Used Double Arm Mixers

Stock# 51766001

Used-Jaygo Laboratory Double Arm Sigma Blade Mixer, Model NHF-5 Capacity: Total: 5 liters Working: 3 liters (Actual working capacity is product dependent). Contact parts: 304 Stainless Steel. Double trough shell with end plates fabricated from steel plate. Trough and end plates are ground and polished smooth. Blades: 304 Stainless Steel cast Sigma blades, tangential mixing action, including Stainless Steel shafts supported by outboard bearings and driven by heavy-duty gearing. Jacket: On trough, designed for 14.9 psig pressure water or oil at 425 F. Insulation and sheathing over all jacketed surfaces. NPT jacket connections on upper sections of mixer trough. Drain in bottom center of jacket. Shaft Seals: Standard packing glands with braided PTFE and adjustable followers. Cover: 304 SS domed cover, with O-ring in groove, lift handle, limit switch, FNPT connection in cover center, quick-release clamps, and hinge at side of mixer trough. Discharge: Mixer tilted manually with worm-wheel gearbox assistance. Drive: 1HP TEFC motor direct connected to right angle gearbox, coupling, and end case gear reducer. Blades speed is variable Approx. 070 RPM front blade and 050 RPM rear blade (ratio between blade speeds is fixed). Guards: All gears, couplings, and rotating shafts guarded to prevent operators from contact. Frame: Mixer body mounted on Carbon Steel support table on wheels. Finish: All product contact parts are polished to uniform finish. All non-product contact parts are 304 SS buffed uniform finish or carbon steel painted. Controls: NEMA 4 enclosure mounted on machine frame and wired to motor and limit switch, with following operators push buttons: Mix/Stop; Emergency Stop; Speed Potentiometer with Digital Speed Readout (front blade speed); Power On light; Power Disconnect ;Step up transformer installed on lower shelf and wired to mixer control panel; Customer to wire 208V/3/60Hz electrical supply to step up transformer

Stock# 50697050

Used- Yamada Kouki Laboratory Double Arm Mixer, 304 Stainless Steel. Approximate 0.5 Gallon Working Capacity. Electrically heated bottom bowl 6" front to back x 6" left to right x 5" deep. (2) Masticator blades, flat top cover, geared one end, manual bowl tilt. Driven by a 1.5 kw, 3/60/208 volt gear motor. Mounted on a frame with casters. Serial # M-118.

Stock# 50697051

Used- Yamada Kouki Laboratory Double Arm Mixer, 304 Stainless Steel. Approximate 0.5 Gallon Working Capacity. Electrically heated bottom bowl 6" front to back x 6" left to right x 5" deep. (2) Tangential sigma blades, flat top cover, geared one end, manual bowl tilt. Driven by an approximate 1.5 kw gear motor. Mounted on a frame with casters. Serial # N-105.

Stock# 50001004

Used- Paul O. Abbe Benchtop Double Arm Mixer, Model SBM-0.5, 316 Stainless Steel. (0.50) Gallon operating capacity (0.80 total). Internal bowl rated Full Vacuum at 250 degrees F, jacket rated 14.7 psi at 250 degrees F. Bowl approximate 5" left to right x 7" front to back x 4-1/2" deep, tangential sigma blades, speeds front 73 rpm, rear 49 rpm, PTFE packing glands, geared one end. Manual tilt, approximate 5" tall bolt on bowl extension, spare blades and top covers. Mixer driven by a 2 hp, 3/60/208-230/460 volt, 1740 rpm gear motor, no ratio. Includes an Allen-Bradley 1305 drive. Serial # A47328. Built 1998. Includes a Neslab RTE-100LP bath circulator, and a Varian SD-200 vacuum pump. Mounted on a steel and wood top table.

Stock# 10715054

Used- Lab Double Arm Sigma Blade Mixer. 5 Liter Total Capacity. 3 Liter Working Capacity. 304 Stainless Steel Mirror Polished Bowl approximate 8" x 8" x 8" deep. Split Bowl with Tangential Sigma Blades. Manual Tilt. Bowl is Vacuum Rated with Cover. Jacketed and rated to 385 Deg F. Mounted on a 304 Stainless Steel Base. Blades front and back are 42/60 RPM. Control Panel. 0.33 HP Motor, 220 V, 3/60. Teflon Packing Glands. Used one time in our lab for a trial.

Stock# 48554009

Used- Baker Perkins Double Arm Mixer, 1 Gallon Capacity, Carbon Steel. Approximately 7.25" x 5.25" x 7" deep jacketed bowl, rated 80 psi at 650 degrees F. with tangential dispersion blades. Driven by a 2hp, 220/440 volt motor, with manual stuffer. National Board# 1243, Serial# 4222.

Stock# 50140001

Used- Paul O. Abbe Lab Double Arm Mixer, Model 1BSB, 316 Stainless Steel. 1 Gallon operating capacity (2 total). Carbon steel jacket rated 14 psi. Bowl approximate 7" left to right x 9-1/2" front to back x 6-3/4" deep, tangential sigma blades, front blade 70 to 17 rpm, rear blade 41 to 10 rpm, flat top cover, geared one end. Single ram hydraulic tilt with power pack. Mixer driven by a 2 hp, 3/60/230/460 volt, 814 rpm variable speed motor with reducer. Mounted on legs with base. Serial # A41282. Built 1990.

Stock# 50140002

Used- Paul O. Abbe Lab Double Arm Mixer, Model 1SBM, 316 Stainless Steel. 1 Gallon operating capacity (2 total). Carbon steel jacket rated 14 psi. Bowl approximate 7" left to right x 9" front to back x 7-3/4" deep, overlapping sigma blades, front blade 53.9 to 13.9 rpm, rear blade 53.9 to 13.9 rpm, flat top cover, geared one end. Single ram hydraulic tilt with power pack. Mixer driven by a 2 hp, 3/60/230/460 volt, 1725 rpm variable speed motor with reducer. Mounted on legs with base. Serial # A39823. Built 1988.

Stock# 48554011

Used- Baker Perkins Double Arm Mixer, 1.5 Gallon Capacity, Carbon Steel. Approximately 9" x 8.5" x 8" deep jacketed bowl, with overlapping serrated sigma blades. Driven by a 1.5 hp, 220/440 volt motor.

Stock# 43789001

Used- Aaron Process Machinery Lab Size Double Arm Mixer, 2 gallon working capacity (7.5 liters), 3.7 gallon total capacity (14 liters). 304 Stainless steel jacketed bowl with top cover. Bowl measures approximately 11" left to right x 9-1/8" front to back x approximately 7" deep, Jacket rated 144 psi at -20 to 400 degrees F. (2) Dispersion blades, manual tilt. Driven by a 2 hp XP gear motor, ratio 25 to 1. Mounted on a stand.Includes Control Panel with Start/Stop, E-Stop and Mixer Speed Control.

Stock# 13527000

Used- Baker Perkins Sigma Blade Mixer, Model 6AN2. 2.25 Gallon working (3.5 gallon total) capacity. Stainless Steel contact parts. Jacketed bowl rated 150 psi at 400 degrees F. Dome top vacuum cover. Bowl is approximately 10 3/4 in x 10 in x 8 1/2 in deep. Pneumatic tilt discharge. Unitized on base. With 2 hp, 3/60/208-230/460V motor. Machine # BPG3428.

Stock# 50001001

Used- Paul O. Abbe Double Arm Mixer, Model SBM-10, 304 Stainless Steel. (10) Gallon operating capacity (20 total). Internal bowl rated Full Vacuum at 250 degrees F. Carbon steel jacket rated 14.7 psi at 250 degrees F. Bowl approximate 17" left to right x 20" front to back x 14" deep, tangential sigma blades, speeds front 44 rpm, rear 29 rpm, PTFE packing glands, geared one end, domed top cover suitable for vacuum with sight glass, light and spray nozzle. Single ram hydraulic tilt with power pack. Mixer driven by a 7.5 hp, 3/60/230/460 volt, 1740 rpm gear motor, ratio 70.54 to 1. Includes a control panel with Allen-Bradley CompuLogix L32E, Yaskawa GPD 506/P5 drive and an Allen-Bradley PanelView Plus 700. Unitized on a common base. Serial # A47111. Built 1998.

Stock# 40664001

Used- AMK Double Arm Mixer, Type VII, Carbon Steel. Approximate working capacity 15 gallon, (29 gallon/112 liter total). Jacketed bowl 20" left to right x 18-3/4" front to back x 15" deep, internal rated -1 bar at 120 degree C, jacket rated 3 bar (43 psi) at 120 degree C. Tangential sigma blades, geared one end, top safety grate, domed top cover with sight glass, suitable for vacuum. Single ram hydraulic tilt with power pack. Mixer driven by a 7.5 kw, 3/50 motor thru a reducer.

Stock# 50697011

Used- Toshin Double Arm Dispersion Mixer, Model TDS75-100MF, Stainless Steel. 75 Liter (19.8 gallon) working capacity, 150 liter (39.6 gallon) total. Jacketed bowl approximate 22" left to right x 23" front to back x approximately 20" deep rated 213 maximum psi at 302 degrees F. Cored masticator blades, front rotor 27 rpm, rear rotor 23 rpm, geared one end, top air operated pressure cap, air operated dust hood, motorized bowl screw tilt with a 2.2kw motor. Mixer driven by a 75kw (100hp), 3/60/480 volt, 1760 rpm motor thru a reducer no ratio. Includes an operator panel and control panel. Mounted on a base. Serial # 916. Built 1956.

Stock# 50697012

Used- Toshin Double Arm Dispersion Mixer, Model TDS75-100MF, Stainless Steel. 75 Liter (19.8 gallon) working capacity, 150 liter (39.6 gallon) total. Jacketed bowl approximate 22" left to right x 23" front to back x approximately 20" deep rated 213 maximum psi at 302 degrees F. Cored masticator blades, front 27 rpm, rear 23 rpm, geared one end, top air operated pressure cap, air operated dust hood, motorized bowl screw tilt with a 2.2kw motor. Mixer driven by a 75 kw (100 hp), 3/60/480 volt, 1760 rpm motor thru a reducer ratio 20.272 to 1. Includes an operator panel and control panel. Mounted on a base. Serial # 1298. Built 1987.

Stock# 88232

Used- (Reconditioned) Baker Perkins Model #15 Double Arm Sigma Blade Mixer, 100 gallon capacity. Steel jacketed bowl 33" left to right x 38" front to back x 30" deep, geared on one end. New 30 hp drive consisting of a torque arm reducer and TEFC motor. Tilt discharge with new hydraulic power pack. All unitized on a common base. (Delivery 8-12 weeks.)

Stock# 88239

Used/Reconditioned- Baker Perkins Double Arm Sigma Blade Mixer, 100 Gallon Capacity, Model #15. Carbon steel jacketed bowl 33" left-right x 38" front-back x 30" deep. Driven by a 30 hp, 3/60/230/460 volt, 1770 rpm motor with speed reducer. Hydraulic tilt, power pack driven by a 7.5 hp motor. Mounted on a painted carbon steel base. Serial # 41090.

Stock# 41785006

Used- Winkworth Z-blade Mixer, Model 43 Z SS DD JKTD, Stainless Steel and mild steel jacketed, 119 gallon (450 liter), 43" x 37.8" x 29" (1090 mm x 959 mm x 737 mm). With hydraulic tilt discharger driven by a 20 hp/15 kW geared drive. Size 10' x 5.3' x 3.9' (3000 mm x 1600 x 1100 mm) tall when closed and 7.2' (2200 mm) when open.

Stock# 11252072

Used- Aaron Process Vacuum Drying Sigma Mixer. Model MBG200-125. All stainless steel construction. Working capacity is 200 Gallons / 760 Liters. Total capacity is 390 Gallons / 1476 Liters. All parts are insulated and sheathed with 304 stainless steel and polished to 150 - 180 grit finish. Mixing/drying chamber is jacketed and rated for 200 PSI at 450 deg. F / -20 deg. F., ASME code constructed. Mixing chamber measures 48" x 40" x 44" deep and includes (2) 6" diameter flanged discharges. Blades are overlapping double nabben blades and driven by 125 hp motor thru heavy duty gearbox. Equipment was manufactured in 2000 and is in very good condition. Previously used in clean room type environment. Complete with control panel and unitized on heavy duty frame. Complete with main control panel, power panel with starters and VFD's, steam-to-water heat exchanger for heating of jacket and hydraulic pump/reservoir for opening vessel lid. Also includes top mounted, stainless steel Mikro Pulsaire dust collector, Model 10-2-FV TR, rated for 117 ACM gas volume.

Stock# 44974

Used- Werner & Pfleiderer Double Arm Mixer, Model UK17, Stainless Steel Clad 200 Gallon. Sigma tangential blades, jacketed bowl (bottom only) 43" front-back x 53" left-right x approximately 36" deep. Geared both ends. Set up for hydraulic tilt 7.5 hp, 220/440V, 1750 rpm. No base, no drive.

Stock# 50059005

Used- Howard Double Arm Mixer, Approximate 200 Gallon, 304 Stainless Steel. Non-jacketed bowl approximate 50" left to right x 44-1/8" front to back x 34-1/2" deep. Overlapping sigma blades set up for hydraulic drive, no power pack. Dual ram hydraulic tilt, top safety grate. Includes a control. Mounted on a stainless steel frame. Serial# H3649-2, built 2001.

Stock# 50059006

Used- Howard Double Arm Mixer, Approximate 200 Gallon, 304 Stainless Steel. Non-jacketed bowl approximate 50" left to right x 44-1/8" front to back x 34-1/2" deep. Overlapping sigma blades set up for hydraulic drive. Dual ram hydraulic tilt, top safety grate. Includes a control panel. Mounted on a stainless steel frame. Serial# H3649-3, built 2001.

Stock# 50697008

Used- Inoue Seisakusho Double Arm Mixer, Model KHD-1600S, Stainless Steel. 900 Liter (237 gallon) working capacity, 1600 liter (422 gallon) total. Carbon steel jacketed bowl approximate 48" left to right x 52" front to back x approximately 36" deep, rated 42 psi. Cored tangential sigma blades, rear blade speed 34 rpm, front blade speed 18.5 rpm, geared one end. Bolt on domed top cover suitable for vacuum, dual bottom outlets. Mixer driven by a 55 kw (75hp), 3/60/480 volt, 880 rpm motor thru a SKK reducer, ratio 25.6 to 1. Includes an operator and control panel. Mounted on a base. Serial # 9522. Built 1979.

Stock# 50697009

Used- Inoue Seisakusho Double Arm Mixer, Model KHD-1600S, Stainless Steel. 900 Liter (237 gallon) working capacity, 1600 liter (422 gallon) total. Carbon steel jacketed bowl approximate 48" left to right x 52" front to back x approximately 36" deep, rated 42 psi. Cored tangential sigma blades, rear blade speed 34 rpm, front blade speed 18.5 rpm, geared one end. Bolt on domed top cover suitable for vacuum, dual bottom outlets. Mixer driven by a 55 kw (75 hp), 3/60/480 volt, 880 rpm motor thru a SKK reducer, ratio 25.6 to 1. Includes an operator and control panel. Mounted on a base. Serial # 9521. Built 1979.

Stock# 50697010

Used- Toshin Double Arm Mixer, Model TKB1600-100, 304 Stainless Steel. 1000 Liter (264 gallon) working capacity, 1600 liter (422 gallon) total. Carbon steel jacketed bowl approximate 48" left to right x 52" front to back x approximately 38" deep. Cored tangential SUS13 stainless steel sigma blades, rear blade speed 34 rpm, front blade speed 18.5 rpm, geared one end. Domed top cover suitable for vacuum with hydraulic pedestal stand with a 3.7 kw power pack. Mixer driven by a 55 kw (75 hp), 3/60/480 volt, 890 rpm motor thru a Sumitomo reducer, ratio 15.996 to 1. Bottom discharge. Includes an operator and control panel. Mounted on a base. Serial # 2947. Built 2008.

Stock# 50640003

Used- Laska Industrial Vacuum Double Arm Mixer, Model ME 1000 ZNVUX, Stainless Steel. Mixing hopper 1000 liters (264 gallon), maximum filling quantity 800 kg (1763 pounds). Non-jacketed hydraulic tilting bowl approximate 49" left to right x 41-1/2" front to back x 28-1/2" deep, overlapping sigma blades approximate output 29 rpm. Domed tilt back top cover suitable for vacuum. Mixer driven by an approximate 22kw motor with triple chain. Serial# 13240, built 2009. Includes a control panel with drive, operator panel, Laksa Mast loader, model BA 24, serial# 13241, built 2009, (3) stainless steel totes, and a tote discharge cradle.

Stock# 10276021

Used- Strommen Double Arm Mixer, Type Universal Mixer. Stainless Steel on product contact parts. 264 gallons (1000 liter) working capacity. Driven by a 53.6 hp (40 kW) motor, powered via 1.5 hp (1.1 kW) hydraulic unit. Frame mounted.

Stock# 63522

Used- Werner & Pfleiderer Double Arm Mixer, Type UK1500 X 55. 316 stainless steel construction. Total capacity is 595 gallons (2250 liters). Working capacity is 400 gallons (1500 liters). 5'6" long x 4'9" wide x 4'2" deep (1690 mm long x 1450 mm wide x 1280 mm deep) mixing bowl. Masticator blades. 7-3/4" shafts. Double jacketed. 2'3" x 1'8" bottom dump outlet. (1) 112.5 hp/75 kw, 380 volt/50 cycle/3 ph XP motor driving a PIV gearbox, Type B355-11V. (1) Busch lube system.

Stock# 63523

Used- Werner & Pfleiderer Double Arm Mixer, Type UK1500 X 55. 316 Stainless Steel construction. Total capacity is 595 gallons (2250 liters). Working capacity is 400 gallons (1500 liters). 5'6" long x 4'9" wide x 4'2" deep (1690 mm long x 1450 mm wide x 1280 mm deep) mixing bowl. Geared one end, cored masticator blades. 7-3/4" shafts. Double jacketed. 2'3" x 1'8" bottom dump outlet. Flat one piece cover with (1) 32" x 34" hydraulic door, (2) 2", (2) 4" x 8" doors, (3) 8" openings. (1) 112.5 hp/75 kw/380 volt/50 cycle/3 ph XP motor driving a PIV gearbox, Type B355-11V. One (1) Busch lube system.
