Used Semi Automatic Manual Load Horizontal Cartoners

Stock# 71753003

Used- Langen Semi-Automatic Manual Load Horizontal Cartoner, Model: B1R-18. 18" centers, (4) chain unit with 3" tall lugs and overhead squaring for 6" maximum carton width. Carton size range: Length of 1-3/4" to 12.5"; Width of 1/2" to 6"; Depth of 3.75" to 14". Nordson 3400 with 4 hoses (incomplete) and Epc 15 pattern controller. 6' load area with 8" wide x 11' long product infeed belt conveyor. 18" long carton magazine with 2 head rotary carton picker with vacuum inducer. Relay controls with 2 VFDs from infeed belt and carton carrier, SN 10-134. 3/60/440V, 20 a, 90 psi comp air. OAL 19' long x 5' wide x 6' high. Retooling, set-up and testing services are available. Contact AEK for more information.

Stock# 71814001

Used- Langen Model B1 Semi-Automatic Horizontal Cartoner. Capable of speeds up to 60 cartons per minute. Has 18" centers with 3" high lugs for a carton size range: (length) 1-3/4" to 13"; (width) 1/2" to 6"; (depth) 3.75" to 14". Two head rotary carton feed. Includes a top squaring device, hot melt glue system and 6' long manual load area. 3/60/208V.

Stock# 71814002

Used- Langen Model B1M-18 Semi-Automatic Horizontal Cartoner. Capable of speeds up to 60 cartons per minute. Has 18" centers with 1 1/2"H lugs for a carton size range: (length) 1-3/4" to 13", (width) 1/2" to 6", (depth) 3.75" to 14". Two head rotary carton feed. Includes top squaring device, hot melt glue system and 6' long manual load area. 3/60/208V.

Stock# 71990001

Used- Langen B1M Semi-Automatic Horizontal Cartoner. 18" center machine with 6" lugs, top squaring rails. Carton size range: Length 4" to 14", Width 1 3/4" to 6.625" and Depth 4 1/4" to 26" and rated from 30 to 60 cpm - speeds depending on materials and application. Four chain unit equipped with two head rotary feeder, 9' long load area, full length Estop chord, Nordson hot melt ready for 4 hot melt nozzles all have independent adjustments built into the program and top carton squaring assembly. Mounted on s/s frame. Elec: 3/60/480V.

Stock# 70056010

Used- Tanney Cartoner, Model 902 EC. Load Area 68", Pitch 12". Missing main drive motor.
