Used Perry Products FTSS-24-1204Z 1,204 Sq Ft 304L Stainless Steel Shell and Tube Heat Exchanger, 2011

Manufacturer Information

Perry Products Corporation is identified as the manufacturer of this industrial shell-and-tube heat exchanger. Model FTSS-24-1204Z features 304L stainless steel construction, a single-pass shell-side arrangement and a six-pass tube-side configuration. The exchanger is ASME U-stamped and designed for industrial heat transfer applications requiring pressure-rated equipment and compatible stainless steel materials of construction.

Main Product Description

Used Perry Products Corporation Model FTSS-24-1204Z stainless steel shell-and-tube heat exchanger, manufactured in 2011, with approximately 1,204 square feet of heat transfer surface area. Designed for industrial process heating, cooling and indirect heat transfer between compatible process fluids. Exchanger features a 304L stainless steel shell, tubes, tube sheets and internal baffles. The shell measures approximately 24" outside diameter, with a distance of 13'11-3/4" between tube sheet faces. Tube bundle consists of (438) straight tubes measuring 3/4" outside diameter x 0.083" wall thickness x 14' long. Features a single-pass shell-side configuration and six-pass tube-side arrangement for heat transfer between separate process streams. Shell side is designed for 200 PSIG at 350°F, while the tube side is designed for 200 PSIG at 500°F. Equipped with an expansion joint to accommodate thermal movement, saddle supports for horizontal installation, 8" shell-side inlet/outlet connections and 1/2" vent and drain connections. Constructed in accordance with ASME pressure vessel requirements and U-stamped. National Board #7500, Serial #B-7509, Job #17450. Estimated dry weight is approximately 6,000 lbs. Manufactured in 2011. Possible applications include industrial liquid heating and cooling, chemical processing, heat recovery, process water temperature control, thermal fluid heat exchange and other compatible industrial heat transfer operations.

Equipment Specifications

• Manufacturer: Perry Products Corporation

• Model: FTSS-24-1204Z

• Equipment Type: Shell-and-Tube Heat Exchanger

• Size: 24-168

• Condition: Used

• Year Manufactured: 2011

• Heat Transfer Surface Area: 1,204 Square Feet

• Shell Material: 304L Stainless Steel

• Tube Material: 304L Stainless Steel

• Tube Sheet Material: 304L Stainless Steel

• Baffle Material: 304L Stainless Steel

• Shell Outside Diameter: Approximately 24"

• Distance Between Tube Sheet Faces: 13'11-3/4"

• Tube Quantity: 438

• Tube Outside Diameter: 3/4"

• Tube Wall Thickness: 0.083"

• Tube Length: 14'

• Shell-Side Passes: 1

• Tube-Side Passes: 6

• Shell Design Pressure: 200 PSIG at 350°F

• Tube Design Pressure: 200 PSIG at 500°F

• Shell-Side Connections: (2) 8" Inlet/Outlet Connections

• Vent and Drain Connections: 1/2"

• Expansion Joint: Included

• Supports: Saddle Supports

• Construction Standard: ASME U-Stamped

• Estimated Dry Weight: 6,000 lbs

• Serial Number: B-7509

• Job Number: 17450

• National Board Number: 7500

Applications

• Industrial Process Heating: Transferring thermal energy from compatible heating media to process liquids in chemical manufacturing, industrial processing and production systems.

• Process Fluid Cooling: Removing heat from compatible liquid process streams using cooling water, glycol solutions or other suitable cooling media.

• Chemical Processing: Heating and cooling compatible chemical solutions, liquid intermediates and specialty chemical formulations during manufacturing and production.

• Pharmaceutical and Specialty Chemical Manufacturing: Providing indirect temperature control for compatible process liquids where 304L stainless steel construction meets process requirements.

• Industrial Water Heating and Cooling: Managing process water temperatures in manufacturing facilities, utility systems and industrial circulation loops.

• Heat Recovery Systems: Recovering thermal energy from compatible process streams and transferring it to other fluids to support industrial energy efficiency.

• Thermal Fluid Heat Transfer: Exchanging heat between compatible thermal fluids and process liquids within the equipment's specified pressure and temperature ratings.

• Petrochemical Processing: Heating or cooling chemically compatible process streams where 304L stainless steel construction and the exchanger's design ratings are appropriate.

• Food and Beverage Processing: Providing indirect heat transfer for compatible liquid ingredients and process water where equipment construction, cleaning capability and applicable sanitary requirements are satisfied.

• Closed-Loop Cooling Operations: Transferring heat between separate industrial fluid circuits without direct mixing of the process media.

Suitable Products and Materials

• Industrial Process Water: Cooling water, heated water, circulating process water and compatible industrial utility water.

• Glycol-Based Heat Transfer Fluids: Compatible ethylene glycol/water and propylene glycol/water solutions used in heating and cooling circuits.

• Chemical Process Liquids: Compatible aqueous chemical solutions, liquid intermediates, diluted chemical mixtures and specialty chemical formulations.

• Industrial Heat Transfer Fluids: Suitable thermal oils, heating fluids and cooling media compatible with 304L stainless steel and the exchanger's design limitations.

• Water-Based Industrial Solutions: Compatible water-based formulations, liquid additives and manufacturing process streams.

• Specialty Chemical Ingredients: Compatible liquid raw materials and chemical formulations requiring indirect heating or cooling.

• Industrial Cleaning Solutions: Selected aqueous cleaning formulations and compatible process liquids where temperature, concentration and corrosion characteristics are appropriate.

• Food Processing Liquids: Compatible liquid ingredients, process water and aqueous food formulations where construction and sanitation requirements are met.

• Water Treatment Fluids: Compatible treated water, recirculating water and industrial water treatment process streams.

Material suitability depends on fluid chemistry, concentration, temperature, pressure, viscosity, fouling potential and compatibility with 304L stainless steel. Chloride concentration and corrosion potential should be evaluated for water-based and chemical services.

Frequently Asked Questions

- What is the heat transfer surface area of this Perry Products heat exchanger?

This Perry Products Model FTSS-24-1204Z heat exchanger has approximately 1,204 square feet of heat transfer surface area.

- What type of heat exchanger is this?

This is an industrial shell-and-tube heat exchanger with a single-pass shell-side configuration and six-pass tube-side arrangement, designed for indirect heat transfer between compatible process fluids.

- What materials are used in its construction?

The shell, tubes, tube sheets and baffles are constructed of 304L stainless steel.

- How many tubes are included in the heat exchanger?

The exchanger contains 438 straight tubes measuring 3/4" outside diameter x 0.083" wall thickness x 14' long.

- What does the six-pass tube-side design mean?

The six-pass tube-side configuration directs the tube-side fluid through six successive passes through the tube bundle. This arrangement affects fluid velocity, pressure drop and heat transfer performance.

- What are the shell-side pressure and temperature ratings?

The shell side is designed for 200 PSIG at 350°F.

- What are the tube-side pressure and temperature ratings?

The tube side is designed for 200 PSIG at 500°F.

- What is the diameter and length of the heat exchanger?

The shell measures approximately 24" outside diameter, with a distance of 13'11-3/4" between the tube sheet faces. The tubes are 14' long.

- Does this heat exchanger include an expansion joint?

Yes. The exchanger is equipped with an expansion joint designed to accommodate thermal movement associated with temperature differences during operation.

- What connection sizes are provided?

The unit includes two 8" shell-side inlet/outlet connections and 1/2" vent and drain connections.

- Is this heat exchanger ASME certified?

The exchanger is ASME U-stamped and identified by National Board #7500. Available nameplate information and code documentation should be reviewed before installation.

- Can this heat exchanger be used for both heating and cooling?

Yes. Shell-and-tube heat exchangers are commonly used for indirect heating and cooling of compatible process fluids. Actual suitability depends on operating temperatures, flow rates, fluid properties, pressure drop and the thermal design.

- Is 304L stainless steel suitable for chemical processing?

304L stainless steel provides corrosion resistance for many compatible industrial fluids and chemical solutions. Suitability depends on the specific chemical composition, chloride content, concentration and operating temperature.

- What is the approximate weight of the exchanger?

The estimated dry weight is approximately 6,000 pounds. Final shipping weight should be confirmed before transportation.

- What is the difference between shell-side and tube-side operation?

In a shell-and-tube heat exchanger, one process fluid circulates through the internal tubes while the other flows around the outside of the tubes within the shell. Heat transfers across the tube walls without the two process streams directly mixing under normal operating conditions.

- Can Aaron Equipment help determine whether this exchanger is suitable for my application?

Yes. Aaron Equipment can assist with reviewing the available specifications, construction materials, heat transfer surface area, operating pressures, temperatures and connection requirements to help evaluate whether the exchanger may fit your process.

- Can Aaron Equipment arrange shipping for this shell-and-tube heat exchanger?

Yes. Aaron Equipment can assist with coordinating domestic and international freight transportation. With an estimated dry weight of 6,000 pounds, suitable loading, lifting and transportation arrangements should be evaluated before shipment.

- How can I request pricing, photographs or additional technical information?

Contact Aaron Equipment to request current pricing, availability, equipment photographs, available drawings, nameplate information and additional details for Perry Products Model FTSS-24-1204Z.
