Used 1,000-4,999 Gallon Stainless Steel Reactors

Stock# 10128098

Used Vendome 1,000 Gallon Stainless Steel Jacketed Processor | Scrape Agitator | Dual-Zone Heat | 100 PSI. It has a dished bottom and a domed top. The jacket is rated for 100 psi @ 338F and the shell is rated for atmospheric pressure. National board # 898. Vendome serial number 2004-01Z-1. Vessel is 72" OD x 63" straight side. Jacket has two heating zones with 2" inlet and outlet on each zone. Bottom has 3" bent tri- clamp nozzle. Top nozzles are: 18" hinged manway, 6" wide x 18" long nozzle, 14" flanged nozzle, three 3" tri clamp, six 2" tri clamp and one 1" tri clamp. Tank has a spray ball inside. The side scraping agitator is driven by a 5 hp gear reduced drive. 230/460 vac 3 ph electric power required. Tank stands on four legs. Some cosmetic denting to the insulation skin otherwise it appears to be in good shape.

Stock# 10151497

Used Alloy Fabricators Approximately 1,000 Gallon 304 Stainless Steel Reactor with Coils. 60" diameter x 72" straight side; Dished top and bottom; Internal rated 33 psi at 335 degrees F; Coils rated 85 psi at 335 degrees F; 1 hp axial type agitator, 304 stainless steel, Single hub with 4 blades, 26 1/2" dia; 18" dia. 2 blade radial flow at bottom Serial # 1-142A; Built 1991.

Stock# 11059324

Unused- 1000 Gallon LEE Sanitary Jacketed Kettle with sweep/scrape mixer. Model 1000 U7S. Internal rated 60 PSI/Full Vacuum @ 250F. Jacketed rated 100 PSI @ 338 Deg..F. MDMT Internal -20 Deg.F. @ 60PSI, MDMT Jacketed -20 Deg.F. @ 100 PSI. Driven by 7.5 HP, 1170 rpm, 230/460 volt motor into Nord Gear reducer with 27 RPM output. Also, has 6" Flange to accommodate higher speed mixer (not included). Equipped with (3) spray balls for CIP and flush mount outlet valve. (UNUSED on Manufacturer's Skid, Date of Manufacture 2022). Drawings on file. 5'6" Diameter x 6' Height.

Stock# 10128097

Used Vendome 1,400 Gallon Stainless Steel Processor | Dual Agitation | Jacketed | 100 PSI | . The bottom and the sides are jacketed. The dimple jackets are rated at 100 psi @ 338F. This unit is equipped with side scrape agitation (5 hp) and a 50 hp top entering homogenizing mixer. 230/460 vac 3 ph electric power required. There is one adjustable baffle inside. The vessel is 84" diameter x 60" straight side with a dished top and bottom. Bottom jacket nozzles are two- 2" RFSO flanges. Side jacket has four-2" RFSO flanges as in/out flanges. Bottom has one 3" tri-clamp nozzle. Top has one- 18" hinged lid manway, one 6" x 18" rectangular inlet, one 6" tri-clamp nozzle, one- 4" sightglass, three-3" nozzles, five- 2" nozzles, and one 1" nozzle. This unit stands on 4 stainless steel pipe legs. National board #299, Serial# 2004-05Z-1. The skin over the jacket has some dents and repairs. The jackets passed our hydro tests.

Stock# 11585104

Used APV Crepaco approx 1500 gallon T316L stainless steel dimple jacket reactor. Internal rated 60 psi @ 350 degrees F. T304 stainless steel Dimple Jacket rated 75 psi @ 350 degrees F. 72" diameter. Dished top. Dished bottom. Bridge mounted agitator. 10 HP. Sweep scraper agitator on sidewall and bottom head. Baffle. NB 9520, Serial# K1972.

Stock# 53849002

Used Sharpsville Container 2,000 Gallon Reactor / Tank (V610), 316L Stainless Steel, Vertical. 78" OD x 78" Straight side. Dished top and bottom. Internal rated 25psi/FV at 200 degrees F. Sidewall jacket rated 50psi at 150 degrees F. Openings top: 24" manway, 12" center, 6", 4", (2) 3", (7) 2". 4" Center bottom outlet. 304 Stainless steel shroud with 12" annulus filler with chloride free insulation. Mounted on (4) stainless steel legs. Serial# 9230, National Board# 8230, Built 2016. Including Circulation system and APV Pump.

Stock# 53849003

Used Sharpsville Container 2,000 Gallon Reactor (V700), 316L Stainless Steel, Vertical. 78" OD x 78" Straight side. Dished top and bottom. Internal rated 25psi/FV at 200 degrees F. Sidewall jacket rated 50psi at 150 degrees F. Openings top: 24" manway, 12" center, 6", 4", (2) 3", (7) 2". 4" Center bottom outlet. 304 Stainless steel shroud with 12" annulus filler with chloride free insulation. Mounted on (4) stainless steel legs. Serial# 9232, National Board# 8232, Built 2016. Including Circulation system and APV Pump.

Stock# 10749128

Used 304L Stainless Steel 1st Stage Crystallizer. 3000 Gallons Capacity, 6'6" diameter x 9'6" T/T. 304L Stainless Steel Shell Material, 304L Stainless Steel (Sanitary Polished Internal) Jacket Material. Vertical. 43.5 psi @ 203 deg. F. both shell and jacket. Mfg. by SRI (Special Restvrijstaal Industrie BV) Designed by GEA Messo PT. Built in 2013. Flanged bolted dished top and welded dished bottom heads. On skirt and leg supports. Conventional jacket type. With center top mounted, internal sweep side scraper and internal bottom mounted shaft steady bearing agitator. Nozzles are sanitary clamped. ALLOY : S; GALLONS : 3000; DIA/WIDTH (FT'IN") : 6'6"; LENGTH (FT'IN") : 9'6"; SHELL PSI : 43.5; SHELL TEMP DEG. F : 203; V/H : V; SHELL MATERIAL : 304LSS; CODE : NB; WALL : 15/32"; JKT/COIL PSI : 43.5; JKT/COIL TEMP DEG. F : 203; JKT/COIL MATERIAL : 304LSS SANITARY POLISHED INTERNAL; AGITATED Y/N : Y; TOP HEAD : FLANGED BOLTED DISHED; BOTTOM HEAD : WELDED DISHED;

Stock# 10749131

Used 3000 Gallon Stainless Steel 1st Stage Crystallizer, 6'6" diameter x 9'6" T/T. 304L Stainless Steel Shell Material, 304L Stainless Steel (Sanitary Polished Internal) Jacket Material. Vertical. 43.5 psi @ 203 deg. F. both shell and jacket. Mfg. by SRI (Special Restvrijstaal Industrie BV) Designed by GEA Messo PT. Built in 2013. Flanged bolted dished top and welded dished bottom heads. On skirt and leg supports. Conventional jacket type. With center top mounted, internal sweep side scraper and internal bottom mounted shaft steady bearing agitator. Nozzles are sanitary clamped. ALLOY : S; GALLONS : 3000; DIA/WIDTH (FT'IN") : 6'6"; LENGTH (FT'IN") : 9'6"; SHELL PSI : 43.5; SHELL TEMP DEG. F : 203; V/H : V; SHELL MATERIAL : 304LSS; CODE : NB; WALL : 15/32"; JKT/COIL PSI : 53.5; JKT/COIL TEMP DEG. F : 203; JKT/COIL MATERIAL : 304LSS SANITARY POLISHED INTERNAL; AGITATED Y/N : Y; TOP HEAD : FLANGED BOLTED DISHED; BOTTOM HEAD : WELDED DISHED;

Stock# 10749133

Used 1st Stage Crystallizer. 3000 gallons, 6'6" diameter x 9'6" T/T. 304L Stainless Steel Shell Material, 304L Stainless Steel (Sanitary Polished Internal) Jacket Material. Vertical. 43.5 psi @ 203 deg. F. both shell and jacket. Mfg. by SRI (Special Restvrijstaal Industrie BV) Designed by GEA Messo PT. Built in 2013. Flanged bolted dished top and welded dished bottom heads. On skirt and leg supports. Conventional jacket type. With center top mounted, internal sweep side scraper and internal bottom mounted shaft steady bearing agitator. Nozzles are sanitary clamped. ALLOY : S; GALLONS : 3000; DIA/WIDTH (FT'IN") : 6'6"; LENGTH (FT'IN") : 9'6"; SHELL PSI : 43.5; SHELL TEMP DEG. F : 203; V/H : V; SHELL MATERIAL : 304LSS; CODE : NB; WALL : 15/32"; JKT/COIL PSI : 43.5; JKT/COIL TEMP DEG. F : 203; JKT/COIL MATERIAL : 304LSS SANITARY POLISHED INTERNAL; AGITATED Y/N : Y; TOP HEAD : FLANGED BOLTED DISHED; BOTTOM HEAD : WELDED DISHED;

Stock# 11059312

Used Ward- 3000 Gallon Alloy 20 Reactor with half pipe jacket. Shell is ALLOY 20 (SB-463) rated 85 psi/Full Vacuum @ 350 Deg.F. Jacket rated 150 psi/Full Vacuum @ 350 to (-20) Deg.F.. 98" Dia. x 6'5" T/T. Top mounted Lightnin model 85-S-25, 25 HP mixer with 84 rpm output speed. Shell is .375" thick. Heads are .4375" thick. Last used as hydrolysis reactor. Drawings available.

Stock# 11059313

Used Jacketed 3000 Gallon Alloy 20 Reactor, Manufactured by Ward. Shell is ALLOY 20 (SB-463) rated 85 psi/Full Vacuum @ 350 Deg.F. Jacket rated 150 psi/Full Vacuum @ 350 to (-20) Deg.F.. 98" Dia. x 6'5" T/T. Top mounted Lightnin model 85-S-25, 25 HP mixer with 84 rpm output speed. Shell is .375" thick. Heads are .4375" thick. Last used as hydrolysis reactor. Drawings available.

Stock# 11059314

Used 3000 Gallon Alloy 20 Reactor, Made by Ward, with half pipe jacket. Shell is ALLOY 20 (SB-463) rated 85 psi/Full Vacuum @ 350 Deg.F. Jacket rated 150 psi/Full Vacuum @ 350 to (-20) Deg.F.. 98" Dia. x 6'5" T/T. Top mounted Lightnin model 85-S-25, 25 HP mixer with 84 rpm output speed. Shell is .375" thick. Heads are .4375" thick. Last used as hydrolysis reactor. Drawings available.
