Used HJM Precision Ignition Cartridge Non-Destructive Inspection Machine | PLC Controlled | 3-Axis Robot | Built 2019

🏭 Manufacturer

HJM Precision, Inc.
A specialized manufacturer of automated and high-accuracy inspection systems for defense, aerospace, and industrial components. Known for customized solutions and robotic NDI (non-destructive inspection) platforms.

📝 Description

This HJM Precision Ignition Cartridge Non-Destructive Inspection Machine was designed and built in 2019 specifically to inspect ignition cartridges for leaks in a fully automated or manual-controlled environment. The system features a three-axis robotic loading mechanism, precision test chambers, and operator-friendly PLC + HMI interface for control and diagnostics.

The machine uses a tray-based loading system, where cartridges are robotically moved into test chamber blocks. Each block contains four chambers, and the entire testing process is automated, repeatable, and non-invasive, ensuring consistent leak testing without damaging sensitive munitions.

⚙️ Specifications

• Model: Ignition Cartridge Inspection Machine

• Manufacturer: HJM Precision, Inc.

• Year Built: 2019

• Purpose: Leak detection / non-destructive inspection of M702 ignition cartridges

• Automation Type:

  • PLC Controlled with HMI Interface

  • Manual and Automatic Modes

• Robot System:

  • 3-axis robot (X, Y, Z)

  • Gripper mounted on linear slides

  • X-axis: Machine length

  • Y-axis: Crosswise movement

  • Z-axis: Vertical motion

• Test Chamber Design:

  • 4 test chamber blocks mounted to dial plate

  • Each block contains 4 chambers (16 test stations total)

• Testing Process:

  • Robotic pick-and-place from input tray

  • Covers lower onto chambers; nozzles extend to base

  • Flow-based leak detection

• Flow Components:

  • Gilmont flow meters

  • Hoke precision needle valves

• Control Interface:

  • PLC-based automation with touchscreen HMI

  • Manual override for cleaning, homing, clearing

• Condition: Excellent (light use, built in 2019)

🧪 Applications

Purpose-built for military and defense industry quality control of ignition cartridges, and adaptable to other small part NDI tasks including:

• Ammunition leak testing

• Cartridge or capsule seal testing

• Igniter inspection in defense/aerospace

• Pyrotechnic device QA/QC

• Pressurized small part NDT

• Small pressurized components in aerospace

• Specialty gas or chemical charge container testing
