings hot side (2) 6”, (2) 2”, cold side (2) 6”, (2) 2”. Mounted on (2) saddles. Unit is nitrogen purged. National Board# 229, serial# S-2858/1.24, CRN# W5665.2, built 2015.
