Used Roll Stock or Die Cut Tray Sealers

Stock# 71652001

Used- ILPRA Koch KATS MAP Tray Sealer. Model 800VG. Machine is capable of approximately 10-15 cycles per minute. Designed for vacuum and gas flush packaging (MAP) using external vacuum source. Maximum tray size: 12.5" x 10" x 2.5". Maximum Film Web Width of 15". Four station turret. 31" long by 16" wide discharge belt conveyor. Operator tray and product load, equipped with scrap film unwind and automatic discharge onto included discharge conveyor. 3/60/220V. Serial # 8841.

Stock# 71646002

Used- MAP Systems Packaging Film Sealer. Uses premade tray and heat sealable film. Gas flush only, no vacuum. Model MS25. Serial # 5250101. Built 1999. Tooled for a 9.2" id cut-out in plate, approximate 10.5" outer diameter flange edge to flange edge.

Stock# 70841001

Used- G. Mondini Tray and Pan Sealer. Model CVS/T1-S. Machine is capable of speeds up to 30+ trays per minute. Is currently set up for a 3 pound 200mm x 600mm (8" x 24") molded paperboard tray with a clear film die cut seal. Also has tooling for crimp-style alum lids to alum trays. Has change parts for 2.5 pound, 200mm x 500mm (8" x 20") trays; 4 pound, 300mm x 600mm (12" x 24") trays; and 5 pound, 500mm x 600mm (20" x 24") trays. Has a 7" x 6' Intralux belt infeed, Serial # 1666-99. Has an Allen Bradley SLC 5/03 PLC programmable control module. 50 Amp, 3/60/208V.

Stock# 72057001

Used- Multivac MAP and Skin Tray Sealer. Model T-700. Last ran approximate 6" x 9" tray. New 2014. Does not include pump. Has extended infeed conveyor.

Stock# 71138001

Used- Omniseal Machines Model IDX 279 Tray Sealer. Has seal plates for both rectangular (5-3/4" x 7-7/8"), Oblique (5-3/4" x 7-7/8") and circular (5-5/8" diameter) trays. Stainless steel construction. Has an Allen Bradley MicroLogix 1500 PLC. 1/60/240V.

Stock# 70132001

Used- Orics Industries Modified Atmosphere Packaging Rotary Tray Sealer, Model R-20. Maximum performance of 13 cycles per minute (20-26 packages). Maximum platen size of 11-1/2" x 18-1/2". (4) Station, 2 up configuration. Consists of an R-20 MAP rotary heat seal machine with vacuum and gas flush. Sealing film web width of 12.5", 18" x 11" chamber, tooling. Has detection for no container, no fill, no seal, no print and no lid detector. Has a 2 up tray denester, Serial # DF2993D, 18" x 38" auto discharge conveyor, dual lane auto-infeed lug chain on 12" centers, each lane 6" wide x 216" long. PLC controls. Wash down and USDA approved. Mounted on casters. Last running frozen dinners. Tray tooling is 4" x 5-7/8" id, 5" x 6-7/8" od (outside flange to flange), rounded corner rectangular. Machine footprint 86" long x 70" wide x 72" tall, conveyor footprint 219" long x 40" wide x 88" tall.
