Used Blown Film Lines

Stock# 42275031

Used- Ghioldi Blown Film Co-Extrusion Line. Including: N. 2 extruders diameter mm.55, 78 kW 30 L/D N. 1 extruder diameter 75 mm. 142 kW, 30 L/D n. 3 lever type screen changers, melt control system 3-layers still die mm.300 gap. mm. 1,4 IBC cooling system AM500/2 dual flow cooling ring 2 temperature exchange batteries, electrical cabinets with Mitzubishi inverters. Oscillating pull-off system width mm.1700, working width mm.1600 FIFE web guider mm.1700. Bubble driver with vertical adjustment and sensor for automatic bubble inflating back to back winding station 1600 with 4 expandible mandrels. Automatic film cutting, automatic reel unloading system. Bolted 12 mm. tall tower with 3 storey, ladders Cason corona treatment mm.1700 DOTECO gravimetrical units (1 for each extruder) 30.000 chilling units chiller Some spare parts included, manuals, drawings. English program for PLC.

Stock# 49373001

Used- Reifenhäuser Gloucester 3 Layer Co-Extrusion Blown Film Line. Designed for Geomembranes with a capacity of 1980-2640 pounds. (900-1200 kgs) per hour consisting of: (2) Gloucester 90 mm (3.5") single screw extruders, Type 90250.R2. 30:1 L/D ratio. non-vented barrel electrically heated, air cooled. Driven via a gearbox by a 180 hp 50/60 cycle motor. (1) Kreyenborg double screen changer, Type K-SWE 101 KV, on wheels. Includes: Plastcontrol feeding system. (1) Reifenhäuser 200 mm (7.8") single screw extruder, type RT 9501-1-200-30D. 30:1 L/D ratio. Non-vented barrel electrically heated, air cooled. Driven via a gearbox/motor. (1) Kreyenborg double screen changer, on wheels. Including: feeding system. (1) 3 Layer extrusion blown film die head designed for structured Geomembranes includes air ring with blower, on wheels. (1) Menzel 156" (4000 mm) width x 31.2" (800 mm) diameter take off winding station. For winding side-gusseted film tubes up to 156" (4000 mm) winding width. 3" (76.9 mm) and 6" (152 mm) cores. Maximum roll weight is 2475 pounds (1125 kgs). (1) Menzel 234" (6000 mm) width x 31.2" (800 mm) diameter take off winding. Core diameter 6" (152 mm). For all flat laying membrane products up to 234" (6000 mm) width. Center cut available for e.g. 2 x 117" (2 x 3000 mm) width or 78" + 156" (2000 + 4000 mm) width Maximum roll weight is 5940 pounds (2700 kgs). Includes (1) Flexoprint 1 color printer, (1) EBS black and white ink jet, Inside and outside film cooling. Includes control panels and further infrastructure. New year 1980/2011/2012.

Stock# 49413001

Used- Barmag 5 Layer Co-Extrusion Blown Film Line, type BF12-5/5-1400 AK. Capacity of 495 lbs. (220 kgs) per hour consisting of: (2) Barmag 45 mm (1.75") single screw extruders, type 4E8/27D-G. 27:1 L/D ratio. 3 Zone non-vented barrel electrically heated, air cooled. Driven via a gearbox by a 28.5 Kw/42.75 hp motor. Includes blending/feeding system. (1) Barmag 60 mm (2.34") single screw extruder, type 6E8/27D-G. 27:1 L/D ratio. 3 Zone non-vented barrel electrically heated, air cooled. Driven via a gearbox by a 49.5 Kw/74.25 hp motor. Includes blending/feeding system. (2) Bargmag 75 mm (2.93") single screw extruders, type 7E8/27D-G. 27:1 L/D ratio. 3 Zone non-vented barrel electrically heated, air cooled. Driven via a gearbox by a 70.5 Kw/105.75 hp motor. Includes blending/feeding system. (1) Barmag rotating blown film die, type RTV4/4E8-W 12.48"/23.4" (320 mm/600 mm) diameter, internal double cooling. Includes interchangeable inserts. On wheels, (1) Barmag cooling air ring, type UF1/320-600 with blower, (1) Barmag height adjustable collapsible frame, type with nip roll station. (1) Barmag after cooler, type NKW 1400, (1) Barmag stainless steel water bath, type WB-1400 incl. temp. control.(1) Barmag 54.6" (1400 mm) wide take off double winding station, type FWI9/1400-A/G-2. Max winding capacity 227.5 (70000 mm) per minut. Max dia. 31.2" (800mm) roll. Includes control panels and further infrastructure. New year 1992.

Stock# 49890001

Used- Windmoller & Holscher 80" 7 Layer Line, Model 2200MM. Blown Film; Die Size 450 mm; Oscilating Nips Size 2100 mm; Diameter Screws: Extruder (G) Varex 70 mm (Outer); Extruder (F) Varex 60 mm (Outer Tie); Extruder (E) Varex 60 mm (Middle Outer); Extruder (D) Varex 70 mm (Middle); Extruder (C) Varex 60 mm (Middle Inner); Extruder (B) Varex 60 m (Inner Tie); Extruder (A) Varex 90 mm (Inner); 30:1; Double Turret Winders; (7) Gravimetric Units; Also includes: Optifil 2, Auto Die Gap, Addex Dual Lip Air Ring, Cage, Beta Thickness Auto Profile Gage, Automatic Adjustment, 2200mm Oscillating Haul Off, Edge guide, Corona 4 side treater, Pillar 15kw Generator, 2200mm Secondary Nip, Edge Trim & Slitters, W&H Filmatic W7573 Single Turret Winders, 36" Diameter, Auto Cut, Slitting, Roll Hoists, Shaft Extractor, 3" & 6" Shafts, Computer Line Control. Mfg. 2000.
