Used Cast Film Lines

Stock# 40555001

Used- Cast Film Line, 14" wide, consisting of: (1) Egan 2-1/2" single screw extruder, approximately 32 to 1 L/D ratio. 5 zone electrically heated, water cooled, non-vented barrel with closed loop system with tank, pump, and heat exchanger. Driven by a 60 hp, 500 volt, 1750/2100 rpm DC motor thru a gearbox, ratio 11.06 to 1. (1) Manual screen changer. (1) Control panel with West 2070 controllers, and a Reliance VS Maxpax III drive, extruder serial #901846-479939, built 1991. (1) A & A Associates quench tank, 304 stainless steel, 24" x 33" x 31" deep, (2) 4" diameter x 17" wide rubber pull rolls, driven by a 1 hp gearmotor. (1) A & A Associates cooling tank, 304 stainless steel, 24" wide x 96" long x 12" deep with (2) sets of pull rolls, (1) control panel with Digitrac panels. (1) Independent Machine Company take up/slitter/winder, model 12SR, serial #6581-1290. (4) Slitter blades manually adjustable, (1) static eliminator, rubber/metal pull rolls, tension bar, two station winder, and a control panel. (3) Transformers, 15, 45, 75 kva.

Stock# 44941002

Used- Killion Laboratory Cast Unit. 10" Wide x 8" diameter casting roll. Mounted on same frame is a pull roll stand consisting of (2) 10" face x nominal 5" diameter pull rolls. Top roll is chrome. Bottom roll is rubber. Chrome cast roll is cored with rotary unions. Cast station is mounted on a water quench tank.

Stock# 45219002

Used- Davis Standard (2) Roll Casting Stand. (2) Approximate 18" Diameter x 30" wide chrome plated cored rolls, (1) fixed, (1) adjustable. Driven by a 2hp, 180 volt, 1750 rpm DC motor thru a reducer, ratio 17.70 to 1. S.O.# 51737, Serial# P-3232, Built 1994. (1) Davis Standard pull roll stand with approximate 46" long cooling conveyor, (5) manually adjustable slitting knifes, (2) 8" diameter x 30" wide pneumatically adjustable rubber pull rolls, driven by a 2hp, 180 volt, 1750 rpm DC motor, S.O.# 51737, Serial# P-3232, Built 1994. Includes a control panel with (2) Reliance drives.

Stock# 43752067

Used- Cincinnati Milacron (2) Roll Stack. Sheet take-off with 34" face x nominal 18" diameter rolls mounted in a vertical arrangement with temperature control system and pull rolls. Last used with a 2.5" extrusion line.

Stock# 40617003

Used- PTI 50" Wide S Wrap Pull Roll Assembly, Model SWU. (2) 24" diameter x 50" wide pneumatically adjustable polyurethane rolls, each roll driven by a gearmotor. Top mounted 6" diameter rubber nip roll. Built 2006.

Stock# 49296004

Used- Macro Engineering 62" Wide 3-Roll Chill Roll Stack. Package consists of the following: 62" wide Macro 3-roll stack with 18" top roll with 8" diameter rubber nip, 28" middle roll, 18" bottom roll with 8" diameter rubber nip. Rolls are hydraulically loaded and have 5 hp AC motors as individual roll drives each roll with a rotary union. Includes, motorized centering adjustment with approximately 4" travel, operator control panel, (2) Sterlco pumping systems for roll cooling. Macro 62" wide "S" wrap pull roll station driven by a 3 HP AC motor. Has shear cut slitting capability including 4 male knives and 8 female kinves. Has a load cell mounted spreader roll and pendant mounted operator control. Operator control panel including ABB variable frequency drives.

Stock# 49296010

Used- Bare Middle Cooling Roll. 36" O.D. x 92" face. For Schkopau PV film line.

Stock# 49296011

Used- Bare Middle Cooling Roll. 36" O.D. x 92" face. For Schkopau PV film line.
