Used Machine Tools

Stock# 51150001

Used- KIA Model Center H63 CNC Horizontal Machining Center. Serial # KH630117.New 1999, 2 25" x 25" pallets, 360 degree table indexing, 2,200 pounds table load, Travels X=37.7", Y=32.5", Z=30", 50 taper, Speeds 20-4, 500 RPM, 60 Position ATC, CoolJet high pressure coolant, Fanuc 15M CNC control.

Stock# 51150002

Used- Bullard Cutmaster 75 Vertical Turret Lathe. Serial # 30395.46" diameter table, 58" maximum swing, 40" maximum height under the rail, 250 RPM, Man-Au-Trol control, Pendant control, 4 jaw table with chuck jaws, 4 position turret with 3 tools, Side head, Heidenhain Positip DRO, 30 HP main motor.

Stock# 51150004

Used- Lagun Model LBF-L1200 CNC Universal Milling Machine. Serial # 620114/29-4-97-12518, 21" x 47" table, 43" longitudinal travel, 23" ram travel, 23" vertical travel, 50 taper spindle, 50-3000 RPM speed range, Universal vertical head, GE Fanuc OM CNC control, Tsudakoma Model RNCK501P 400mm rotary table Serial # 971385. (Note work piece on table is not included.)

Stock# 51251001

Used- Selco Rear Load Panel / Beam Saw, Model WNT200. 3/60/480 volt. Year 1997.

Stock# 51224001

Used- Ameri-Can Machinery Manual Copy Router, Model CR500. Includes: pneumatic turning table at three positions -90- 0 - 90 with goniometer (accurate scale) for adjusting intermediate angles. It is also equipped with a variable speed spindle adjustable by inverter and potentiometer (from 2800 to 12000rpm) with three phase motor 1,5 HP. Its working capacities are 500x280x220mm (19.6x11x8.6 in) and (2) pneumatically actuated tracer points.

Stock# 50837001

Used-Jonsen Two Sided Deburr Machine; Model SB1000; Maximum working width: 950mm (37.4?); Minimum working length: 200mm (7.9"); Machine opening: 180mm (7"); Minimum working thickness: 1mm (20 Gauge). Conveyor speed: 1-5m/minimum (3.3 16.4 foot/minimum) Variable speed; Deburring belt compensation height: 40mm (1.5"); Dust extraction capacity: 4000m3/h (2,350 ft3/min); Total power consumption: 17.2 kW, Voltage 230V, 3 Ph / 60Hz ; Feeding table height: 800mm (31.5"); PLC control: Mitsubishi PLC; Deburring block unit types: DuPont abrasive (3 x 2 x 1). Weight: Approximately 10,000 pounds.

Stock# 409334

Used- Guifil "GHE" Hydraulic Guillotine Shear, Model GHE630. Maximum shearing length 10'. Cutting angle 0.5 to 2.5 degrees. Cutting capacity: mild steel USG 3, stainless steel USG 8. Strokes per minute: 16 at max angle, 50 at min angle. 18 Clamps. Main motor approximate 10 hp, 1450 rpm. Backgauge electric motor approximate 0.55kW, 1390 rpm. Backgauge travel 0 to 3'3". Maximum cutting pressure 3556 psi.

Stock# 50538001

Used- Juki Selective Solder System, Model 400L. Three-stage inline system, 4mm to 30mm diameter soldering nozzles, Drop Jet, Spray Fluxer, Pressurized Tank, Pre-Heater.

Stock# 50309001

Used- Heim Rousselle Tow Point Straight Side Stamping Press. 150 Tons, Model S2. Near Bottom Stroke, Twin Drive (Crankshafts), 60 Strokes per minute, 4" Stroke. Bed size 72" x 42". Bolster Area 72" x 42", 3" Bolster. Bed Opening 48" x 21". Slide Area 72" x 42", 4" Slide Adjustments. 18" SDAU Shut Height above Bed, 15" SDAU Shut Height above bolster. 77.5" Distance between LR uprights. 34" Floor to top of bed, 37" floor to top of bolster. 25 hp. Floor Space 122" x 74". 148" Overall Height; 440/3/60 volts. Approximately 30,000 pounds. Mfg. 2013. Reported to be reconditioned.

Stock# 51067001

Used- Hines Bending Systems Hydraulic Tube Bender. Model 150 CNC. Includes BenPro G2 Series Control System. Maximum Feeding of 130 feet / minute. Maximum POB 40 R/minute. Maximum Bend Angle of 190 Degrees. Maximum Bend Arm Speed of 10 RPM. Operating Pressure of 1200 PSI. Driven by 10 hp motor. Reservoir Capacity of 120 Gallons. Round Tube Capacity of 1.5" OD x .125" wall. Standard Maximum Radius of 10". Includes Pressure Die Holder, Drop-A-Way Clamp Holder, Wiper Die Holder, and Pressure Die Assist we/ line encoder and proportional valve with servo. 220 Volt/ 3 Phase/ 60 Hz.
