Used Sysco Machinery Shear; Model USA FH2663-30M; Cutting Force 28 Tons (25 Metric Tons) Cutting Stroke 7.1" (180 mm) / 9.8" (250mm) Maximum Daylight 9.1" (230mm) / 11.8" (300mm) / (Others Available) Machine Bed (20" D x 49.2"-63" W) / (500mm D x 1250-1600mm W) Main Motor 3 HP Gross Weight TBD Series FH - 25 Tons A four-post hydraulic press producing 25 metric (28 U.S.) tons of cutting force, with two cylinders mounted over cross members linked end to end with torsion bars. This mechanical balancing system ensures that the maximum cutting force of the press can be delivered across the entire cutting area of the machine, and keeps the bed and bridge parallel even under asymmetrical (unbalanced) loads, which, in turn, reduces mis-cuts and damaged parts and provides for longer tool and pad life. This hydraulic press can deliver its total force during the entire down stroke.
Used Sysco Machinery Shear; Model USA FH2663-30M; Cutting Force 28 Tons (25 Metric Tons) Cutting Stroke 7.1" (180 mm) / 9.8" (250mm) Maximum Daylight 9.1" (230mm) / 11.8" (300mm) / (Others Available) Machine Bed (20" D x 49.2"-63" W) / (500mm D x 1250-1600mm W) Main Motor 3 HP Gross Weight TBD Series FH - 25 Tons A four-post hydraulic press producing 25 metric (28 U.S.) tons of cutting force, with two cylinders mounted over cross members linked end to end with torsion bars. This mechanical balancing system ensures that the maximum cutting force of the press can be delivered across the entire cutting area of the machine, and keeps the bed and bridge parallel even under asymmetrical (unbalanced) loads, which, in turn, reduces mis-cuts and damaged parts and provides for longer tool and pad life. This hydraulic press can deliver its total force during the entire down stroke.
