Used Double Arm Mixer Extruders

Stock# 82688

Used- Baker Perkins/Guittard Lab Size Mixer Extruder, Model LEX8. 1.33 Gallon working capacity, 2.125 total, 304 stainless steel bowl with carbon steel jacket. Bowl measures 8-1/2" front to back x 8-3/4" left to right x approximately 7-1/2" deep. 317 Stainless steel tangential sigma blades, geared one end. Domed top cover with sight glass, suitable for vacuum. 2" diameter x 14" long screw discharge. Both driven by an approximate 2 hp motor. Includes a C.W. Brabender model T303 Thermotron heater. Unit mounted on a cabinet with control panel and casters.

Stock# 10147158

Used AMK Mixer/Extruder, Model VIU20, Stainless steel construction on product contact parts. 5.3 gallon (20 liter) working capacity. Bowl jacketed and rated for vacuum (-1). Working pressure 45 psi (3 bar) at 482 deg F (250 deg. C). Incl. vacuum top cover. With adjustable packing glands. 8.25HP/5.5 KW, 400/690Volt/50cycle/3Ph motor. Arm speed 6/28 and 7/35 Rpm, Screw discharge, by 8.25HP/5.5 KW 400-690Volt/50 cycle/3Ph motor. Z-blades, screw speed 6-18 RPM by a variable speed frequency inverter. Control panel. Overall dimensions: 65" (2000 mm) x 49" (1500 mm) x 59" (1800 mm) high. Weight 1.7 tonnes. New 1970. Reported reconditioned.

Stock# 10147159

AMK Mixer/Extruder, Model VIU20IV, 316/316TI stainless steel construction on product contact parts. 5.3 gallon (20 liter) working capacity. Bowl jacketed and rated for vacuum (-1). Working pressure 45 psi (3 bar) at 482 deg F. (250 deg. C). Incl. vacuum top cover. With adjustable packing glands. 8.25HP/5.5 KW, 400/690Volt/50cycle/3Ph motor. Arm speed 6.5/32 and 13/64 Rpm, Screw discharge, by 8.25HP/5.5 KW 400-690Volt/50 cycle/3Ph motor. Z-blades. Extrusion screw discharge. Screw speed 6.5-32 RPM by a variable speed frequency inverter. Incl. oil heating unit, type CPS 04-1-8-1 and control panel. Overall dimensions: 59" (1800 mm) x 33" (1000 mm) x 59" (1800 mm) high. New 1997

Stock# 13705058

Used- 15 Gallon Jacketed, Vacuum, Sigma Blade Mixer/ Extruder. S/S Groupe Lautrette (RPA Process) Model MBD-90/60 Jacketed, vacuum, heavy duty sigma blade mixer/ extruder. Stainless steel construction. 90 liter (22.5 gallon) total capacity. 60 Liter (15 gallon) working capacity, 15.5" x 22" x 17" deep bowl. 3 " diameter extruder screw. Jacket rated 3 bar (45 psi). Unit driven by 11 kW (15 hp.) motor, screw driven by 5.5 kW (7.5 hp) variable speed motor. Mounted on base with vacuum cover. Elec: 3/60/240V.

Stock# 50013001

Used- Ross AMK Class V Double Arm Kneader Extruder, 15 Gallon (60 Liter) Working Capacity, Stainless Steel. Jacketed bowl approximate 19-5/8" left to right x 19" front to back x approximately 20" deep, internal rated -1 bar at 200 degrees C., jacket rated 3 bar at 200 degrees C. Air operated domed top cover, suitable for vacuum, with sight glass and light, hinged safety grate. Tangential sigma style blades, geared one end. Approximate 5" diameter discharge screw with slotted die. Mixer driven by a 20hp, 3/60/230/460 volt, 1765 rpm motor, screw driven by a 5.5hp, 3/60/230/460 volt, 1740 rpm variable speed motor thru a dual reducer. Includes a control panel. Mounted on a stainless steel & carbon steel base. Serial# 12425, built 1990.

Stock# 50001002

Used- Paul O. Abbe Double Arm Mixer, Model SBM-20, 304 Stainless Steel. (20) Gallon operating capacity (40 total). Internal bowl rated Full Vacuum at 250 degrees F., carbon steel jacket rated 14.7 psi at 250 degrees F. Bowl approximate 21" left to right x 25" front to back x 19" deep, tangential dispersion blades, speeds front 31 rpm, rear 22 rpm, PTFE packing glands, geared one end, hydraulic lift domed top cover suitable for vacuum with sight glass and spray nozzle. Single ram hydraulic tilt with power pack. Mixer driven by a 10hp, 3/60/230/460 volt, 1740 rpm gear motor, ratio 38.30 to 1. Includes a control panel with an ABB ACS600 drive. Unitized on a common base. Serial# A47889, built 1999.

Stock# 48594

Used- Werner & Pfleiderer Mixer/Extruder, type UK12-AU3. 21 Gallon (80 liter) working capacity, 29.1 gallon (110 liter) total capacity. Material of construction is carbon steel on product contact parts. 20-1/2" (530 mm) long x 20-1/2" (530 mm) width x 19-1/2" (500 mm) deep jacketed bowl. Jacket estimated rated for 75 psi (5 bar). Sigma style blades with a speed of 17/21 RPM. Tangential. 6" (150 mm) dia. screw shafts. Standard packing glands. Counter balanced top cover. Screw product discharge. Belt driven thru gearbox by a 22.5HP/15 kw-380V/50cycle/3Ph-1475 RPM motor. Safety belt cover. Screw product discharge by a 11.25HP/7.5Kw-380volt/50cycle/3Ph motor. Frame mounted. Overall dimensions: 85" (2600 mm) long x 52" (1600 mm) width x 5.9" (1800 mm) high. Weight 3 tonnes. Serial # 193951.

Stock# 45977001

Used- Werner & Pfleiderer Mixer Extruder, Type UK80-AES, 316 Stainless Steel on product contact parts. Working capacity 21.2 gallon (80 liter), total capacity 31.7 gallon (120 liter). Double jacketed bowl 20-3/4" front to back x 20-1/4" left to right, approximate 27" deep. Domed top cover with (2) 4" sight glasses, (2) 2", (2) 3/4", suitable for vacuum. Has a grid lid. 316 Stainless steel sigma style blades, approximate 5-1/4" diameter x 44" long 316 stainless steel screw discharge. Blade speed 10.5 to 105 rpm and discharge screw speed 8.5 to 85 rpm. Hydraulic driven by (3) Hydrokraft model PVG130-E hydraulic units driven by 22kW, 50 Hertz motor. Includes (2) control panels, (1) top cover with press piston and ram, (1) extra screw, and misc. parts. Mounted on carbon steel frame. Built 1988.

Stock# 11690000

Used-Day mixer/extruder, 75 gallon working capacity. Stainless steel shell atmos at 353 deg F, carbon steel jacket 125 psi at 353 deg F. 32" x 32" bowl, 135 deg spiral blades overlapping, 10" diameter discharge screw, geared one end, packing glands with air purge, chain driven by (2) 25 hp variable speed motors 3/60/230/460V, gearboxes have no tags. Includes approximate 2 hp hydraulic unit for raising cover.

Stock# 10147157

Used- AMK Mixer/Extruder, Model VIU450. Stainless steel construction on product contact parts. 119 gallon (450 liter) working capacity. Bowl jacketed and rated for vacuum (-1). Working pressure 45 psi (3 bar) at 482 deg F (250 deg C). With adjustable packing glands. Includes vacuum cover with counter weights. 45HP/30 KW, 415 Volt/50cycle/3Ph motor. Screw discharge, by 15 KW, 380-660Volt/50 cycle/3Ph motor. Control panel. Overall dimensions: 137" (4200 mm) x 72" (2200 mm) x 98" (3000 mm) high. Weight 8.5 tonnes. New 1987.

Stock# 48655001

Used- AMK Mixer/Extruder. 150 gallon working capacity, 347 stainless steel. Non-jacketed bowl approximately 39-3/4" front to back x 47" left to right x approximately 43" deep. 321 stainless steel sigma blades driven by a 20 hp, 3/60/230/460 volt, 1760 rpm motor. Hinged top cover, geared one end. Approximate 11" diameter x 64" long 321 stainless steel screw discharge driven by a 15 hp, 3/60/230/460 Volt, 1745 rpm motor.

Stock# 10147154

Used- AMK Mixer/Extruder, Model VIU630IV. Carbon steel construction on product contact parts. 169 gallon (630 liter) working capacity. Bowl jacketed and rated for vacuum (-1).. Working pressure 45 psi (3 bar). With adjustable packing glands. 25/37 KW, 415 Volt/50cycle/3Ph motor, arm speed 20/41 –and 14/29 rpm, screw discharge, by 15 KW, 415 Volt/50 cycle/3Ph motor, screw speed 24 rpm. Overall dimensions: 14’6” (4500 mm) x 8’1” (2500 mm) x 8’4” (2600 mm) high.

Stock# 64593

Used- Werner & Pfleiderer Mixer/Extruder, Type UK20X-AU-4V. 316 Stainless steel construction. Total capacity 793 gallon (3000 liter); working capacity 530 gallon (2000 liter). Bowl 56.6" x 65.5" x 54.6" deep (1450 mm x 1680 mm x 1400 mm deep). Sigma style blades, 7.8" (200 mm) diameter. Double jacketed, rated for 180 psi (12 bar) and vacuum. 11.7" (300 mm) discharge screw. Driven by a Flender #177-110-115-7A gearbox, 57 hp/38 kw. Sonder 1/728. N1 465-265 rpm. N2 15/112-5 rpm. Overall dimensions (mixer only) are: 15'5" long x 6'2" wide x 8'9" high (4750 mm long x 1900 mm wide x 2750 mm high).
