Used Full Case Palletizer

Stock# 70037112

Used- ABC Packaging Low Level Case Palletizer, Model 72A. Case size range 6"-19"(24"if a wheel is removed) long x 6"-16" wide x 4"-16" high. Maximum pallet size: 48" x 44" with wide side leading. Includes a pallet magazine. The transfer table has a roller stripper plate which reduces friction, allowing case transfer without squeezing or shifting the contents and deforming the case. Quick Jr. Proface Panel HMI. Allen-Bradley SLC 5/02 CPU and 160 VFD. Air requirement: avg 4 scfm, 80 psi. Electrical: 460V/3Ph/60H/12 FLA.

Stock# 71906002

Unused- ABC, Model 72A Case Palletizer. Has product timing infeed conveyor, 25" wide row forming conveyor with case turner. Standard row pusher. Low friction roller transfer table. Main frame with elevator and side squaring plates. 40 x 48 empty pallet dispenser with 2 chain feed conveyor. 90 deg (2) chain roller pallet transfer conveyor. 90 degree (3) chain roller pallet transfer conveyor. Rotary tier sheet inserter sheet bin. 36" product infeed elevation, 18" pallet conveyor elevation. Allen Bradley CompactLogix PLC with ethernet communication. Allen Bradley Panelview Plus 7-1000 terminal HMI. Elec: 3/60/480V. 80 PSI air, 4 scfm.

Stock# 71900002

Used- Alvey Model 800 Automatic Palletizer. Capable of speeds up to 75 cases per minute. Has Allen Bradley 5-20 PLC controls, last running 40 x 48 pallets. Has pallet feeder, compact design.

Stock# 71900003

Used- Alvey Model 880 High Level Palletizer. Capable of speeds up to 60 cases per minute. Has Allen Bradley 5-40 PLC control, AB HMI, 40 x 48 automatic pallet feeder. Maximum load weight: up to 3000 pounds. Maximum pallet load height: up to 80".

Stock# 70037114

Used- Low Level Case Palletizer for 40" x 48" GMA Style Pallets. Speeds of 10 to 15 cases per minute. Case flow - narrow-side leading. Pallet flow - wide-side leading. Allen-Bradley SLC controls with Panelview touchscreen. 75" maximum load height. 36" case infeed elevation and 18" full pallet discharge elevation. Air supply: 80 psi. Palletizer main frame dimensions and weight: 15'4"long x 7'9" wide x 9'7" high and 8,010 pounds. Infeed assembly dimensions and weight: 7'3" long x 3' wide x 3'6" high and 860 pounds. Electrical: 230V/3ph/60Hz. Price includes pallet dispenser and setup and testing for (1) package.

Stock# 70037116

Used- Columbia Pallet Dispenser. 40" x 48" GMA style pallets. Dual chains jump transfer. Pallet discharges with narrow side leading. Pallets lifting motor has 12 output rpm.

Stock# 71932003

Used- Lambert Material Handling 1200 Fully Automatic Bag Palletizer. Speeds up to 50 cases per minute based on layer pattern, load capacity 600 pounds per layer, Maximum load capacity 4000 at 70" height pallet, pallet size 48" x 40" x 5.5" tall. Includes pallet and sheet dispenser, (2) sections of discharge roller conveyor, control panel with Allen-Bradley PanelView 1000 and SLC5-03 CPU. Serial# 271, (1) Westfalia Technologies bag flattener inclined rubber belt conveyor, model 410-B.Approximate 24" wide x 16' long. Each belt driven by a gear motor, serial# 08-4748.

Stock# 70411013

Used- Skinetta Pac-Systems PALTEQ 1400 Automatic Palletizer. Servo driven, capable of speeds up to 12 movements per minute. Will handle formats as large as 600 x 400 x 400, 17 Kg (39#) case . . Maximum pallet height 1400mm (plus pallet height of 40mm). Automatic pallet feeder, AB PLC controls. Pallet dimensions: maximum 1200 x 800 x 140 mm or 1200 x 1000 x 140 mm. Optional 480V / 17 amp / 60 Hz. PSI: 6-8 bar. Built 2005. Equipment comes with two complete manuals.

Stock# 71962001

Used- Top Tier Low Infeed Conventional Palletizer. Rates 1-3 Layers/ Min. Infeed height 23.0"60.0". Minimum case dimension 4.5". Maximum case dimension 29.0". Maximum case height 36.0". Minimum layer dimension 38.0". Maximum layer dimension 50.0". Standard layer weight 300 lbs. Typical foot print 233"x 155". Controller Allen Bradley PLC. Includes Signode In Line Pre-Bander. Disassembled and loaded on buyers truck.
