Used Double Cone and V Rotary Vacuum Dryers

Stock# 84799

Used- Paul O. Abbe Double Cone Dryer, 1.1 Cubic Foot Working Capacity, 316 Stainless Steel. 18" diameter x 7" cone x 7" cone. 6" top with cover, 5" bottom outlet with manual butterfly valve. Driven by a 3/4 HP gearmotor with a ratio of 38.5:1. Mounted on a carbon steel base with casters. Unit is jacketed and rated 15 psi at 250 degrees F.

Stock# 48145001

Used- Patterson Kelley Liquid Solids Processor, 5 Cubic Feet Capacity. Stainless steel. Internal rated full vacuum at 250 deg. F. Rated for 300 lbs. / cuft. Bulk density. Vacuum pump and a Pacific Scientific liquid metering pump included as well as a Copper Rod Heating Unit. Yr. 1985.

Stock# 41821002

Used- Gemco Twin Shell Vacuum Dryer, Model Formulator, 20 cubic feet working capacity, 316L stainless steel. Maximum material density 60 pounds per cubic foot. Internal rated FV/10 psi at 250 degrees F. 304 stainless steel jacket rated 30 psi at 250 degrees F and 20 degrees F at 30 psi. (2) 18" diameter top charge ports, no covers. Shell driven by a 5 hp, 3/60/230/460 volt, 1750 rpm XP motor. (1) Internal agitator bar, driven by a 7.5 hp, 3/60/230/460 volt, 1740 rpm XP motor. 6" center bottom outlet. Unit includes a control panel and a Kinney Model KLRC-125-KFA 10 hp vacuum pump. Mounted on 74" tall carbon steel stands.

Stock# 44099089

Used- Patterson Kelley Twin Shell Solids Processor, 20 Cubic Feet. 316 Stainless steel construction product contact areas. Maximum material density 65 pounds a cubic foot. Internal rated full vacuum at 250 degrees F. 304 Stainless steel jacket rated 30 psi at 250 degrees F. Liquid solids bar driven by 5 hp, 230/460 volt xp motor, requires 2 hp DC main drive with brake. Mounted on a stainless steel stands with covers. Serial# 272560.

Stock# 47265001

Used- Patterson-Kelley Twin Shell Solids Processor, 20 Cubic Feet, Stainless Steel. Internal rated Full Vacuum at 200 degrees F, carbon steel jacket rated 30 psi at 200 degrees FV. Maximum material density 65 pounds a cubic foot. (2) 17" Diameter top charge ports with quick release covers, 8" center bottom outlet with a manually operated butterfly valve and a quick release cover. Shell driven by a 3 hp, 3/60/220/440 volt, 860 rpm motor thru a Falk reducer, ratio 71.7 to 1. Mounted on carbon steel stands with 36" tall leg extensions. Serial# 17157.

Stock# 47944002

Used- Paul O. Abbe Rota-Cone Vacuum Dryer. Approximate 20 cubic feet working capacity, stainless steel on product contact areas. Jacketed, channel type approx 14.7 psi @ 150F, 48" Diameter shell driven by a 2hp, 230/460 volt XP motor. 14" Diameter feed with cover, 8" outlet with a manual butterfly valve. Stainless steel vacuum & spray arm, high speed agitator bar, driven by a 5hp, 230/460 volt XP motor. Mounted on carbon steel stands. Approximate 78" overall height & 38" swing radius. Serial# A-9491-19239.

Stock# 48829003

Used- Gemco Twin Shell Vacuum Dryer, Model Formulator, 50 Cubic Feet Working Capacity, 316 Stainless Steel. Maximum material density 55 pounds per cubic foot. Internal rated. 304 Stainless steel jacket rated. (2) 24" diameter top charge ports with hinged covers. Shell driven by a Reeves variable speed drive, 5 hp, 3/60/230/460 volt, 1730 rpm gear motor, 2.2 to 1 ratio. Internal liquids/solids agitator bar, driven by a 15 hp, 3/60/230/460 volt, 1765 rpm XP motor. 16" Center bottom outlet with air operated valve. Includes (1) Tuthill/Kinney vacuum pump, Model KLRC-75-FA2, driven by a 5 hp motor, (1) solvent recovery tank, (1) gemcomatic, lot of extra parts. No controls. Serial# VD86230.

Stock# 48829001

Used- Patterson Kelly Twin Shell Vacuum 'V' Blender, 60 Cubic Feet Working Capacity, 304 Stainless Steel. Maximum material density 140 pounds a cubic foot. Internal rated full vacuum at 250 degrees F. Jacket rated Less than 15 psi at 250 degrees F. (2) 17-1/2" diameter top charge ports with quick release covers. Shell driven by a 2 hp, 3/60/208-220/440 volt, 1745 rpm gear motor 130 to 1 ratio. 12" Center bottom outlet with air operated valve. Includes (1) Travaini vacuum pump, Model TRW300V-1NR, Serial# 13816-02, driven by a 20 hp, 3/60/230/460 volt, 1760 rpm motor. (1) Patterson Kelly heat exchanger with 3/4 hp pump. (1) Set of extension legs, approximately 61-1/2" tall. Mounted on painted carbon steel stand. Serial# 220808.

Stock# 40024075

Used- De Dietrich Glass Lined Double Cone Dryer, 70 Cubic Feet Working Capacity (107 Total), Model SR3030, 3009 Blue Glass. Internal rated 40 PSI and Full Vacuum at 350 Degrees F, jacket rated 90 PSI and Full Vacuum at 350 Degrees F. 18'' charge with cover, 8'' outlet with valve. Driven by a 7.5 HP, 3/60/230/460 Volt, 1750 RPM motor with brake. Mounted on stands. Includes (1) Used Rosenmund Apovac Vacuum System consisting of: (1) Sulker Burckhardt hastelloy C22 pump, model PMZU2510H8, 15 HP XP motor; (1) Kontro pump, model 4, 2 HP motor; (1) Industrial Piping 105 gallon hastelloy C276 pressure tank; 35 square feet hastelloy C276 liquid ring cooler, 19 square feet hastelloy C276 suction condenser, 37 square feet hastelloy C276 exhaust condenser and misc piping and valves. Frame mounted.

Stock# 61730

Used- Patterson Industries Double Cone Vacuum Dryer, 132 Cubic Feet Working Capacity, 304 Stainless Steel. 7'6" Diameter x 16" straight side x 52" cones, rated FV at 250 deg F, carbon steel jacket rated 15 psi at 250 deg F. 16" discharge opening, 12" hand operated slide gate discharge valve, bull gear drive 10 hp 208-220/440/1745 rpm (with electric brake). Thru Westinghouse gearbox ratio 57:5 giving 30 rpm output. Equipped with Stokes vacuum pump model 212-11 with 7.5 hp 230/460 motor, displacement 150 cfm, input 3" flange, output 2" NPT.

Stock# 61731

Used- Patterson Industries Double Cone Vacuum Dryer, 132 Cubic Feet Working Capacity, 304 Stainless Steel. 7'6" Diameter x 16" straight side x 52" cones, rated FV at 250 deg F, carbon steel jacket rated 15 psi at 250 deg F. 16" discharge opening, 12" hand operated slide gate discharge valve, bull gear drive 10 hp 208-220/440/1745 rpm (with electric brake). Thru Westinghouse gearbox ratio 57.7:1 giving 30 rpm output.

Stock# 61733

USED: Patterson Industries double cone dryer, 132 max cubic foot working capacity, 304 stainless steel. 7'6" diameter x 16" straight side x 52" cones, rated FV at 300 deg F, carbon steel jacket rated 25 psi at 300 deg F. 16" discharge opening, 12" hand operated slide gate discharge valve, 7.5 hp, 3/60/230/460 volt, 1725 rpm thru Falk gearbox, ratio 46.59:1.

Stock# 64013

Used- Gemco Double Cone Vacuum Dryer, Model VD140. 140 Cubic feet working capacity, 316 stainless steel. Carbon steel jacket. 90" diameter x 22" straight side x 48" cones. 18" diameter top port with cover, 16" bottom outlet with a Gemco T type valve. Driven by a 5 hp, 3/60/230/460 volt, 1750 rpm motor thru a Dodge gearbox, ratio 15:1. Unit includes drum unloader and stands.

Stock# 40388001

Used- Klein Double Cone Vacuum Dryer, Approximate 235 Cubic Feet (6660 Lliter) Working Capacity, 353 cubic feet/10000 liter total capacity. 316TI stainless steel. Internal rated FV and 1.5 bar (22.5 psi) at 100 deg C (212 F), carbon steel jacket rated 2.3 bar (35.5 psi) at 100 deg C (212 F). (1) 17.55" (450mm) diameter center product inlet, (1) 11.7" (300 mm) diameter center bottom product outlet.

Stock# 48474

Used- Venuleth & Ellenberger Double Cone Dryer, 212 cubic feet (6000 liter) working capacity, 282 cubic feet (8000 liter) total, 304 stainless steel. Approximately 108'' diameter x 108'' high (3000 mm x 3000 mm). Carbon steel jacket rated for 45 psi (3 bar). Inside rated for full vacuum at 338 deg F (170 deg C). (1) 18" diameter (460 mm) product in and outlet. Driven by a 25 hp, 380 volt/50 cycle/3 ph explosion proof motor, braking mechanism. Mounted on 4 carbon steel legs. Overall dimensions are 19' long x 9' wide x 9' high (5800 mm long x 3000 mm wide x 3000 mm high).

Stock# 66632

Used- Henkhaus Stainless Steel Double Cone Vacuum Dryer, 8000 Liter (282 Cu Ft) Total Capacity. Unit measures approximately 3000 mm diameter x 1000 mm straight side x 1000 mm long cones. Internal rated full vacuum at 250 degrees C. Driven by a 5.5 kW, 3/50/380 volt, 14560 rpm variable speed drive 1-4.5 rpm. Unit includes internal vacuum tube. Leybold Heraeus vacuum skid. 2.6 kW, 3/50/220/380 volt, 1440 rpm vacuum pump. 7.5 kW, 3/50/380 volt, 2880 rpm vacuum booster.
