Used Nutsche Filters

Stock# 45874001

Used De Dietrich Rosenmund Pilot Scale Filter/Dryer, Pressure rated Vessel. Type ROLAB RGFD 0.06-09. Material of construction is Hastelloy 2.4602 on product contact parts. Inside volume 11.37 gallon (43 liter). Internal and jacket pressure rated 90PSI (6bar) and full vacuum (-1) at -4-+302 deg F. (-20 to +150 Deg. C). Inside Test pressure 141 PSI (9.4 bar), Jacket test pressure 168 PSI (11.2 bar). Complete with heated agitator, side discharge and drive. Explosion proofed control. On 8 legs, mobile on wheels. Serial # RGFD 0.06-09-20308.

Stock# 43339002

Unused- Rosenmund Guedu RGFD Filter Dryer fabricated of 316L stainless steel with approximately 0.25 m2 filtration area. This premium OEM agitated filter dryer was never installed or placed into service. Features include a side solids discharge and column-mounted, two-arm S-blade heated agitator with mechanical seal and bellows for filtration, cake washing, mixing, and vacuum drying in a single enclosed vessel. Includes an APOVAC explosion-proof gas recirculation system and an additional APOVAC unit originally supplied for a tray dryer. Mechanical components are present; however, controls were never built, and the purchaser will need to design and implement a control system. Engineering drawings are available. Ideal for pilot plant, process development, scale-up, and small-batch production of pharmaceutical APIs, fine chemicals, specialty chemicals, biotechnology products, and other high-value materials requiring contained filtration and drying. Built in 2001.

Stock# 11585050

Used Rosenmund Filter Dryer RSD -3, (0.3) Square Meter, Model # RSD-0.3-528-89. T316L stainless steel contacts. Internal rated 100 psi / Full vacuum at 400 degrees F. T304L Stainles steel Jacket rated 150 psi at 400 degrees F. Maximum capacity vessel 45 gallon. Hydraulic agitator. Side discharge. Built 1990. NB 911. Vacuum pump, receiver and control panel. Apovac 3.2/850 PMZF2510 Liquid Ring vacuum pump skid mounted with receiver.

Stock# 10151515

Used Rosenmund 4 Square Meter Nutsche Filter, Model RPD4-388-86. Bottom discharge; 904L stainless steel shell, 316 stainless steel jacket; Shell rated 75 psi/FV at 397 degrees F; Half pipe jacket rated 100 psi/FV at 392 degrees F; Base rated 150 psi/FV at 370 degrees F; 10 hp main drive; hydraulic pack; Serial # F69653-1185-1; National Board # 17935; Built 1986 (Rebuilt since).

Stock# 10151512

Used Rosenmund 8 Square Meter Nutsche Filter, 304 Stainless Steel. Liquid discharge. 304 stainless steel shell, jacket, and internal. Shell rated 50 psi/FV at 370 degrees F. Half pipe and bottom plate jacket rated 150 psi/FV at 370 degrees F. Base rated 150 psi/FV at 370 degrees F. 20 hp main drive; hydraulic pack. Built 1991.
