Stock No.: 54129003
Used Tria TR 120-49 High-Capacity Granulator | 1,200 kg/hr | 490mm Rotor | 50 HP | Sound-Insulated | Water-Cooled Chamber
Used Tria TR 120-49 High-Capacity Granulator | 1,200 kg/hr | 490mm Rotor | 50 HP | Sound-Insulated | Water-Cooled Chamber. 1200mm rotor width. Approx. 970mm W 120mm H feed opening, rear trap-door feed system. Open rotor w. (5) rows of (2) knives (10 total). (2) front and (2) rear stator knives, (4) total. Water cooled cutting chamber. Large discharge screen. Enclosed in sound-insulated steel enclosure w/ hinged access doors. 50 HP (approx. 37 kW) drive motor, 3/60/460-480V.
-
ManufacturerTria
-
ModelTR-120-49
-
CategoryPlastics Equipment
-
SubcategorySize Reduction - Grinders and Granulators
Used equipment facts about this machine
Manufacturer Information
🏭 Manufacturer Information
-
Manufacturer: Tria
-
Model: TR 120-49
-
Type: High-Capacity Industrial Granulator
-
Condition: Used
⚙️ Product Description
This Used Tria TR 120-49 Granulator is a heavy-duty size-reduction system engineered for high-volume processing of plastics, film, sprues, runners, sheet, and thermoformed materials. With throughput capability up to 1,200 kg/hr (depending on material and screen size), it is ideal for demanding industrial environments.
The granulator features a 490 mm rotor diameter and 1,200 mm rotor width, with an open-rotor design containing 5 rows of 2 knives (10 knives total). The cutting chamber includes 4 stator knives (2 front, 2 rear) for efficient, clean cuts.
A water-cooled cutting chamber supports thermal stability during continuous operation, while the rear trap-door feed system makes it well-suited for thermoforming scrap. The unit is enclosed in a sound-insulated steel enclosure with hinged access doors for quieter operation and easier maintenance.
Powered by a robust 50 HP (≈37 kW) motor, this granulator is designed for industrial reliability and consistent particle-size reduction.
📏 Specifications
-
Model: TR 120-49
-
Rotor Diameter: 490 mm
-
Rotor Width: 1,200 mm
-
Feed Opening: Approx. 970 mm W × 120 mm H
-
Rotor Type: Open rotor
-
Rotor Knives: (5) rows × (2) knives = 10 knives
-
Stator Knives: (2) front + (2) rear = 4 total
-
Throughput Capacity: Up to 1,200 kg/hr
-
Cutting Chamber: Water-cooled
-
Discharge: Large throughput-optimized screen
-
Enclosure: Fully sound-insulated steel housing with hinged doors
-
Drive Motor: 50 HP (approx. 37 kW)
-
Electrical: 3/60/460–480V
🧩 Applications
-
Plastics recycling
-
Film and sheet scrap reduction
-
Thermoforming line integration
-
Injection molding & extrusion waste
-
Pipe, profile, and purging granulation
-
Recycling plants
-
Industrial compounding operations
-
Packaging material reduction
-
Fiber & light-material granulation
-
Regrind production
⚗️ What Might This Be Used For
-
Reducing plastic waste into uniform regrind
-
Feeding downstream extrusion or compounding systems
-
Inline thermoforming scrap granulation
-
High-capacity plastics recycling lines
-
Energy-efficient size reduction with water-cooled chamber
🧱 Materials It Can Process
-
PET, PP, PE, PS
-
Film, sheet, web trim
-
Thermoformed scrap
-
Sprues / runners
-
Engineering plastics
-
Nylon & polycarbonate (with proper setup)
-
Soft and rigid plastics
-
Packaging plastics
-
Flexible materials
-
Recycled commodity plastics
