Used Semi Automatic Manual Load Vertical Cartoners

Stock# 71899004

Used-Adco Vertical Cartoner, Model 9VHL-100-SS. Has automatic carton layflat magazine with rotary vacuum pick and place feed, 9" centers for carton size range Length: 1" to 6.5", Width: 1" to 3.5", & Depth 4" to 10". Has (apprximate) 12' manual product feed section. Is equipped with (2) Becker vacuum pumps and a Nordson hot melt glue system, model ProBlue4; complete with (2) hoses and (2) glue applicators. Has Allen Bradley PlaelView Plus 400 HMI. Serial no. 4797HS. 3/60.230V.

Stock# 70877001

Used- Bivans Model Vertuck 74 Vertical Glue Cartoner. Machine is capable of speeds up to 120 cartons per minute. Has 6" centers for a carton size range: length 7/8" - 5", width 3/4" - 3-1/2", depth/height 2-1/4" - 10". Has carton magazine, discharge conveyor and vacuum pump. Has Nordson 2200 hot melt glue system and embosse date coder. 3/60/220/440V.

Stock# 71341003

Used- Bivans Model 74T Vertuck Semi-Automatic Vertical Cartoner. Machine is capable of speeds up to 120 cartons per minute (depending on application). Has 6" centers for a carton size range of: 7/8" to 5-1/4" (length); 3/4" to 3-1/2" (width); and 2-1/2" to 10" (height). Machine is equipped with top flap emboss coder and casters plus leveling legs Now set up for glue sealing with a Nordson hot melt glue system with hoses and glue guns. 12 amp. 3/60/230V.

Stock# 71341004

Used- Bivans Model 74T Vertuck Semi-Automatic Vertical Cartoner. Machine is capable of speeds up to 120 cartons per minute (depending on application). Has 6" centers for a carton size range of: 7/8" to 5-1/4" (length), 3/4" to 3-1/2" (width), and 2-1/2" to 10" (height). Is currently set up for glue sealing with a Nordson 2302 hot melt glue system with hoses and glue guns. 12 amp. 3/60/230V.

Stock# 70192022

Used-Brunner Model VC Vertical Semi Automatic Intermittent Motion Cartoner. Capable of speeds up to 60 cartons per minute. Carton size range: length 15mm to 60mm, width 20mm to 80mm, height 60mm to 100mm. Has manual load station for product loading. Currently set up for reverse tuck style cartons. 3/60/220V. Machine footprint 54'' long x 30'' wide x 64'' tall. Machine can be set to size and retooled at additional cost upon receipt of carton samples.

Stock# 70192023

Used- Brunner Model VC Vertical Semi Automatic Intermittent Motion Cartoner. Capable of speeds up to 60 cartons per minute. Carton size range: length 15mm to 60mm, width 20mm to 80mm, height 60mm to 100mm. Has manual load station for product loading. Currently set up for reverse tuck style cartons. Equipped with optional pre-folded leaflet, for 'U' style insertion. 3/60/220V. Machine footprint 54'' long x 30'' wide x 64'' tall. Machine can be set to size and retooled at additional cost upon receipt of carton samples.

Stock# 71482003

Used- CAM Model AV Vertical Cartoner With Automatic Bottle Loader. Capable of speeds from 15 - 70 cartoners per minute. Has a carton size range of 20mm - 115mm length x 15mm - 70mm width x 50mm-190mm depth. Features adjustable centers, bottom flap embosse date coder, prefolded leaflet inserter, robotic bottle loader. Equipped automatic bottle loader. Can be run as a manual load cartoner with approximately 4' of load area. Machine can be customized and set to size per at an additional cost subject to receipt of product samples. Currently set up on reverse tuck cartons. Uses Omron Sysmac CQM ONE PLC controls. 3/60/208V.

Stock# 71571001

Used- Clybourn Model CHL7 Vertical Hand Load Hot Melt Glue Cartoner. Capable of speeds from 10 to 100 cartons per minute. Set on 10" centers for a carton size range: 1" - 8.25" length x 0.75" - 3.5" width x 4.25" - 11.25" height. Has 14' of load area. Rotary carton feeder with 6' long powered carton magazine, Nordson Problue7 hot melt glue system with Electro Cam PLS 5000 series controls. Currently set up on a 7.25" x 1.75" x 5.75" carton for operator loading multi-count pouches of gummy bears. 3/60/240V.

Stock# 71706003

Used- Clybourn Model C Automatic Load Vertical Cartoner equipped with 16 stainless steel funnel pockets with extended product load time. Machine is capable of speeds up to 80-200 cartons per minute. Has 10" centers for a carton size range of: 1" - 8" length; 3/4" - 2-1/2" width; 4-1/4" - 8" depth. Includes Nordson ProBlue 7 hot melt glue system with Eclipse series pattern controller. Uses an Allen Bradley MicroLogix 1200 PLC control system. Lexan barrier guarding. Has 4-head rotary carton feeder with 10' long powered magazine. Last used with Ishida scale (not included) packing water soluble dish detergents pouches into cartons. Installed floor plan dimensions: 29'L x 7'W. 3/60/460V.

Stock# 70795001

Used- Econocorp Model 6932 V-System Semi-Automatic Vertical Cartoner capable of speeds up to 40 cartons per minute. Carton size range: length 1" to 8"; width 3/4" to 3"; depth 2-1/2" to 10". Set up for tuck style cartons. Has Westlund 200 leaflet inserter. 5.4 Bar at 80 psi. 1/60/220V.

Stock# 70795002

Used- Econocorp Model 6932 V-System Semi Automatic Vertical Cartoner capable of speeds up to 40 cartons per minute. Carton size range: length 1" to 8"; width 3/4" to 3"; depth 2-1/2" to 10". Set up for tuck style cartons. Has Westlund 200 leaflet inserter. 5.4 Bar at 80 psi. 1/60/220V.

Stock# 71605001

Used- IMA Vertima Vertical Tuck Style Cartoner with Automatic Bottle Loader. Capable of speeds up to 70 cartons per minute. Has a carton size range: 20mm - 120mm (0.787"-4.7") length; 24mm - 100mm (0.94" - 3.93") width; 40mm - 100mm (1.57" - 3.93") height. Has robotic loader that picks cosmetic bottles out of pucks and places into carton. Has puck return conveyor, Madag thermal hot stamp transfer date coder. Uses Siemens PLC controls. 3/60/208V.

Stock# 40765002

Unused- Fabrima VP-120 Semi- Automatic Continuous Motion Vertical Cartoner. Capable of speeds 120 cartons per minute. Never installed! Has top flap embosse date coder. Currently set up for reverse tuck style cartons. Has 8" centers for a carton size range: length 20mm to 135mm; width 20mm to 90mm; height 60mm to 320mm. 62" product load area each side, has PLC controls with HMI interface. Mounted on casters. Built 2005. Has not been used in production. See video of machine running on AEK web page.

Stock# 41177366

Used- Jones CMV8 Continuous Motion Vertical Cartoner capable of speeds up to 90 CPM. Has 8" centers for a carton size range: length 2" to 7-1/4", width 1" to 3", depth 3" to 9". Has 30" long carton magazine, 12' long loading area with Nordson hot melt glue system in enclosure.

Stock# 41177368

Used- Jones CMV 8 Continuous Motion Vertical Cartoner. Capable of speeds up to 90 CPM. Has 8" centers for a carton size range: length 2" to 7-1/4", width 1" to 3", depth 3" to 9". Has 30" long carton magazine, 12' long loading area with Nordson hot melt glue system in enclosure.

Stock# 70105002

Used- Jones CMV6 Cartoner. Semi- automatic continuous motion vertical tuck cartoner. Capable of speeds up to 120 cpm. Has 5.5" centers for a carton size range: length 1" - 5-1/4", width 3/4" - 4-1/4", depth/height 2-1/2" - 8". Has 3' frame extension for 8' of load area on each side. No glue unit nor controls. 3/60/220/440V.

Stock# 70105003

Used- Jones CMV5 Semi Automatic Continuous Motion Vertical Tuck Cartoner. Capable of speeds up to 120 cpm. Has 5" centers for a carton size range: length 1" - 4-1/4", width 3/4" - 4-1/4", depth/height 2-1/2" - 8". Has 3' frame extension for 8' of load area on each side.. Set up for tuck style using belt tuckers. Unitized on a carbon steel base on casters.

Stock# 40344003

Used- Jones CMV5 Semi Automatic Continuous Motion Vertical Hot Melt Glue Cartoner, Model CMV5. Capable of speeds up to 120 cpm. Has 5" centers for a carton size range: length 1" - 3" width 3/4" - 4-1/4"; depth/height 2-1/2" - 8". Lexan safety guarding , stainless steel product guarding. Has 5' long manual load area. Bottom flap embosse date coder, requires print head. Mounted on casters.3/60/240V

Stock# 71991001

Used-Jones CMV5 Semi Automatic Continuous Motion Vertical Tuck Cartoner. Capable of speeds up to 120 cpm. Has 5" centers for a carton size range: 1" - 4-1/4" (length) x 3/4" - 4-1/4" (width) x 2-1/2" - 8" (depth/height). Has Allen Bradley Micrologix 1000 PLC control, Allen Bradley Microview touchpad HMI, Laetus Argus IV bar code scanner. Lincoln One Shot lubrication system. Set up for reverse tuck style using belt tuckers. Standard 5' long load area on each side. Has a 9' long powered belt discharge conveyor. Unitized on a carbon steel base on casters. Price includes machine set to one size tuck style carton in good working condition (subject to review of product samples). Ask your AEK sales representative for details. 3/60/480V. Top flap embosse date coder available at an additional cost.
