Used Twin Screw Pelletizing Lines

Stock# 11453370

Used- Leistritz Twin Screw Pelletizing Line, Model Micro18/GGC-40D. 18 mm screws, counter rotating screws, 40:1 l/d, 500 rpm screw speed. Electrically heated, water cooled barrel, 2.3 kw, 210/260 volt, 2950 rpm dc motor with SCR controller. (8) barrel sections with (1) jacketed feed, (1) vented, (1) vented and plugged, (5) non vented barrel sections, on board control panel with (10) Eurotherm controllers. 10" wide x 180" long cooling conveyor, Beta Lasermike, Model 135-325. Built 2003, Randcastle strand pelletizer, model RCP-4.0, 4" wide helical rotor, pull rolls. Built 1999.

Stock# 11453371

Used- Leistritz Twin Screw Pelletizing Line, Model Micro18-GGL. 18 mm screws, counter rotating screws, 40:1 l/d, 500 rpm screw speed. Electrically heated, water cooled barrel, 2.3 kw, 210/260 volt, 2950 rpm dc motor with SCR controller. (8) barrel sections with (1) jacketed feed, (1) vented, (1) vented and plugged, (5) non vented barrel sections. On board control panel with (10) Eurotherm controllers, with (1) Ktron twin screw gravametric feeder, model K2LT20. Stainless steel construction on stand, 10" wide x 96" long cooling conveyor, Beta Lasermike, model 135-325. Randcastle strand pelletizer, model RCP-4.0, 4" wide helical rotor, pull rolls with diverter valve discharge. Built 2003.

Stock# 48419001

Used- Complete Plastics Line to Manufacture PE/PP/PET. State of the art fully automated hot wash processing and Pelletizing plant. High volume capacity for processing (60,000 lbs by hour). Equipment including: (1) Fully automated computer sorting system, (2) Avian grinder, (1) hot water boiler, (3) hot water washing system, (6) blenders, (6) dryers, (3) high volume Twin Screw Extruders with Underwater Pelletizing System. (7) High capacity Silo for in/out storage, and more.

Stock# 49786001

Used- Dr. Collin Twin Screw Pelletizing Line. Consisting of: (1) Dr. Collin twin screw extruder, Type ZK 25. 25 mm (0.98") diameter x 850 mm (33.1") long co rotating screws. 34:1 L/D, Maximum screw speed 460 rpm. Electrically heated, water cooled. 5 section barrel, (3) vented and plugged, (2) non vented barrel sections. Driven via a 22.5 hp/15 kW Knödler gearbox, Type KS-80-2-DW-21. Gearbox ratio 1:6.52. N1 3000 RPM/N2 460 rpm by an exp. motor. On board Dr. Collin operating panel. Incl. (1) Brabender single screw gravimetric feeder. Stainless steel construction on covers and stand. On 4 wheels. New year 2004. Over all dimensions: 72" long x 2 width x 62" high (2200 mm long x 640 mm width x 1900 mm high), (1) Dr. Collin cooling band, Type ABZUGSBAND, Stainless steel construction, 5.9" (150 mm) wide x 111.1" (2820 mm) long. 3 air zones. Water pressure 60 psi (4 bar), Air pressure 90 psi (6 bar). On 4 wheels, Serial # 4710-38-04, New year 2004. Overall dimensions: 96" long x 33" width x 42" high (2950 mm long x 100 0mm width x 1300 mm high). (1) Dr. Collin strand pelletizer, Type GRANULATOR, wide helical rotor, pull roll. On 4 wheels. Serial # 4130-38-04, New 2004. Overall dimensions: 33" long x 33" width x 44" high (1000 mm high x 1000 mm width x 1350 mm high). (1) Accrapak Systems Ltd pelletizer, Type 750 Series. wide helical rotor, pull roll. On 4 wheels. New year 2004. Overall dimensions: 28" long x 16" width x 44" high (850 mm long x 500 mm width x 1350 mm high). (1) Single temperature unit, STW 150/1-6-20-K5, Serial # 042217. New year 2004. (1) Tool-Temp AG cooling unit, Type TT12000H, 3 x 380-415volt/50cycle/3Ph. Serial # 24-05212-1. New 2004. (1) Rittal double door control panel 39" long 19" width x 72" high (1200 mm long x 600 mm width x 2200 mm high). New year 2004.

Stock# 49926001

Used- 26mm Coperion Mega Co-rotating Twin Screw Extruder. 1400 rpm screw speed with 30 Kw AC motor, 2650 rpm and VFD drive. 460 volt AC input. Approximate 36/1 L/D vented barrel, water cooled, with Brabender (2) gravimetric feeders. 1.89/1 gear ratio, touch screen operator control, and strand die. Downstream includes approximate 6' water trough, and BT2.5 Sheer Bay strand pelletizer. Still installed as operated until January 2019. New 2005.

Stock# 49846001

Used- Twin Screw Pelletizing Line Consisting of: Werner & Pfleiderer 40mm Twin Screw Extruder, Type ZSK40F-32-5E. Approximate 40 to 1 L/D ratio. 10 zones, 1 zone with vent port, 1 water cooled feed section, electrically heated, water cooled with closed loop system. Approximate 60" long screw, approximate 40" center line height. Driven by a 50 HP, 500 volt, 1750-2100 rpm DC motor. (1) Side feeder type ZSB-40 driven by a 1-1/2 HP motor. (1) Cumberland 4" wide strand pelletizer driven by a 3 HP motor. (1) Water bath. Control panel for main drive, barrel cooling pump, control voltage, pellet cooler, coupling, and screen changer. (1) Control panel with GE adjustable variable speed drive.

Stock# 47677001

Used- Krauss Maffei K.M. 120 mm Twin Screw Extruder (Reconditioned by Trimec 2012). Approximate 24 to 1 L/D ratio. (12) Zone top vented barrel with vacuum pump electrically heated air cooled. Water cooled feed throat with a 2.2 kW dosing feeder. Extruder driven by a 62 kW, 308 volt, 2600 rpm motor. Includes a control panel with temperature controllers, approximate 39-1/2" centerline height. (1) Approximate 6-1/2" diameter hydraulic screen changer with a cart and 1.5 kW hydraulic power pack. (1) Hot face pelletizer with (2) blades, housing with blower discharge and a 5.5 kW blower. (1) Cyclone, (1) 6.8 kW Crammer feeder. Used for 4 months.

Stock# 49772001

Used- Prism Twin Screw Co-Rotating Extrusion Pelletizing Line. Consisting of: (1) Prism 16mm side by side twin screw extruder, approximate 15 to 1 L/D, electrically heated 6 zone clam shell barrel, approximate 42-1/2" centerline height. Water cooled feed section with a K-Tron twin screw feeder with conditioning hopper, driven by a 0.45kw DC motor with speed controller. Extruder driven by an approximate 3/4hp motor. Includes a control panel with CAL 9900 temperature controllers. Mounted on casters, serial# 1446. (1) 2 Hole strand die, (1) Prism stainless steel water bath, approximate 39-1/2" long x 4-3/4" wide x 5-3/4" deep, end mounted air knife with a 0.37kw blower. (1) Prism approximate 1/2" wide 4 blade pelletizer with metal and rubber pull rolls. Machine# 1446.

Stock# 11453369

Used- Leistritz Twin Screw Pelletizing Line, Model Micro18PH/GG-40D. 18 mm screws, counter rotating screws, 40:1 l/d, 500 rpm screw speed. Electrically heated, water cooled barrel, 2.3 kw, 480 volt, 3200 rpm dc motor with SCR controller, (2) barrel sections with jacketed feed. (1) vent, on board control panel with (10) Eurotherm 2208 controllers, with feed, (7) barrel, (1) adaptor, (1) die zones. Built 2003.

Stock# 11453367

Used- Leistritz Twin Screw Pelletizing Line, Model Micro27-GGC-40D. 27 mm screws, counter rotating screws, 40:1 l/d, 500 rpm screw speed. Electrically heated, water cooled barrel, 12 kw, 460 volt dc motor with SCR controller. (10) barrel sections with (1) jacketed feed, (1) vented, (3) vented and plugged, (4) non vented barrel sections. On board control panel with (13) Eurotherm controllers, 10" wide x 180" long cooling conveyor. Beta Lasermike, Model 182. Built 1996. Randcastle strand pelletizer, Model RCP-4.0, 4" wide helical rotor, pull rolls, built 1999.

Stock# 49303001

Used- Werner & Pfleiderer Twin Screw Pelletizing Line, ZSK 92mm Mega Plus, Model ZSK 92 MC, S/N 20509206, Year 2009 40:1 L/D, 10 Barrel Sections includes side Feed Barrel (#6) and Vent Barrel sections (#5, #9). Electrically Heated, Water Cooled. Driven by Elin MKH 745E06 Water Cooled 1319kW Motor Serial 505791-08001, 1471 RPM, Flender Gear box rated for 1470 RPM N2=1000 RPM, Side Feeder Coperion ZS-B 92 S/N 20509201, Year 2009, Includes Ktron Loss-In-Weigh Feeders, Die Plate, Water Slide and Automatik JSGM600 Pelletizer, DSM Vibratory Screener, Siemens Touch Screen Controls.

Stock# 49376001

Used- Comac Twin Screw Pelletizing Line. Includes: Comac co- rotating twin screw extruder 43 mm, 32 to 1 L/D. Comac co-rotating twin screw extruder, type EBC 40, series HT, nominal diameter 43mm. Approximate 32 to 1 L/D ratio. (8) Barrel zones electrically heated, water cooled, (2) top vented (1 closed). Water cooled with pump, tank, and heat exchanger. Water cooled feed throat with a DSM dosing feeder. Approximate 43-1/2" centerline height. Driven by a 45 Kw, 3/50/400/690 volt, 1475 rpm motor thru a Zambello reducer, type RB35/42CORHT. (1) Operator panel, (1) main control panel with temperature controllers and a Siemens Micromaster 440 drive. (1) 8 Hole strand die head. (1) Caccia high intensity mixer, Model CP0400V, stainless steel. Approximate 340 liter working capacity. (2) Tier blade, fixed sidewall baffle, top cover, side outlet with plug valve, (1) control panel with an Omron programmable controller. Driven by a 75kw motor. (1) Meccano Plastica pelletizer, type T150. With blower, and small air knife. Mounted on wheels. (1) Tenco screener, Model VMC60A, stainless steel. Triple deck, 4 separation, mounted on a base. (1) Frigel chiller, (2) High pressure blowers, (1) water bath. Mfg. 2001.

Stock# 41757009

Unused-Plama ZSP 70 GF Compounding Line for PP and fiberglass blend. Comprised of (1) Plama ZSP70GF co-rotating extruder, 2.56" (70 mm), L/D 40, screw speed 600 rpm, 346 hp/260 kW, 50 hz, water cooled, siemens drive and control and Thyssen gearbox. (1) Brabender dosing system with (4) surge tanks and pneumatic sliders. (1) Plama SF-40 side feeder, 2 x 1.6" (41 mm), 600 rpm screw speed, 2 hp/1.5 kW, capacity 700-800 kg/hr. (1) C.F. Scheer granulating system, 30 holes x 0.16" (4 mm) strand die, cooling batch and granulator, capacity 2976 lbs/h (1350 kg/h). (1) Z-F-20/60 granule conveying system. (1) S-F20 glass fiber conveying system. (2) F10 Masterbatch conveying system. (1) Tempering unit. (1) Water cooling unit.
