Corrosion Resistant 30,000 Gallon FRP Tank | Augusta Fiberglass Process Storage

Manufacturer: Augusta Fiberglass
Equipment Type: FRP Storage Tank / Fiberglass Process Tank
Capacity: 30,000 Gallons
Condition: Unused
Year Built: 2015

Description

Unused Augusta Fiberglass 30,000 gallon FRP storage tank designed for industrial liquid storage and process applications requiring corrosion-resistant fiberglass construction. Engineered for atmospheric service, this large-capacity tank is suitable for chemical processing, water treatment, industrial liquid storage, and corrosive fluid handling operations.

The tank features fiberglass reinforced plastic (FRP) construction with a corrosion-resistant liner system consisting of a surfacing veil and 100 mil “C” glass corrosion liner. Manufactured using Resin 9102, Hetron 922, or equivalent materials, the vessel is designed for fluids with a specific gravity up to 1.1 and operating temperatures up to 110°F.

The tank includes numerous process nozzles, internal baffles, side manways, siphon drains, and a carbon steel top bridge for agitator mounting. The exterior is finished in gray with UV inhibitors for outdoor durability and weather resistance.

Specifications

• Manufacturer: Augusta Fiberglass
• Type: FRP storage tank
• Capacity: 30,000 gallons
• Construction: Fiberglass reinforced plastic (FRP)
• Condition: Unused
• Year Built: 2015

Dimensions

• Diameter: 13’ 6”
• Straight Side Height: 28’

Design Conditions

• Internal Rating: Atmospheric
• Maximum Temperature: 110°F
• Specific Gravity Rating: 1.1

Resin & Liner Construction

• Resin: 9102, Hetron 922, or equal
• Surfacing Veil: (1) ply
• Corrosion Liner: 100 mil “C” glass
• Exterior Color: Gray with UV inhibitors

Tank Design

• Flat top
• Flat bottom
• (4) internal baffles
• Carbon steel agitator bridge

Top Connections & Fittings

• (1) 24” manway
• (1) 8” center agitator nozzle
• (1) 6” vent
• (3) 4” nozzles
• (2) 6” nozzles

Side Connections & Drains

• (1) 24” side bottom manway
• (1) 6” side top overflow outlet
• (2) 6” siphon drains
• (1) 8” siphon drain
• Siphon drains positioned approximately 2” from tank floor
• (3) 4” side bottom outlets

Applications

Ideal for chemical storage, water treatment, industrial process liquids, and corrosive material handling applications.
