Used Paddle Mixers

Stock# 44231006

Used- Rietz Bepex Creamer, Model RC-60, 304 Stainless Steel. Non-jacketed trough approximately 58" diameter x 78" long. 6" Diameter shaft with ribbons, and T paddles. hydraulically driven, no power pack. (2) Top access doors, (2) spray balls. 3" End bottom outlet. Mounted on (4) stainless steel legs.

Stock# 44231007

Used- Rietz Bepex Creamer, Model RC-70, 304 Stainless Steel. Non-jacketed trough approximately 58" diameter x 91" long. 6" diameter shaft with ribbons, and T paddles. hydraulically driven, no power pack. (2) Top access doors, (2) spray balls. 3" End bottom outlet. Mounted on (4) stainless steel legs.

Stock# 44231008

Used- Rietz Bepex Creamer, Model RC-60, 304 Stainless Steel. Non-jacketed trough approximately 58" diameter x 78" long. 6" Diameter shaft with ribbons, and T paddles. hydraulically driven, no power pack. (2) Top access doors, (1) spray ball. 4" End bottom outlet. Mounted on (4) stainless steel legs.

Stock# 49173002

Used- Feldmeier Horizontal, Insulated, Jacketed, Round Hip Paddle Blender, 1,500 Gallons. (12,000 lbs raw material and 90 gallons of water). 304 Stainless steel contact parts. Internal rated 40 psi/full vacuum at -20 to 300 degrees F. 304 stainless steel jacket rated at 150 psi at -20 to 300 degrees F. 66" internal diameter x 96" straight side. Built 2014.

Stock# 73698

Used- Paul O. Abbe/Forberg Twin Shaft Fluidizer/Dryer, Model AFD-20. 0.7 Cubic feet working capacity, 1 total, 304 stainless steel. Trough 15-3/4" x 18-1/2" x approximate 17" deep. (2) 1-3/4" Diameter shafts with 12 paddles welded to 3/4" diameter posts. Driven by a 1 hp motor. (2) Pneumatically operated bomb-bay style bottom discharge doors. 150 cfm heat transfer package, liquid injection, top mounted dust collector and Nema 12 packaged controls.

Stock# 48091001

Used- American Process Twin Shaft Fluidized Zone Mixer, Model FZM-4S. 4.2 Cubic feet, 120 liters, Carbon Steel. Non-jacketed trough approximate 33" long x 29" wide x 24" deep. (2) 2" diameter shafts each with (14) 5-3/4" wide x 1/8" thick paddles welded to 1" posts. Driven by a 5 hp, 3/60/230/460 volt, 1680 rpm motor. (2) Breaker bars driven by a 1 hp, 3/60/230/460 volt, 1720 rpm motors. (2) approximate 26" x 6" bottom outlets. Has side lugs. Serial# 4388. Built 1995.

Stock# 10147138

Used-Forberg Double Shaft Paddle Mixer, Model F-120 S. Stainless steel construction, pneumatically operated with cover. Working capacity 4.24 cubic feet (120 liters), 2.5 hp/1.9 kW motor. Trough size 33" (840 mm) x 38.4" (720 mm), inlet 38.4" (720 mm) x 21.3" (540 mm), outlet 26.4" (670 mm) x 5.1" (130 mm). 380 Volt, 50 hz. With switch and "Flow Distortion Bar". 0.77 Hp/0.58 W, 380 volt, 50 hz.

Stock# 48058002

Used- Paul O. Abbe Forberg Twin Shaft Paddle Mixer, Model AF 120, 4.3 Cubic Feet (120 liters), working capacity 0.9-6.0 Cubic Feet, 304 Stainless Steel. Non-jacketed trough approximate 33-1/8" long x 28-3/8" wide x 24" deep. (2) 2.5" Diameter shafts each with (14) 5-1/2" wide x 3/16" thick paddles welded to 1" diameter posts. Driven by a 5 hp, 3/60/230/460 volt, 1680 rpm motor with 11.2:1 gearbox ratio. Top hinged cover. Mounted on a frame with casters. Serial# A45241. Built 1994.

Stock# 10147024

Turbulent dryer (1x), Make Drais, Type HT-160 A, No 50561, New 1981, Material stainless steel (1.4571), Capacity 160 Ltr, Trough sizes dia. 505x900mm, Inlet dia. 300mm, Outlet dia. 125mm, Working pressure vac/6 bar, Test pressure 7,8 bar, With jacket (18 Ltr), Trough sides jacketed (2,7+1,5 Ltr), Working pressure 6 bar, Test pressure 9,1 bar, Max. temperature 200 Degr. C., With mechanical seal, Motor 12,0 KW, 380 Volt (Ex), Floorspace 4,6x1,3 M (in open position), Total height 2,2 M (without filter)

Stock# 10147127

Used-Drais Powder Turbo Mixer. Capacity 8.82 cubic feet (250 liters). Motor 25 hp (18.5 kW). Trough size diameter 27.55" x 29.53" (700 x 750 mm). (1) Inspection hatch 19.68" x 11.81" (500 x 300 mm).

Stock# 49532001

Used- American Process OptiBlend Fluidizing Paddle Mixer, Model FPB-010, 10 Cubic Feet, 316 Stainless Steel. Non-jacketed trough approximately 48" left to right x 26" front to back x 34" deep. (20) welded on paddles approximate 7-1/4" wide x 1/2" thick on 3" diameter shaft. Driven by a 30 hp, 3/60/230/460 volt, 300-1800 rpm gearmotor, output 90 rpm, 19.45 to 1 ratio. Hinged top cover with 9' x 6" sight glass, (1) 14", (2) 3", (6) 2" diameter openings. 3" Side bottom outlet, 16" x 8" center bottom outlet with pneumatic valve. Side access door 15" x 13" with hinged cover. Mounted on stainless steel legs. Built 2013.

Stock# 49881001

Used- Bella Fluidized Zone Mixer, Model B-350XN. Dual direct drive. 12.36 cubic feet batch capacity. (2) 5 hp motors. Approximate 2,020 lbs. Mfg. 2012.

Stock# 49881002

Used- Bella Fluidized Zone Mixer, Model B-350XN. Dual direct drive. 12.36 cubic feet batch capacity. (2) 5 hp motors. Approximate 2,020 lbs. Mfg. 2012.

Stock# 48832001

Used- Paul O. Abbe Cross Flow Mixer / Twin Shaft Fluidizer, Model AF350, 304 Stainless Steel. 12.4 Cubic feet working capacity, maximum 17 cubic feet. Non-jacketed trough approximately 39-3/8" wide x 49-1/2" long x 35" deep. (2) Approximate 3" diameter shafts with (28) 8" wide x 7" long x 3/16" thick paddles welded with 1-1/4" diameter posts. Bolt on top cover with (2) hinged doors, (2) side access doors. (2) Bombay outlet door, air operated. Driven by a 7.5 hp, 3/60/230-460 volt, 1720 rpm motor with with 24.40:1 gearbox ratio. Mounted on a painted carbon steel frame. Serial# A48097.

Stock# 49567011

Used- Will Flow Paddle Blender, Approximately 19 Cubic Feet, Stainless Steel. 28” Wide x 48” long x 31” deep dimple jacketed trough with a 15” tall welded top extension, rated 55 psi at 300 degrees F. Approximate 2” diameter shaft with (3) paddles, welded to 1-1/4” diameter posts. Top cover, Driven by an approximate 3hp gear motor. 3” End bottom outlet with a Waukesha positive displacement pump, model 060, serial# 143944, set up for hydraulic drive, no power pack. Blender mounted on 4 stainless steel legs. National Board# 5556, serial# 50873, built 1987.

Stock# 10151253

Used- Marion Paddle Mixer, Model FP-3648. 30 Cubic foot working capacity. 304 Stainless steel. Jacketed trough measures approximately 51" long x 38" wide x 51" deep. Jacket rated 150 PSI at 100 degrees F. Closed top cover with bolt down cover. 8" offcenter discharge with Norbro ball valve. Driven by a 15 hp, 3/60/460 volt motor thru reducer.

Stock# 49143001

Used- American Process Systems Forberg Fluidized Zone Mixer, Model FZM-35, 35 Cubic Feet Working Capacity, 304 Stainless Steel. Non-jacketed chamber approximate 58" long x 67" wide. (2) 4" Diameter shafts with (16) paddles per shaft, paddles 11-9/16" wide x 3/8" thick welded to 1-1/2" diameter posts. Driven by 30 hp, 3/60/208-230/460 volt, 1760 rpm motor with 30.05:1 gearbox ratio. (2) 20" x 20" side access doors, (2) 9" x 57" Bombay door style outlets. Includes stainless steel stand, Bag Dump Station. Serial# F1041. Built 1995.

Stock# 10128038

Used- Marion 45 Cubic Foot Paddle Mixer, Model 4020. Series 4000. 45 cubic foot working capacity, 62 cubic foot total volume. Mixer is driven by a 20 hp 1755 rpm motor through gear reducer down to 38 rpm. The mixer is an open top with a 36" x 35.75" opening and a 36" x 14.25" opening. The mixer bottom has an 8" diameter flanged center discharge with butterfly valve 32" from ground. The mixer has 36" diameter paddles with a 2.75" diameter shaft. Mixing chamber is 72" long x 36" wide x 45" deep. Overall dimensions are 56" wide x 114" long x 85" tall. Requires 230/ 460 vac 3 phase electrical supply.

Stock# 14191070

Used- Marion Paddle Blender Batch Mixer, Series 4000, Model 4020. 45 cubic foot, carbon steel. Batch paddle mixer has a 45 cubic foot working capacity and a 62 cubic foot total volume. Mixer is driven by a 20 hp, 1755 rpm motor through gear reducer down to 38 rpm. The mixer is an open top with a 36" x 35.75" opening and a 36" x 14.25" opening. The mixer bottom has an 8" diameter flanged center discharge with butterfly valve.

Stock# 47480002

Used- Forberg Narrowed Top Style Twin Shaft Fluidizer. Approximate 50 Cubic Feet, 304 Stainless Steel. Non-jacketed trough, feed opening approximately 62" long x 48" wide x 37" deep. (2) Approximate 5-1/2" diameter shafts each with (14) paddles 13" long x 13" wide x 3/16" thick welded to 2" diameter posts. (2) Air operated Bombay outlet doors. Mixer hydraulically driven, no power pack. No manufacturers tag.

Stock# 11059140

Used- American Process Systems Paddle Blender, Model FZM-53. (53 Cu.Ft./1500 Liter) Twin shaft fluidized zone mixer/paddle blender. 304 stainless steel. 30 hp 230/460 volt motor. Mixer paddles are 25 rpm. Includes control panel. Last used in a sanitary application in pharmaceutical plant.

Stock# 47631001

Used- American Process Systems Twin Shaft Fluidizing Paddle Blender Mixer, Type FZM-70 S, Model F070-5858, 70 Cubic Feet Capacity, 304 Stainless Steel. Non-jacketed trough approximately 87" wide x 73-1/2" long x 70" deep. (2) Approximate 5" diameter shafts with (14) paddles per shaft, paddles 15" x 12-1/2" x 1/2" thick welded to posts. Driven by a 40 hp, 3/60/208-230/460 volt, 1775 rpm gear motor, ratio 29.95 to 1. Bolt-on top cover with (1) 40" x 32" hinged cover, (1) 30" x 24" hinged cover. Air seals and roller bearings. 10" End bottom outlet with air operated valve. Frame mounted. Serial# 5858. Built 2002.

Stock# 46727001

Used- American Process Forberg Twin Shaft Fluidizer Zone Mixer, Model FZM-70, 70 Cubic Feet Capacity, 304 Stainless Steel. Non-jacketed chamber approximately 73-5/8" wide x 86-1/16" long x approximate 60" deep. (2) Approximate 5-1/2" diameter shafts with 14 paddles (28 total) 14-1/2" x 12-1/2" x 5/16" thick welded to 2-3/4" diameter posts. Driven by a 50 hp, 3/60/230/460, 1760 rpm gear motor, 37.42 to 1 ratio, approximate 23 rpm agitator speed. (2) Air operated Bombay bottom outlet doors, approximately 12" wide x 72" long. Bolt on top cover with 17" feed, 6", 4" vent, 12-1/2" x 12-1/2" and (2) hinged access doors, (4) 20" x 20" hinged side access doors. Split packing glands with air purge seals, outboard roller bearings. Serial# 5136, built 1998.

Stock# 49352001

Used- Marion Continuous Paddle Mixer, Model CPS-42144, 94.5 Cubic Feet Capacity, 304 Stainless Steel. Non-jacketed trough 42" wide x 144" long x approximately 64" deep. Approximate 4-15/16" diameter shaft with (16) bolt-on paddles (2 missing). Driven by a 75 hp, 3/60/230/460 volt, 1,775 RPM TEFC motor through a SEW-Eurodrive (MC3PLHT06) shaft mounted torque arm reducer, ratio 29.6108 to 1, approximate output 38.4 rpm. Top cover has two 24" x 36" access doors with safety grates. Openings top: 42" x 9", (2) 24" x 12", (1) 4", side: (2) 6". (2) 4" Bottom outlets, bottom end discharge with wear plate, 42" x 12". Outboard roller bearings and style E split and adjustable stuffing box main shaft seals are included. Serial# 08039. Product data (Normal Flow, Maximum Flow, Density): Wet Cake 29,205 LB/HR; 37,965 LB/HR; 35 LB/FT3. Syrup 26,835 LB/HR; 34,890 LB/HR; 72 LB/FT3 Distillers dried grains with solubles 105,725 LB/HR; 169,160 LB/HR; 35-48 LB/FT3.

Stock# 49352002

Used- Marion Continuous Paddle Mixer, Model CPS-42144, 94.5 Cubic Feet Capacity, 304 Stainless Steel. Non-jacketed trough 42" wide x 144" long x approximately 64" deep. Approximate 4-15/16" diameter shaft with (16) bolt-on paddles (2 missing). Driven by a 75 hp, 3/60/230/460 volt, 1,775 RPM TEFC motor through a SEW-Eurodrive (MC3PLHT06) shaft mounted torque arm reducer, ratio 29.6108 to 1, approximate output 38.4 rpm. Top cover has two 24" x 36" access doors with safety grates. Openings top: 42" x 9", (2) 24" x 12", (1) 4", side: (2) 6". (2) 4" Bottom outlets, bottom end discharge with wear plate, 42" x 12". Outboard roller bearings and style E split and adjustable stuffing box main shaft seals are included. Serial# 08043. Product data (Normal Flow, Maximum Flow, Density): Wet Cake 29,205 LB/HR; 37,965 LB/HR; 35 LB/FT3. Syrup 26,835 LB/HR; 34,890 LB/HR; 72 LB/FT3 Distillers dried grains with solubles 105,725 LB/HR; 169,160 LB/HR; 35-48 LB/FT3.

Stock# 49638001

Used- Inotec Double Paddle Vacuum Mixer, Type IM3000V. Stainless steel construction. Working capacity 105.9 cubic feet (3000 liters). Double shafts with each 6 paddles. Double end product discharge. Complete with a 52.5 HP/35Kw-400 volt/50cycle/3Ph motor and gearbox. Pneumatically operated top cover. Includes controls. Frame mounted, on 4 legs. Overall dimensions: 13’7” long x 8’1” width x 7’8” high (4212 mm long x 2495 mm width x 2407 mm high) New 2004. Previous used in a meat application.

Stock# 49307008

Used- Marion Paddle Mixer, Model BPS-5496, 304 Stainless Steel. Approximate 144 Cubic Feet Working Capacity. Non-jacketed trough approximate 96" long x 54" wide x 59" deep. Approximate 5" diameter shaft with (6) welded 2" diameter posts, (2) side scrappers. Driven by a 75 hp, 3/60/460 volt, 1770 rpm motor thru Dodge speed reducer 25.66 to 1 ratio. (4) Tulip style side choppers, driven by a 10 hp, 3/60/230/460 volt, 3500 rpm motors. 12" Center bottom outlet with pneumatic slide gate valve. Bolt-on top cover with (2) hinged doors. Includes top mount Reimelt jet-filter 404 P4 dust collector. Serial# 95030.

Stock# 43199001

Used- Hough Forberg Twin Shaft Fluidizer, Model FB500002. 176.6 Cubic Feet Working Capacity, Carbon Steel. Non-jacketed trough approximate 98" wide x 118" long x approximately 60" deep. Top pin mill bar, driven by a 10 hp, 3/60/460 volt, 1750 rpm motor. (2) Shafts with paddles welded to posts. Mixer driven by a 100 hp, 3/60/230/460 volt, 1160 rpm motor thru a dodge reducer, ratio 25.60 to 1, approximate output 68.4 rpm. (2) Air operated bombbay style bottom discharge doors with chute and air operated slide gate valves. Includes a top removable cover with openings.
