Used 2008 Wanner E 45x80 Heavy-Duty Plastic Granulator – 40 HP, 1,760 Lb/Hr Capacity

Manufacturer Information

Wanner

Wanner manufactures granulators and industrial size-reduction equipment used in plastics processing, recycling, injection molding, extrusion, and production-scrap recovery applications. Granulators of this type are designed to reduce compatible plastic scrap into smaller material for recycling, reprocessing, handling, or disposal.

This Wanner Type E 45x80 was manufactured in 2008 and combines a 450 mm diameter x 800 mm wide cutting section, 40 HP drive, up to 450 RPM operating speed, and soundproof enclosure.

Description

Available for sale is a used Wanner Granulator, Type E 45x80, manufactured in 2008.

The granulator features an approximately 450 mm (17.7") diameter x 800 mm (31.5") wide cutting section and operates at a stated maximum speed of 450 RPM.

Power is provided by a 30 kW (40 HP) belt-driven motor designed for 400V, 50 Hz, 3-phase electrical service.

The Wanner E 45x80 has a stated maximum processing capacity of approximately 800 kg/hr (1,760 lb/hr), depending on the product and operating conditions.

This unit is installed within a soundproofed enclosure, which can help reduce operating noise in plastics processing and recycling environments.

Overall dimensions are approximately 1,000 mm x 2,250 mm x 2,100 mm high (39.4" x 88.6" x 82.7" high). Empty weight is approximately 2 metric tonnes (4,409 lb).

Specifications

Typical Applications

• Plastics recycling
• Industrial size reduction
• Injection molding scrap recovery
• Extrusion scrap processing
• Production waste reduction
• Runner and sprue granulation
• Regrind production
• Plastic component granulation
• Manufacturing scrap recovery
• In-house material recycling
• Polymer processing
• Production reject reduction

Products & Materials This Granulator Could Be Used For

• Injection molded plastic parts
• Plastic runners
• Sprues
• Plastic production rejects
• Extrusion scrap
• Plastic profiles
• Thermoplastic components
• Plastic containers
• Polymer scrap
• Plastic sheets and offcuts
• Compatible rigid plastic waste
• Other materials suitable for granulation

Actual capacity and suitability depend on material type, dimensions, density, toughness, feed rate, knife condition, screen configuration, and required finished particle size.

Frequently Asked Questions

• What is the maximum capacity of this Wanner granulator? The stated maximum capacity is approximately 800 kg/hr (1,760 lb/hr), depending on the material and operating conditions.
• How much horsepower does the E 45x80 have? It is powered by a 30 kW (40 HP) belt-driven motor.
• What is the maximum operating speed? The machine has a stated maximum operating speed of 450 RPM.
• Does this granulator include noise reduction? Yes. The machine is installed in a soundproofed enclosure designed to help reduce operating noise.
• What electrical service is required? The motor is specified for 400V, 50 Hz, 3-phase power. Electrical compatibility should be confirmed before installation, particularly at facilities using 60 Hz service.
• Can Aaron Equipment assist with shipping and logistics? Yes. Aaron Equipment can assist with loading coordination, domestic and international freight, customs documentation, and logistics planning. With an empty weight of approximately 2 metric tonnes, appropriate lifting and freight arrangements can be coordinated.
