Used Gas Turbine Generators

Stock# 52272001

Unused - Siemens 22 MW Steam Turbine, Model SST-600 (NK50/45). (1) Siemens Compressor 12 MW STC-GV (40-6); (1) Siemens 10 MW Generator, 60 Hz, 4160 Volt, 3 Phase, 11764 kva; (1) high speed Lufkin gear unit; (1) lube oil unit, (1) set Complete turbine thrust bearing; (1) Set Complete Turbine Front Journal Bearing; (1) Set Rear Journal Bearing; (1) set Complete Set Sealing Strips and Chaulking Material; (1) Set Journal and Thrust Bearings Bull Gears Shaft and Pinion shafts; (1) Set Labyrinth Shaft Seals; (1) Set Oils Seals for Bull and Pinion Shafts.

Stock# 45686003

Used- Ingersoll-Rand PowerWorks 70 kW Microturbine / Peak Shaving Natural Gas Generator Set, Model 70LM, SN-PW00220DO2074. 3/60/480V. Weather enclosure. 988.9 Hours. Located in CA.

Stock# 52984002

Unused - Triveni Turbine Bleed Condensing Steam Turbine, type Bleed Condensing Turbine. Power rated to 20000 KW. Inlet steam 40 bar (600 PSI) at 400 deg. C (752 deg F). Inlet steam flow 91.5 TPH. Exhaust flow 86.139 TPH. Turbine speed 6150 RPM, Agitator speed 1500 RPM. Incl. Teil-Mysore gearbox, type N3219C. 21000 Kw. Input/output speed 6150/1500 RPM. Lubrication oil system, type 1135 LPM. 21000-liter (5555 US-Gallon) tank capacity. MOP main lubrication gear pump, type ISO-VG-46. Capacity 1200 liters (317 US-gallon) per minute. Auxiliary skit, Steam condenser. Complete with sensors, piping, valves, and additional infrastructure. Order reference: C-2846. New year 2012.

Stock# 52984003

Used-Triveni Turbine Bleed Condensing Steam Turbine, type Bleed Condensing Turbine. Power rated to 20000 KW. Inlet steam 40 bar (600 PSI) at 400 deg. C (752 deg F). Inlet steam flow 91.5 TPH. Exhaust flow 86.139 TPH. Turbine speed 6150 RPM, Agitator speed 1500 RPM. Incl. Teil-Mysore gearbox, type N3219C. 21000 Kw. Input/output speed 6150/1500 RPM. Lubrication oil system, type 1135 LPM. 21000-liter (5555 US-Gallon) tank capacity. MOP main lubrication gear pump, type ISO-VG-46. Capacity 1200 liters (317 US-gallon) per minute. Auxiliary skit, Steam condenser. Complete with sensors, piping, valves, and additional infrastructure. New year 2012.
