Used Homogenizers

Stock# 48665003

Used- Cherry-Burrell/Waukesha Homogenizer, Model 1000, 316 Stainless Steel. Capacity 350 gallons per hour, 5000 psi, dual stage homogenizing valve assembly. Driven by a 20 hp, 3/60/230/460 volts, 1760 rpm motor, with dodge speed reducer, 5.67 to 1 ratio. Mounted on a painted carbon steel frame. Serial# 218556 98.

Stock# 49418001

Used- Mizuho Industries Vacuum Emulsifying Homogenizer System, Model VT-1-1000, Stainless Steel. Consisting of (1) 1000 Liter (264 gallon) reactor, product contact 316L stainless steel, jacket 304 stainless steel, approximate 40" diameter x 48" straight side, dished top and bottom, no ratings. Opening top cover: 6" x 4" w/ sight glass, (3) 3", (3) 2", 1.5", 1" Triple agitation system: (1) anchor style side and bottom scraper, driven by a 7.5hp, 3/60/460 volt, 1185 rpm motor thru gear box, 1/25 ratio (Requires scrapers). (1) Paddle mixer, (6) inner paddles approximate 7-1/2" x 4" x 1/2" thick, driven by a 3hp, 3/60/480 volt, 1190 rpm thru gearbox 1/25 ratio. (1) Ultra Mixer, driven by 30hp, 3/60/480 volt, 3565 rpm motor. Top cover hydraulic lifting system with hydraulic pack driven by 5.5 kW motor. Auto tilting discharge, driven by 1.5hp motor, also center bottom outlet discharge. (1) Mizuho temperature control unit, model H.C.-1000, serial# 39-1156-U, built 1999, 3/60/460 volt. Consists of (1) jacket tank, approximate 48" diameter x 56" straight side, flat top and bottom, (3) separate internal coils, agitator with 3-blade turbine. (1) Circulation pump. (2) Control panels, #1" with (2) temperature controllers, (1) programmable temperature controller, Allen Bradley 1771-P7 PLC, 3" with (3) ABB ACS 600 drives for agitation. Includes gould centrifugal pump, (2) approximate 40 gallon plastic tanks, thermoscientific model 3510 lab cabinet, hydrofogger, Nash 5hp vacuum pump, Welch 1/2hp vacuum pump. System serial# 39-1156-H, built 1999.

Stock# 49670002

Used- APV Gaulin Homogenizer, Type 200-3.0P. Approximately 7,936 gallon (30000 liter) per hour at 3,150 PSI (210 bar). Driven by a 300 hp/200Kw, 3Ph/50cycle/380volt, motor. 3-piston compression block with valve. Stainless steel covers and access door. Mounted on carbon steel frame. Over all dimensions 9’8” (3000 mm) long x 7’8” (2400 mm) w x 5’4” (1650 mm) high. Weight 7.6 tonnes. Built 1999. Includes control panel. Used on milk in the dairy industry.

Stock# 49670003

Used- APV Gaulin Homogenizer, Type G 132Q-2.5P. Approximately 5,820 gallon (22000 liter) per hour at 2,625 PSI (175 bar). Driven by a 198HP/132Kw, 3Ph/50cycle/380volt, motor. 5-Piston compression block with valve. Stainless steel covers and access door. Mounted on carbon steel frame. Over all dimensions 93" (2860 mm) long x 61" (1890 mm) w x 54" (1650 mm) high. Weight 6 tonnes. Built 2005. Includes control panel. Used on milk in the dairy industry.

Stock# 44987001

Used- B.E.E. International Ultra High-Pressure Homogenizer, Model DeBEE2000. 316 Stainless steel on product contact areas. Maximum flow rate 1 liter per minute (15.85 gallons per hour) depending on pressure and viscosity of product, maximum operating pressure 3100 kgf/cm2 (45,000 psi), maximum product inlet temperature 80 degrees C. (176 F.). 1" Inlet with hopper, tube outlet. 7.5 kw (10 hp), 400/3/50 hydraulic motor. Includes Modular Homogenizing Cell Type ECD2+EC4, and control panel with a PLC controller. Mounted on wheels. Serial# 2521. Built 2004.

Stock# 48882001

Used- APV Homogenizer, Type: LAB100-6TBSX, 304 Stainless Steel. Capacity 31.7 gallons per hour (120 L/H), 5801 psi (400 bar) maximum pressure. 3 piece valve housing, single stage homogenizing valve assembly. Approximately 1" inlet/outlet. Driven by a 2.2 kW motor. Serial# 94L34421. Incomplete/parts needed.

Stock# 49620013

Used- Gaulin Homogenizer, Model 160 M6 10 TBS, Stainless Steel. Capacity 160 gallons per hour, 10000 psi maximum. Single stage homogenizing valve assembly. Tapered removable seat ball valves, spring loaded. Serial# 281-8529.

Stock# 48968003

Used- GEA Niro Soavi Homogenizing High Pressure Pump, Type NS3075P. Approximate 700 gallons per hour at 10,000 psi. Maximum pressure 70 MPa (10,152 psi). Driven by a 150 HP, 3/60/460 volt, 1785 rpm motor. 3-Piston compression block with valve. Includes 3/4 HP hydraulic pump. Stainless steel covers. Mounted on carbon steel frame. Serial# 4586. Built 2002. (For use with Spray Dryer).

Stock# 47316001

Used- Soavi B. & Figli SPA Homogenizer, Model CA/60R, 2205 Stainless Steel. Rated 5000 liters per hour (1320 gallons) at 175 stroke per minute, maximum pressure 150 bar (2175 psi). (3) Pistons 55 x 345mm. Driven by a 22kw, 3/50/380 volt, 1455 rpm motor. Serial# 1791.

Stock# 45053105

Used- Rannie Homogenizer, Model 50.120H, 2205 Stainless Steel. Capacity 7400 Liters per hour (1954.9 Gallon), maximum homogenizing pressure 552 bar (8004.2 psi). Driven by a 200 hp, 460 volt, 885 rpm motor. 5200 Hours on meter. 50mm Plunger, 120mm stroke. Approximate 900 rpm crank speed. Serial# 1.89.235. Built 1989.

Stock# 49620014

Used- Niro Soavi Homogenizer, Model NS3037-H, Stainless Steel. Approximate capacities 3170 gallons per hour at 1500 psi to 211 gallons per hour at 22,000 psi. Driven by a 37kw motor. Serial# 2437, built 1993. Includes a feed skid with an Alfa Laval GHPD positive displacement pump, model SRU-4NLS, serial# 02-5-10008A, driven by a 5hp, 3/60/230/460 volt, 1725 rpm gear motor, ratio 4.5 to 1, (1) L.J. Star bubble trap, (1) Allegheny Bradford heat exchanger. Shell & tubes rated 150 psi at -20 to 350 degrees F, serial# 10923-1-1, built 2002, and (2) control panels. Both pieces mounted on casters.

Stock# 49085025

Used- APV Rannie 175 Homogenizer, Model BT-58-175, Stainless Steel. Maximum capacity 14,200 liters (3751 gallons) per hour at 500 bar (7251 psi) maximum pressure. Two stage homogenizing valve assembly, plunger size 58mm. Approximate 2" inlet & outlet. Driven by an approximate 250 kw motor. Includes an Allen-Bradley PLC. Mounted on a carbon steel frame. Serial# 1-99-115, built 1999.

Stock# 46078005

Used- Cherry Burrell Superhomo Homogenizer, Model SS-5000-TGR, 304 Stainless Steel. Approximate capacity 1500-5000 gallons per hour. Single stage valve. Driven by 125 hp, 3/60/460 volt, 1780 rpm XP motor with reducer. Mounted on carbon steel frame.
