Used Cutters, Dicers and Slicers

Stock# 51186009

Used- Fritsch International High Speed Cutting Mill. Model Pulverisette 19. Stainless Steel Construction. Capable of variable rotational speed adjustment increments between 300 and 3000 rpm. Maximum feed size of 70 x 80 mm. Maximum throughput of 60 I/H. Sieve Sizes: 4mm or 6mm. Powered by 5 kW three-phase motor with frequency converter. Defined final fineness due to interchangeable sieve cassettes 0.2 10 mm. Collection vessel 0.25 L to 60 L. Optimized Clean Design for maximum ease of cleaning. Practical operation directly on the front panel. Externally adjustable cutting gap with double cone bearing of the rotor. Last used in a Cannabis application.

Stock# 51359001

Used- Grote Pendulum Slicer, Model S/A 530-E. Stainless steel. AB Panel View and Servos.

Stock# 51591001

Used- Grote Model S/A 530 Single Lane Slicer/Applicator. Machine is rated at up to 176 strokes per minute per lane. Unit also bulk slices, stacks and shingles. Maximum slice rate in stack or shingle mode 120 strokes per minute per lane. Set up for a 1/2" wide band blade. Slicing zone up to 30" wide, up to a maximum of 6" slicing stroke. Currently set up for (4) round lanes, includes 30" wide x 72" long wire mesh discharge conveyor. Control panel with Mitsubishi GOT1000 HMI and MELSEC-FX3u-32M PLC. Utilizes Grote's Accuband slicing system. Machine is designed to apply toppings, top buns, pizza crusts, trays, and oven belts. Can slice and apply most boneless/non-frozen meat, fish, poultry, cheese, bread products, fruits and vegetables. Is a wash-down unit. Was last running on a fresh sandwich line. 3/60/208-230 Volt.

Stock# 51591002

Used- Grote Model S/A 530 Single Lane Slicer / Applicator. Machine is rated at up to 176 strokes per minute per lane. Unit also bulk slices, stacks and shingles. Maximum slice rate in stack or shingle mode 120 strokes per minute per lane. Set up for a 1/2" wide band blade. Slicing zone up to 30" wide, up to a maximum of 6" slicing stroke. Currently set up for (5) square lanes, includes 30" wide x 72" long wire mesh discharge conveyor. Control panel with Mitsubishi GT1055 HMI and MELSEC-FX3u-32M PLC. Utilizes Grote's Accuband slicing system. Machine is designed to apply toppings, top buns, pizza crusts, trays, and oven belts. Can slice and apply most boneless/non-frozen meat, fish, poultry, cheese, bread products, fruits and vegetables. Is a wash-down unit. Was last running on a fresh sandwich line. 3/60/208-230V.

Stock# 51500001

Used- Holac SECT 28 Continuous High-Volume Slicer. Capable of 350-700 cuts per minute. Cutting thickness 1 mm to 250 mm. Approximate 9-1/2" wide X 57" long infeed conveyor with down-holder belt. Stable cut-off blade. Driven by a 7.5 HP motor. Control panel with Panelware digital microprocessor, Lenze AC drives, B&R system 2003 PLC. Stainless Steel construction. Frame mounted. 3/50/400V.

Stock# 51560001

Used-Jaccard Full Automatic Stacker Slicer; Model VA 4000AT; Stainless Steel Construction; 25-55 strokes per minute; 13" Blade; Slice thickness 0-0.40"; Cutting Length 10" x 7.7" High; Programmable side to side shingling to product 4 way layered and/or circular pattern for deli trays; Easy to Clean Chain Drive; certified by NSF; 120 Volt single phase; Overall Dimensions: 52" L x 45" W x 52.4" H; approximately 287 lbs.

Stock# 44268178

Used- Stephan Food Processing Machinery Vacutherm System, Model V-MC1200/150, Serial # 109002, with Waukesha 180U2 Pump, Centrifugal Pump, Quadro Emulsifier and a Lifter/Tilter, and AB Chart Recorder. ** SALE SUBJECT TO SELLER'S APPROVAL **

Stock# 44268179

Used- Stephan Food Processing Machinery Vacutherm System, Model V-MC1200/150, Serial # 109001, with Waukesha 180U2 Pump, Centrifugal Pump, Quadro Emulsifier and a Lifter/Tilter, and AB Chart Recorder. ** SALE SUBJECT TO SELLER'S APPROVAL **

Stock# 47760001

Used- Stephan TC Combicut Mixer, Model TC 600, 304 Stainless Steel. Drum capacity 600 liter, batch size 200 to 420 liter, capacity up to 2700 liters per hour. Jacketed drum approximate 43" diameter x 25" deep, rated 2 bar at 134 degrees C. Hinged front jacketed door with a mixing baffle/scraper driven by a 15 hp, 3/60/230/460 volt, 1750 rpm gear motor, ratio 65.51 to 1. (1) Trapezoidal kneading element driven by a 104 kw, 3/60/460 volt, 1180 rpm motor. Top mounted ingredient hopper with slide gate valve, bottom outlet with a slide gate valve. Includes a hydraulic power pack, control panel (2) feed hoppers. Mounted on a stainless steel frame with 40" tall legs. Serial # C85-711.036.01. Built 1985.

Stock# 49112002

Used- Stephan TC/SK Combicut Mixer, Model TK-850-S, 304 Stainless Steel. Drum capacity approximate 850 liter, batch size 300 to 570 liter, capacity up to 3600 liters per hour. Drum approximate 46" diameter x 30" deep. 14" x 15.25" infeed, 21.5 in x 13" discharge. Hinged front door with mixing baffle/scraper driven by approximate 15 hp motor. Kneading element (Incomplete) driven by a approximate 100/120kW motor. Includes control panel with Allen Bradley controls. Serial # 3353393. Built 1994.

Stock# 50812001

Used- Stephan Cutter Combicut; Model TC300; Batch sizes: 100 up to 220 liters; Capacity: up to 1200 l/h; Temperature: maximum 95C; Unit combines several process steps in one: cutting, mixing, dispersing, heating, cooling, deaerating and emulsifying. Horizontal Mixing Drum; cutting and emulsifying knives are driven through the back plane by the main motor; mixing arm with scraper is activated by a Applications and Processing Steps Design of the Combicut TC System motor through the front cover; machine is charged by a slide and / or pipe connection; Discharging is done via a slide or a bottom seat valve; Includes Control Cabinet: Version: Simatic S5-115 U incl. CPU 943; Maximum 8 programs; Last used in a food application for sauces and processed cheese.

Stock# 50907002

Used- Stephan Cutter / High Speed Universal Horizontal Vacuum Mixer, Stainless Steel. Jacketed 29" diameter x 17" deep SS bowl. Hydraulic slide gate discharge 12" x 10". Driven by a 15 kw drive, with Stephan Stainless steel hopper 32" x 12" straight side x 22" cone. Pneumatic butterfly valve, Stephan incline discharge conveyor, 24" wide x 80", discharge, with control panel. Serial # 718781. No tag on the Mixer, but it appears to look like a Model TK150. Used for Dough/ Bakery.

Stock# 51530001

Used- Urschel Dicer, Model RA. Designed to uniformly dice, strip cut, or slice. Slice thickness 1/16" to 3/8", circular knife cuts 1/8" to 1", crosscut knife cuts 1/8" to 1-1/2". Maximum input product is 3-1/2" in any dimension. Mounted on a stainless steel frame.

Stock# 51530002

Used- Urschel Dicer, Model GA. Designed to uniformly dice, strip cut, or slice. Slice thickness 1/16" to 3/4", circular knife cuts 3/32" to 3", crosscut knife cuts 9/32 to 7/8". Maximum input product is 5-1/2" in any dimension. Mounted on a stainless steel frame.
