Unused- Nash Main Condenser Exhaust System, Model AT-3400E
Unused- Nash Main Condenser Exhaust System, Model AT-3400E, Carbon Steel. Consists of: (1) Nash 2 stage liquid ring vacuum pump, model AT-3004E, test #77U5205, 435 rpm. Approximately 28.5" maximum vacuum, 2590 cfm. Driven by 200 hp, 3/60/230/460 volt, 1775 rpm motor thru a Falk gear drive, ratio 4.095 to 1. (1) Inlet manifold, (1) first stage discharge manifold, (1) second stage inlet and discharge manifold, (1) separator tank, and (1) 3 hp centrifugal pump. Skid mounted.
