Used Rietz Disintegrator for Sale - 12” Diameter, 4” Outlet, Stainless Steel

Used- Rietz 12" Diameter 45 Degree Angle Disintegrator. 21" ID reduction chamber. (4) rows of 12" diameter, (5) hammers stacked on top with each other. (3) 12" diameter stainless steel 360 degrees reduction screens with 3/8" diameter perforations. Driven by Baldor 50hp, 3/60/460 volt, 3600 rpm direct drive motor. (2) 2" diameter sanitary threaded inlets with (1) reducer to 1" diameter tri-clamp, (1) 2" diameter tri-clamp fitting with cap. 4" Diameter sanitary thread outlet with reducer to 3" diameter tri-clamp fitting.

MFR: Rietz

Used IKA Works Inline Dispax Reactor – Model MHD/DR-PB 20, 50 HP Homogenizer

Used- IKA Works Inline Dispax Reactor. Mixing/Homogenizing/Dispersing, Model MHD/DR-PB 20. Nominal flow rate 30 gallons per minute, solids capacity 6200 pounds an hour. Driven by a 50 hp, 3/60/460 volt, 3535 rpm motor. 4" Solid inlet, 3" liquid inlet, 2" outlet. Unit mounted on a base Part # P015897. Serial # 2603-12.

MFR: IKA Works

APV Baker Perkins MP50/25D Twin Screw Extruder – 330 LBS/HR Capacity

Used- APV Baker Perkins Twin Screw Extruder, type MP50/25D. 50 mm dia. twin screws. 25:1 L/D. Co-rotating. Electrically heated, water cooled. Max Screw speed 500 RPM via a gearbox by a 55.2 KW (74hp)-3/50/400v AC motor. Max output capacity 150 kgs (330 Lbs) per hour. Complete with feeding system, die head, control panel and additional infrastructure. Previously used on PE/PP/PA/PC/ABS/PS in a Masterbatch application. Reported rebuild in 2017. Our freight specialists can assist you with door to door transportation and all customs documents needed to make the process go as smoothly as possible.

MFR: APV

Used Patterson-Kelley Twin Shell Blender – 50 Cu Ft Working Capacity, Stainless, 5 HP, Bottom Outlet

Used- Patterson Kelley Twin Shell Blender approximately 50 cubic foot working capacity, 83 cubic foot total capacity. Stainless steel mixer contacts with stands and leg extensions. Shell diameter 42". 5 Hp Motor 3/60/208-220-440V with reducer - approximately 14 rpm blender speed. Includes covers, leg extensions and guards. Bottom outlet with valve.

MFR: Patterson Kelley

Used Robinson Air Ring Blower – 50 HP, 5840 CFM | High-Performance Industrial Blower for Airflow & Ventilation Applications

Used- Robinson Air Ring Blower. Approximate 5840 CFM, Static pressure of 20 oz. Driven by a 50 HP, 3/240/480 volt, 3500 rpm motor.

MFR: Robinson

Industrial 50 Cu. Ft. Stainless Steel Twin Shell Blender – Patterson-Kelley

Used- Patterson-Kelley Twin Shell Blender, 50 Cubic Feet Capacity, 304 Stainless Steel. Rated 55 pounds per cubic foot maximum material density. Standard feed ports with covers, 10" discharge with manual butterfly valve on stainless steel stands. 5 hp, 220/440 volt xp motor drive with brake. Serial # 163723. THIS MACHINE CAN BE ASSEMBLED FOR CUSTOMER AT EXTRA COST.

MFR: Patterson Kelley

Used Patterson-Kelley Twin Shell Blender

Used- Patterson-Kelley (PK) Twin Shell Blender, 50 Cubic Feet Capacity, 304 Stainless Steel. Rated 55 pounds per cubic foot maximum material density. Standard feed ports with covers, 10" discharge with manual butterfly valve on stainless steel stands. 5 hp, 220/440 volt xp motor drive with brake. Serial # 163722. THIS MACHINE CAN BE ASSEMBLED FOR CUSTOMER AT EXTRA COST.

MFR: Patterson Kelley

Used 50 Cubic Foot Stainless Steel Double Ribbon Blender with 25 HP Drive

Used 50 Cubic Foot Stainless Steel Double Ribbon Blender with 25 HP Drive. Designed for efficient mixing of dry bulk materials and features a robust stainless steel bowl and ribbon assembly. The unit offers an approximate full capacity of 75 cubic feet and a working capacity of approximately 50 cubic feet, making it suitable for medium- to large-scale blending applications. Inside dimensions of approximately 80" long by 39.5" wide by 41". Equipped with a bottom end discharge system featuring an air-operated discharge valve located approximately 6" from the floor, allowing for efficient and controlled product release. The unit includes a three-piece cover for ease of access and maintenance. Driven by a 25 HP, 3-phase, 60 Hz, 230/460-volt motor, providing reliable performance for continuous industrial operation.

Used Tria Model TR 120 49 Granulator | 50 HP | 1,200 kg/hr | Water-Cooled, Soundproofed Plastic Recycling Grinder

Used Tria Model TR 120 49 Granulator | 50 HP | 1,200 kg/hr | Water-Cooled, Soundproofed Plastic Recycling Grinder. Diameter: 490 mm Rotor Width: 1,200 mm Feed Opening: Approximately 970 mm wide 120 mm high Rotor Type: Open rotor with 5 rows of 2 knives (10 total) Stator (Bed) Knives: 4 total (2 front, 2 rear) Drive Motor: 50 HP (approx. 37 kW) Voltage: 460V / 480V, 3-Phase Frequency: 60 Hz Cutting Chamber: Water-cooled Throughput Capacity: Up to ~1,200 kg/h (varies by material & screen size) Construction: Soundproofed steel enclosure with hinged access doors Screen Area: Large discharge screen for high throughput Feed System: Rear trap-door (ideal for thermoforming line integration) Knife Material: Tungsten-tipped for extended wear life Noise Reduction: Fully enclosed sound-insulated casing.

MFR: Tria

Used Tria TR 120-49 High-Capacity Granulator | 1,200 kg/hr | 490mm Rotor | 50 HP | Sound-Insulated | Water-Cooled Chamber

Used Tria TR 120-49 High-Capacity Granulator | 1,200 kg/hr | 490mm Rotor | 50 HP | Sound-Insulated | Water-Cooled Chamber. 1200mm rotor width. Approx. 970mm W 120mm H feed opening, rear trap-door feed system. Open rotor w. (5) rows of (2) knives (10 total). (2) front and (2) rear stator knives, (4) total. Water cooled cutting chamber. Large discharge screen. Enclosed in sound-insulated steel enclosure w/ hinged access doors. 50 HP (approx. 37 kW) drive motor, 3/60/460-480V.

MFR: Tria

Used GEA Panther1500 Lab Homogenizer – 150 MPa | 50 L/h | Nanoemulsion | High Shear | 2022 | <300 Hrs Use

Used- GEA Panther1500 Process Scale Homogenizer, Type Lab Panther Homogenizer 3006. Maximum pressure 150 MPa; Rated flow of 50 dm3/h; Nanoemulsification production rate (10 mg servings/h) 42,000; 21,700 PSI; 5.5 kW motor power; Includes: Spare parts package; 3A execution; Heat exchanger; IKA T-50 high shear mixer package. Nanoemulsification equipment for manufacturing premium beverages, edibles, and topicals. The GEA pressurizes the fluid and then releases it through a special homogenizing valve. The extreme shearing forces the emulsion experiences during this process causes the droplets to become extraordinarily small, improving its stability and bioavailability. Required Utilities: Lubricating and cooling water of 60 L/h. Reported to have less than 300 hours of use; Serial # 17144; New in 2022. Electrical Requirements: 400 VAC 50 HzAir Requirements: None. Our freight specialists can assist you with door to door transportation and all customs documents needed to make the process go as smoothly as possible.

Used Buhler BTSK 30/40D Twin Screw Extruder | 50 mm Co-Rotating Process Extruder

Used- Buhler BTSK 30/40D Twin Screw Extruder, 2 x 50 mm diameter side by side screws, 53:1 L/D ratio, 11-barrel sections, electrically heated water cooled. Driven by a 21 kw(31.5hp)-440-volt AC drive motor via a gear box. Screw speed maximum 800 RPM. Frame mounted, Control panel. Weight 1540 LDS/700 Kgs. Extruder: 2400 mm L x 500 mm W x 1450 mm H (extruder only). Previously used in a Teijin Aramid application. Our Freight Specialists can assist with any customs documents and forms to insure a smooth transition.

MFR: Buhler Inc.
