Used Rotary Vacuum Dryers

Stock# 10288042

Used- J.P. Devine Rotary Vacuum Dryer. 100 cubic foot. Chamber inside diameter: 48". Chamber length: 15'. 304 stainless steel construction. Interutpted ribbon and wipers. Bull gear and pinion gear, 75 hp falk gear reducer. Does not include the motor, rated full vacuum. Jacketed for 15 PSI and full vacuum at 300 F. Jacket built for steam heat. Heavy duty outboard roller bearings. 12" center bottom outlet with pneumatic cylinder. 16" diameter top center mount manway with lid. 8" diameter vacuum port. 30" high leg extensions.

Stock# 11252086

Used- Aaron Process Vacuum Dryer with Cored Shafts and Jacketed Trough. All stainless steel construction, 200 gallon capacity. All parts are insulated and sheathed with 304 stainless steel and polished to 150 - 180 grit finish. Mixing/drying chamber includes vacuum cover and is jacketed. Rated for 200 PSI at 450 deg. F / -20 deg. F. ASME code constructed. Mixing chamber measures 48" x 40" x 44" deep and includes (2) 6" diameter flanged discharges with ball valves. Blades are overlapping double nobben blades and driven by 125 hp motor thru heavy duty gearbox. Previously used in clean room type environment. Complete with control panel and unitized on heavy duty frame. Includes main control panel, power panel with starters and VFD's, steam-to-water heat exchanger for heating of jacket and hydraulic pump/reservoir for opening vessel lid. Also includes top mounted, stainless steel Mikro Pulsaire dust collector, Model 10-2-FV TR, rated for 11. Mfg. 2000.

Stock# 45764010

Used- Processall Tilt-A-Mix Lab Size High Temp Rotary Vacuum Dryer, Model 4HV, 316 Stainless Steel. 2 Liter working capacity (.07 cubic feet), 4 total. 316 Stainless steel jacketed chamber approximate 6-5/8" diameter x 8-3/8" deep, internal rated Full Vacuum 15 psi at -20 to 715 degree F, jacket rated 75 psi at 715 degrees F. Approximate 1-1/2" diameter shaft with (2) welded plow blades, and (2) welded end scrappers, manual tilt. Driven by an approximate 1 hp XP motor. Mounted on a base. Serial# 218. Chamber certified by J-Weld, National Board# 399, Serial# 0399, built 2001.

Stock# 10147148

Used-Draiswerke Turbulent Dryer, Model T-50 FM-1. Built 1991, Stainless steel (1.4541) on product contact parts. Capacity 1.76 cubic feet (50 litre). Trough sizes diameter "15.5"x17.7 (395x450 mm), Inlet diameter 9.6" + 1.6" (245 mm + 40 mm), Outlet diameter 3.1" (80mm). Working pressure vacuum, Jacket 1.7 gallon (6.5 litre). With GWK type Teco oil heater. Working pressure 174 PSI (12 bar), Test pressure 245 PSI (16.9 bar), Maximum temperature 302°F (150°C). 5.3HP (4 kW), 380V, 50Hz motor, with variable speed drive. Speed mixing shaft ±48-291 Rpm. With lump breaker driven by a 5.3 HP (4 kW), 380/660V, 50Hz motor. Mounted on frame with wheels, with switchgear.

Stock# 68598

Used- Lodige Plow Mixer/Reactor, Type DVT 130, 316 Stainless Steel. 3.1 Cubic feet working capacity (4.6 total). Carbon steel jacketed chamber approximately 20" diameter X 26" long, bolt on flat hinged jacketed end. Approximately 4" diameter shaft with bolt on blades. Chopper driven by a 4.9/6 KW (6.5/8 HP), 3/50/380 Volt, 1445/2905 RPM motor. Openings top 10" diameter charge port with cover, 3" center bottom outlet with a manual plug valve. Driven by a 7.5 KW (10 HP), 3/50/380/660 Volt, 1440 RPM vari-speed motor, ratio 11.51:1. Mounted on a 22" tall carbon steel stand. Includes a control panel.

Stock# 49714001

Unused- Scott Equipment Company Indirect Batch Vacuum Dryer, Model INDVACDRY306SS. Approximately 20 cubic feet. 304 Stainless Steel. Approximately 30" diameter x 72" long jacketed chamber. Jacket rated 30 psi at -20 to 274 degrees F. Intermittent Ribbon Design with (16) 6" long x 2-1/2" wide x 5/16" thick paddles welded to 1-1/2" diameter posts. Driven by a 5 hp/3.7 KW, 3/60/575 volt, 1750 rpm motor with 24.74:1 gearbox ratio. 10" Diameter center bottom outlet with pneumatic valve. Mounted on a painted carbon steel frame. Includes control panel with Allen Bradley Panel-View plus 400 with Allen-Bradley MicroLogix 1100 drive. Mac Process top mounted dust collector. Airtech vacuum pump system, model SCS-3AL2281-1B, driven by a 11 HP, 3/60/208-230/460 volt, 1450-1750 rpm motor. Dryer serial# 1301021, built 2013.

Stock# 44438001

Used- Lodige Druvatherm Batch Type Vacuum Paddle Dryer, Type VTA 1200, 316 Stainless Steel. Approximate 28.3 Cubic feet (800 Liter) working capacity (42.3 total). Carbon steel jacketed chamber approximately 950mm (37.4") diameter x 1700mm (66.9") long. (1) End removable for telescoping shaft. Internal rated vacuum (-1) at 170 degrees C (338 F), jacket rated 7 bar (101 psi) at 170 degrees C (338 F). Shaft with fixed plows. (2) Side entering choppers with blades, 6.5-9 kW (8.7-12 hp) motors. Openings top 250mm (9.8") diameter charge port, 700mm (27.5") with a 2.4 square meter filter, rated vacuum (-1) at 170 degrees C (338 F), jacket rated 7 bar (101 psi) at 170 degrees C (338 F). 200mm (7.8") Center bottom outlet with a plug valve. Mixer driven by a 75kw (100hp), 3/50/380 volt, 1480 rpm motor thru a reducer, ratio 18.23 to 1. Includes a control panel, and miscellaneous framework.

Stock# 46075100

Used- Processall Rotary Vacuum Dryer Plow Mixer, Model 1200, 304 Stainless Steel. Approximate 1200 liter capacity (42 cubic feet). Jacketed chamber approximate 36" diameter x 96" long. Internal rated 100 psi at 350 degrees F, jacket rated 30 psi at 350 degrees F. (7) Bolt on plow blades, provision for (2) side entering choppers. Driven by a 60hp, 3/60/230/460 volt, 1780 rpm XP motor a Falk reducer, ratio 13.95 to 1, output 83 rpm. Includes a top mounted filter. Serial# 123. Certified by Cincinnati Butchers Supply, National Board# 0092, serial# PV-09-93, built 1993.

Stock# 81560

Used- Vevey Rotary Vacuum Dryer, 75 Cubic Feet Working Capacity. Material of construction is stainless steel on product contact parts. 4,000 Liter capacity. Approximate 52" diameter x 128" straight side (1380mm diameter x 3250mm straight side). Dished, one end removable. Inside rated for 30 psi (2 bar) and full vacuum (-1) at 392 degrees F (200 degrees C). Cored agitator with paddles rated for 75 psi (5 bar) and full vacuum. Flat channel jacket rated for 75 psi (5 bar) and full vacuum (-1). (2) 12" x 15" (310mm x 385mm) end clean out doors. Mechanical seal. Complete with gearbox, 6,6 kW, 500 volt motor.

Stock# 81561

Used- Buss Rotary Vacuum Dryer, 75 Cubic Feet Working Capacity. Material of construction is stainless steel on product contact parts. 52" diameter x 128" straight side (1400mm diameter x 3000mm straight side). Dished, one end removable. Inside rated for 30 psi (2 bar) and full vacuum (-1) at 302 degrees F (150 degrees C). Cored agitator with paddles rated for 72 psi (5 bar) and full vacuum (-1) at 302 degrees F. Spiral jacket rated for 72 psi (5 bar) and full vacuum (-1) at 302 degrees F. (2) 12" x 15" (310mm x 385mm) end clean out doors. Mechanical seal. Complete with gearbox, 5,5kW, 500 volt motor.

Stock# 81562

Used- CMR Construzioni Metallurgiche Riunite Rotary Vacuum Dryer, 75 Cubic Feet Working Capacity, 316L Stainless Steel. Approximate 52" diameter x 128" straight side (1400mm diameter x 3000mm straight side). Dished, one end removable. Inside rated for 30 psi (2 bar) and full vacuum (-1). Cored agitator with paddles rated for 116 psi (8 bar) and full vacuum (-1). Spiral jacket rated approximate 116 psi (8 bar) at 392 degrees F (200 C). (2) 12" x 15" (310mm x 385mm) end clean out doors. Mechanical seal. Complete with gearbox, motor.

Stock# 81565

Used- Vevey Rotary Vacuum Dryer, 75 Cubic Feet Working Capacity. Material of construction is stainless steel on product contact parts. Approximate 52" diameter x 128" straight side (1400mm diameter x 3000mm straight side). Dished, one end removable. Inside rated for approximate 72 psi (5 bar) and full vacuum (-1) at 311 degrees F (155 degrees C). Cored agitator shaft with paddles rated for 72 psi (5 bar) and full vacuum. (2) 12" x 15" (310mm x 385mm) end clean out doors. Adjustable packing glands. Complete with gearbox, 15kW motor.

Stock# 43405

Used- Giovanola Rotary Vacuum Dryer, 77 Cubic Feet Working Capaity, 316 Stainless Steel, Horizontal. Approximate 55" diameter x 114" straight side. Dished heads. One end removable. 316 Stainless steel flat channel jacket rated 75 psi @ 392 deg F. Internal full vacuum. 25" Diameter cored shaft rated 75 psi with paddle type agitators. (2) 12" x 16" End cleanout doors. Packing glands. (1) 19" Top inlet. 19" Center bottom outlet with valve. Direct driven 25 kw (33 hp) 3/50/500V/1450 rpm thru shaft mounted gearbox, 362.5:1 ratio. Agitator speed 4-5 rpm. Unitized on I-beam frame. Year 1965.

Stock# 63761

Used- Buss Type Rotary Vacuum Dryer, 4000 Liter Total Volume, 82 Cubic Feet Working Capacity, 316 Stainless Steel. 55" Diameter x 123" straight side. Dished heads, 1 end removable. Flat channel jacket rated 71 psi. Internal FV/50 psi. Cored shaft approximately 25" diameter rated 71 psi. With scraper type paddle agitator, (2) 12" x 16" end cleanouts. Approximate 14" cbo with valve. 48" discharge height. Top openings: (1) 18", (1) 4", (2) 2". Mechanical seals. 25 hp motor 230/460 volt, 1800 rpm. Dryer requires gear reducer.

Stock# 61537

Used- Aaron Process Equipment Vacuum Blender/Dryer, 100 Cubic Feet. 4' Wide x 8' long x 5' deep. Dome top. Stainless steel dimple jacket rated 90 psi. 8" shaft with 1/2" x 2" inner and outer ribbon, 8" center bottom discharge. Chain drive, 20 hp 3/60/220-440/900 rpm motor thru a Foote Bros gear reducer (no tag on gearbox). Equipped with outboard bearings and packing glands.

Stock# 77172

Used- CMR Rotary Vacuum Dryer, 101 Cubic Foot Working Capacity, 316 Stainless Steel. Approximate 60" diameter x 126" long, dished bolt on ends, stainless steel channel jacket, approximate 12" diameter cored shaft with paddles. Openings: top 18"; side 2 clean out doors; approximate 12" center bottom outlet with valve.

Stock# 77173

Used- CMR Rotary Vacuum Dryer, 101 Cubic Foot Working Capacity, 316 Stainless Steel. Approximate 60" diameter x 126" long, dished bolt on ends, stainless steel channel jacket, approximate 12" diameter cored shaft with paddles. Openings: top 18"; side 2 clean out doors; approximate 12" center bottom outlet with valve. Driven by an 18/11.5 kw (24/15 hp), 3/50/380 volt, 1455/730 rpm motor with fluid coupling thru an L Kissling gearbox.

Stock# 40388005

Used- Keltzenberg & Company Rotary Vacuum Dryer. Material of construction is 316TI stainless steel on product contact parts. 316TI stainless jacket. 209 cubic feet (5920 liter) working capacity. 44" diameter (1356 mm) x 12'8" (3953mm) straight side drying chamber. One removable end. Two inspection doors. Inside rated for 46.5 psi (3.1 bar) and full vacuum (-1) at 392 deg F (200 deg C). Jacket pressure 120 psi (8 bar) and full vacuum (-1) at 392 deg F (200 deg C). Paddle speed 3.4 rpm via a gearbox by an XP motor.

Stock# 40388006

Used- Keltzenberg & Company Rotary Vacuum Dryer. Material of construction is 316TI stainless steel on product contact parts. 316TI stainless jacket. 209 cubic feet (5920 liter) working capacity. 44" diameter (1356 mm) x 12'8" (3953mm) straight side drying chamber. One removable end. Two inspection doors. Inside rated for 46.5 psi (3.1 bar) and full vacuum (-1) at 392 deg F (200 deg C). Jacket pressure 120 psi (8 bar) and full vacuum (-1) at 392 deg F (200 deg C). Paddle speed 3.4 rpm via a gearbox by an XP motor.

Stock# 40388007

Used- Keltzenberg & Company Rotary Vacuum Dryer. Material of construction is 316TI stainless steel on product contact parts. 316TI stainless jacket. 209 cubic feet (5920 liter) working capacity. 44" diameter (1356 mm) x 12'8" (3953mm) straight side drying chamber. One removable end. Two inspection doors. Inside rated for 46.5 psi (3.1 bar) and full vacuum (-1) at 392 deg F (200 deg C). Jacket pressure 120 psi (8 bar) and full vacuum (-1) at 392 deg F (200 deg C). Paddle speed 3.4 rpm via a gearbox by an XP motor.

Stock# 47140

USED: Buss paddle rotary vacuum dryer (6000 liter) 211 cubic foot working capacity. 316L stainless steel contact parts. 1600mm (62.992") diameter x 4100 mm (161.417") long, dished ends. Rated internal vacuum jacket 2 bar. Openings: top 18", (2) 4-3/4" sightglass; side (2) 11" x15" inspection doors. Center plug valve outlet 9-1/2". Bare shafted. Driven By 11 Kw 6 Rpm Fixed Gear Drived Motor Drive.

Stock# 46213001

Used- Bethlehem Corporation Trough Style Vacuum Dryer Mixer, Approximately 500 Cubic Feet, 304L Stainless Steel. Internal rated 10 psi at 350 degrees F. Carbon Steel jacketed trough approximate 212" long x 70" wide x 80" deep, rated 75 psi and Full Vacuum at 350 degrees F. Approximate 18" diameter T-Bar agitator shaft with (32) paddles 18" long x 5" wide, welded on to 4" diameter posts. Welded top cover with openings, approximate 14" x 30" end bottom outlet. Driven by an approximate 40 hp motor thru gear box, no ratio tag, approximate 70 to 1. National Board # 4836. Serial # 36-1308-1A. Built 1981.
