Used X-Ray Metal Detectors

Stock# 72727011

Used- Loma X-Ray Metal Detector, Model X5 Spacesaver. 304 Stainless steel construction. 25kg max weight, 1/50/230v requirements. Serial# DEV-021680.

Stock# 72727023

Used-Loma X-Ray Metal Detector, Model X5 Spacesaver. 304 Stainless Steel. 25kg max weight. AAT technology allows the X-ray Diode setting to be changed depending on the product you are inspecting, offering the very best detection levels across the board. Using a 0.4mm setting for very small metal contaminants and 0.8mm and 1.6mm to find softer contaminants such as Bone, Ceramic and Glass. 1/50/230v requirements. Serial number DEV-021183.

Stock# 72629003

Used- Mettler Toledo (Safeline) X-Ray Metal Detector, Model PowerCheck 250. Capable of speeds up to 400' fpm (depending on size and application). Has a 20" X 9" aperature. 15" full color touch screen HMI with REAL automatic set-up software. A/B powerflex 4M drive. Air reject. Built 2015. 1/60/220V. Missing belt.

Stock# 72858001

Used- Mettler Toledo (Safeline) Model X3720 Plus 400mm X-Ray System for bottles and upright containers. Has reject. Mfg. 2019

Stock# 72781001

Used-Thermo Ramsey Model Xpert b600 Xray Metal Detection System; Product Rate: 10,000 Bulk Density (lbs/cubic foot); Standard Features: Line Length: 2173mm (85.5"), including infeed funnel and outfeed reject system.: Typical inspectable belt width: 474mm (18.6")@ 72mm (2.8") product depth (see beam geometry chart for other widths/heights); lnfeed hopper height: 1350mm (53.1"), +75mm (2.95") / -30mm (1.18"); Outfeed reject chute height: 547/Bmm (21.57"), +75mm (2.95") I -30mm (1.18"); Long life x-ray source: 200W (75kV/2.0mA) standard; High sensitivity 0.8mm detectors; Typically detects 1-2mm dia. metal, 3-4mm for other dense contaminants like glass and stone; Belt Speeds from 14 to 34 MPM (45 to 113 FPM) or 27 to 68 MPM (90 to 223 FPM); Wash down drum motors; Input funnel can be fed from the back, end or front of the machine; Easy Set-Up wizard; Easy debug; Troughed belt, fabric guides or hard plastic guide; Max reduct weight on belt is 50k; Pneumatic gate style rejecter, 1/2/3 or 4 lanes; Up to 8 lanes inspection with standard guide rails & up to 6 lanes with troughed belt guide rails.; Binary threshold, contrast detection, gradient threshold, groups and morphology filters for contaminants; High quality real-time or frozen image display. Last 20 reject image buffer; Rugged HD for storing reject images/statistics.; Watertight USB port; Windows 7 PC based with HMI touchscreen, 381 mm/15" diagonal; Multiple level password security system; Built-in cabinet air conditioner

Stock# 72781002

Used-Thermo Ramsey Model Xpert b600 Xray Metal Detection System; Product Rate: 10,000 Bulk Density (lbs/cubic foot); Standard Features: Line Length: 2173mm (85.5"), including infeed funnel and outfeed reject system.: Typical inspectable belt width: 474mm (18.6")@ 72mm (2.8") product depth (see beam geometry chart for other widths/heights); lnfeed hopper height: 1350mm (53.1"), +75mm (2.95") / -30mm (1.18"); Outfeed reject chute height: 547/Bmm (21.57"), +75mm (2.95") I -30mm (1.18"); Long life x-ray source: 200W (75kV/2.0mA) standard; High sensitivity 0.8mm detectors; Typically detects 1-2mm dia. metal, 3-4mm for other dense contaminants like glass and stone; Belt Speeds from 14 to 34 MPM (45 to 113 FPM) or 27 to 68 MPM (90 to 223 FPM); Wash down drum motors; Input funnel can be fed from the back, end or front of the machine; Easy Set-Up wizard; Easy debug; Troughed belt, fabric guides or hard plastic guide; Max reduct weight on belt is 50k; Pneumatic gate style rejecter, 1/2/3 or 4 lanes; Up to 8 lanes inspection with standard guide rails & up to 6 lanes with troughed belt guide rails.; Binary threshold, contrast detection, gradient threshold, groups and morphology filters for contaminants; High quality real-time or frozen image display. Last 20 reject image buffer; Rugged HD for storing reject images/statistics.; Watertight USB port; Windows 7 PC based with HMI touchscreen, 381 mm/15" diagonal; Multiple level password security system; Built-in cabinet air conditioner

Stock# 70970387

Used- ThermoFisher Scientifc X Ray Metal Detector, Model DYXIM S. Aperture approximately 5-1/2" wide x 26-1/2" long x 17-1/2" tall. Maximum inspection speed up to 100 m per minute. Detectable foreign bodies: glass from 2 mm, metal from 0.15 mm, stone from 2 mm, bone from 3 m, PVC & types of plastic from 3 mm. GP Tecno HMI. Includes Haskris Model R033 chiller. 230 Volt.

Stock# 72609002

Used- Safeline (Mettler Toledo) Model Sidechek + 400 X-Ray Metal Detector. Approximate aperture 8" wide x 11-3/4" tall. Conveyor 4-1/2" wide x 152" long. Connectivity/DataUSB or Ethernet RJ45 / Ethernet IP or OPC data, Display: Full color TFT 15-inch touch-screen. Cabinet/Conveyor: 304 Stainless Steel, Cooling Method: Heat exchanger or air conditioner, Ambient Humidity30-85%, Ambient Temperature: 32 to 104F. Scan Height: 8 inches, Belt Speed: VFD controlled maximum 600 fpm. Environmental Protection: NEMA 4 / IP65 standard; NEMA PW12 / IP69K optional. Cleaning: Low pressure standard, X-ray Generator: 70KV 1.5mA, 84KV 1.2mA, 50KV 2.0mA, Detector: 0.4mm, 0.8mm, 1.5mm pitch, X-ray Emissions: 5 µSv per hour, X-ray Protection: Line of sight, curtains, shielding, Certifications: CE standard; Controls Allen Bradley. 1/50/60/220 Volt, 10 amps.
